ARGON18 KRYPTON Manuel utilisateur

KRYPTON : ASSEMBLY GUIDE

Revision 3.0 - 06-01-2016

Assembly Overview . . . . . . . . . . . . . . . . . . . . . . . .................2

1. Frame inspection . . . . . . . . . . . . . . . . . . . . . ...................3

2. Headset installation . . . . . . . . . . . . . . . . . . . . ..................4

3. Cable housing installation . . . . . . . . . . . . . . . . . . . . . . . . ......5-7

4. Electronic drive-train specication . . . . . . . . . . ..........8-12

5. Saddle adjustment . . . . . . . . . . . . . . . . . . . . . . . .......... 13-14

6. Derailleur hanger adjustment. . . . . . . . . . . . . . . . . . . . . . . . 15-19

For the warranty to be valid, the bicycle must be fully assembled by an authorized Argon 18 dealer. High end components,

particularly carbon parts, need extra care when assembled. Those components must be installed using a calibrated torque

wrench to make sure every bolt is at the right torque setting to prevent damage.

KRYPTON : Table of contents

2. Headset installation 3. Cable housing installation

IMPORTANT NOTICE: It is easier to install the

cables and cable housings before the bearings.

5. Seatpost adjustment 6. Derailleur hanger adjustment

KRYPTON : Assembly overview

4. Electronic drive-train cable

routing specication

1. Frame inspection

KRYPTON : 1. Frame inspection

Parts installed on the frame Description Screw Tork Detail

type Nm

1 Seatpost, Ø 27.2mm Seatpost Carbon paste

2 Front derailleur hanger Screw 3mm 3Nm Loctite

3 Rear derailleur hanger Screw (2) 3mm 4Nm Loctite

4 Bottle cage Screw (4) 4mm 3Nm Grease

5 Seatpost collar Clamp 4mm 6Nm Grease

6 Rear derailleur cable stopper Screw (2) 2mm 2Nm Loctite

7 Bottom bracket cable guide Screw 5mm 3Nm Grease

When assembling a new frame, be sure to check if the following parts are assembled correctly.

KRYPTON : 2. Headset installation

Install the 3D headset (6) according

to the presst assembly guide. You

can choose from 3 dierent heights :

25mm, 15mm or 0mm.

KRYPTON : 3. Cable housing installation

A : barrel adjuster

brake and speed adjustment

B : metal cap

C : plastic cap

brake adjustment : B+A+B

speed adjustment : C+A+C

Install the front and rear derailleur

cable starting at the top of the down

tube.

For the derailleur and brakes cable,

measure a sucient lenght of housing

to be able to turn the handlebar both

ways correctly.

KRYPTON : 3. Cable housing installation (continued)

Rear brake cable housing

Remove the 2 cable stopper near the head tube

and seat collar.

Font section: Measure the necessairy cable

housing to ensure proper rotation of the

handlebar. Insert the cable through the shifter,

than insert the cable housing in the top tube.

Rear section: With a magnet, get the rear brake

cable out of the frame, and pass it trough the rear

cable stopper. Measure the rear housing correctly

to avoid interference with the rider’s left leg. Fix

the cable to the brake according to the brake

manufacturer assembly guide.

KRYPTON : 3. Cable housing installation (continued)

Front and rear derailleur: Pass

the two cables inside the

frame starting at the top tube

until they comes out under the

bottom bracket.

Pass both cables into the cable

guide (4d). Make sure the

5mm screw is set to 1.5 Nm.

For a Di2 conguration, use

the bottom bracket dedicated

cover for electric shifting (4i).

It’s better to install the cables

before installing the bottom

bracket and crank.

KRYPTON : 4. Electronic drive-train specication

The Di2 cable routing can be achieved easily using this

simple trick: use a brake cable and a metal cable end to

x the Di2 cable. For more information on Shimano Di2

electronic system installation, go to : http://si.shimano.com.

KRYPTON : 4. Electronic drive-train specication

Use the proper grommet on the

downtube to x the cable correctly,

depending if you us the mechanical

(4h) or electronic (5b-5c) drive-train.
