MAINTENANCE
Page 9 EN - English
ROUTINE CHECKS
Regularlytheusershouldperformabasicchecktoverifyifthe
appliance is functioning correctly, on the basis of the
following control points:
1. Check settings of electromechanical control panel.
2. Measure water hardness before/after appliance.
3. Check drain line from control valve; there shouldn’t be
any water flow(unless appliance is in regeneration).
4. Check drain line from brine cabinet overflow; there
shouldn’t be anywater flow.
5. Checkapplianceandsurroundingarea;thereshouldn’tbe
any water leakages.
BYPASSING THE APPLIANCE
Occasionally it may be necessary to put the appliance
hydraulically in bypass, i.e. to isolate it from the water
distribution system; f.e.:
in case of an urgent technical problem;
when it is not necessary to supply treated water to the
house/application (refill swimming pool, irrigation,...).
WITH 3-VALVE BYPASS SYSTEM (not included)
Picture 6.a
SERVICE POSITION
= bypass valve is CLOSED
= inlet valve to appliance is OPEN
= outlet valve from appliance is OPEN
Picture 6.b
BYPASSPOSITION
= bypass valve is OPEN
= inlet valve to appliance is CLOSED
= outlet valve from appliance is CLOSED
Picture 6.c
MAINTENANCE POSITION
= bypass valve is OPEN
= inlet valve to appliance is OPEN
= outlet valve from appliance is CLOSED
WATER CONDITIONER SALT
Picture 7
Theapplianceneeds'brine'foritsperiodicregenerations.This
brinesolutionismadefromwater,thatisautomaticallydosed
in the brine cabinet by the brine float valve, and water
conditioner salt. The user should make sure that the brine
cabinetisalwayskeptfullofwaterconditionersalt.Therefore
he should periodically check the salt level inside the brine
cabinet and refill it if necessary. The salt lid can be removed
completely tofacilitate refilling.
Ideally the level of water conditioner salt inside the brine
cabinet is kept between 1/3 and 2/3. A lower level of water
conditioner salt can cause insufficient brine saturation,
resultinginalossofsoftening capacity.Ahigherlevelofwater
conditioner salt can cause salt bridging (hard crust or salt
bridges in the brine cabinet). When you suspect salt bridging:
carefully pound on the outside of the brine cabinet to
break loose the salt bridges;
usingabroom(orlikeblunttool)carefullypushthesaltto
break it apart;
pour warm water over the top of the salt to dissolve it.
APPEARANCE
Toretaintheappearanceoftheappliance,simplywipeitwith
a damp cloth or clean it with a mild soap solution; never use
abrasive cleaners, ammonia or solvents.
RESIN CLEANER
Other contaminants (f.e. iron) present in the feed water can
causethe resin bed tofoul up, resulting in aloss of softening
capacity. An approved resin cleaner can be used periodically
to thoroughly clean the resin bed.
SANITIZING THE APPLIANCE
This appliance is manufactured from premium quality
material and assembled insafe conditions toassureit isclean
and sanitary. If installedandserviced correctly, thisappliance
willnotinfectorcontaminateyourwatersupply.However,as
in any 'device' plumbed-in in your water distribution system,
a proliferation of bacteria is possible, especially in case of
'stagnant water'. Therefore this appliance will automatically
rinse the resin bed periodically.
If the power supply to the appliance is disconnected for a
longer period of time, we recommend, when the power
supply is re-established, to manually initiate a complete
regeneration.
