Aquatic Serenity Studio 9 Manuel utilisateur

SPECIFICATIONS:

The manufacturer accepts a 1/4” variance. There are variations on each tub and speciﬁcations are subject to change as we improve upon our product as required. The dimensions needed for site preparation

and structure building should be measured from the tub; Aquatic Industries, Inc. assumes no responsibility for preparatory work. www.aquaticwhirlpools.com 800.555.5324

October 2007

Rough-In Plumbing

Measurements

SErENITy STudIO 9

SErENITy STudIO MODEL # AI9AIR7444 / AI9AIR7444TO (Tub Only)

Air Bath System:

- 60 Air Jets

- 1 HP Variable Speed Air Blower with 20-Minute Timer

- 600 Watt Air Heating System

- Electronic Control Package with Wave and Pulse Features

- Automatic Purge and Dry Cycle with Water Sensor

Aquatic Quality Features:

- Chromatherapy

- Slip Resistant Floor

- Air Channels Lined with Antimicrobial Coating

- Extra Deep and Long Bathing Well

- Pre-leveled ABS Support Base

- Durable, easy to clean, Lucite® Cast Acrylic Surface

- Available in 8 Standard No-Charge Colors

UL & IAPMO Listed, Factory Tested

Limited Lifetime Warranty

STANDARD EQUIPMENT:

• Comfort Pillow - Oval or Rectangle

• Lift & Turn Waste and Overow

- Chrome, Polished Brass, Gold, Polished Nickel,

Satin Nickel or Oil Rubbed Bronze

• Cable Drive Waste and Overow

- Chrome, Polished Brass, Gold, Polished Nickel,

Satin Nickel, Oil Rubbed Bronze or

Color Matched (Bone, White and Biscuit Only)

• Waterproof Remote Control with infrared sensor

and 25’ cord

• Optional Blower Location

• Remote Blower Wiring Kit

• Premium Colors

All acrylic colors featured by Aquatic match the

industry’s leading xture manufacturers.

OPTIONAL EQUIPMENT:

GENERAL SPECIFICATIONS:

Tub Size 74” x 44 1/2” x 23 1/2”

188 cm x 113 cm x 60 cm

Bathing Well 50” long

28” wide

21 1/2” interior depth

Shipping Weight 200 lbs. / 91 kg

Tub Weight Filled 1170 lbs. / 532 kg

Tub Only Weight 146 lbs. / 66 kg

Gallons to Overow 128 gal. / 485 L

ELECTRICAL SPECIFICATIONS:

Blower/Heater 1 HP; 10.5 AMP; 120V

Requirement 15 AMP; 120V, separate circuit

required protected w/ Class A GFCI

Two Person Bath

74”

Each Serenity Air Bath model is equipped with a 600 watt air heating system to raise the temperature of the air going into the bath. This air tem-

perature will be less than the bathing temperature of the water, but will help to reduce a rapid decrease in water temperature. In addition, the air

coming from the air jets will feel cool against the skin, just as a breeze on a warm day cools your body. This system does not heat the water.

44 1/2”

Blower Option 2

Standard

Blower

Location

Deck Width 3”

Note: Serenity tub only models feature

a Pre-leveled ABS Support Base.

44 1/2”

21 3/4”

20 1/2”

23 1/2”

Fax-On-Demand

Document # 1188

2 1/2”

13”
