Borg & OverströmGB
04
Dispense Options
Contents
Component/Feature Overview
Operation
Functions & Controls
Basic Troubleshooting
General Safety
GB
B2
Chilled
Ambient
NOTE: This booklet to be leftwith
appliance following installation.
User Guide
Level Sensor
Alarm
Waste Tank
Dispense Buttons
Drip Tray
Door
Component/
Feature Overview
B3 -
Major Components
Dispense Taps
Hot Switch
Chilled Switch
Water Inlet
IEC power socket
Drain Port
The temperature of the chilled
water can be set from 39˚F to
52˚F. When the chilling LED
is the set temperature has
been reached. This can take
up to one hour.
13
Connect and turn on the water
supply. Then connect the
power supply.
WARNING: On reservoir models the Carbon bag mustbe
removed from the cold tank before connecting to power and water.
Dispense from all options (to Turn on the cold switch (located
at the rear on the unit) to begin
the chilling process.
Turn on the hot switch (also
located at the rear on the unit) to
activate the heating element.
5
Flush through 10 litres of water
before use.
10 L
cold
hot
heating
cold
hot
6
Chilled & Ambient:
When the Green LED is on the
cooling circuit is activated.
When the Yellow LED is on the
compressor is operating.
Chilled & Hot:
When the Green LED is on the
cooling circuit is activated.
When the Yellow LED is on
heating circuit is activated.
When the Red LED is on the
heating element is activated.
7
Allow up to 1 hour for the
water to reach its minimum
temperature.
1
hour
cold
hot
heating
cold
hot
cold
hot
heating
Operation
2
The relevant indicator lights
will be lit.
4
8
cold
hot
52˚F
39˚F
Functions & Controls
Factory set to:
Cold Thermostat
NB: Turn clockwise to decrease water temperature
The temperature of cold water can be set from 39˚F to 52˚F.
Basic Settings
39˚F
52˚F
Controls
Ambient or
Hot Water Lock
& Hot Water
Button
Ambient or
Hot Water
Button
Chilled Water
Button
Hot Water
Lock
HotModels:Lift hot water lock
button prior to dispense
Hot Models: Press hot water
lock button and then hot water
button to dispense.
Chilled Water
Button
+˚F
-˚F
6 inches
•Leave a space no less than 6 inches
between the wall and dispenser.
•Keep the machine away from
sunlight, heat and moisture.
WARNING: On reservoir models
the Carbon bag must be removed
from the cold tank before connecting
to power and water.
General Safety
Basic Troubleshooting
Problem/Report Possible Cause Suggested Action
No Water Dispensing Water supply turned off. Check that power supply, and all taps/ valves/
lters on the incoming water supply are tted
and are turned on.
“Leak detector”” (if tted) tripped off. Disconnect the power and water supply, check
for leaks. To reset the machine contact your
distributor.
Faulty water pressure regulator, or other
failure.
Contact your distributor.
Warm Drinks Insufcient cooling air ow through the
fridge.
Contact your distributor.
Faulty compressor, or other failure.
Water lying on top edge of
lower door panel and/or
bottom of cabinet.
Overowing drip tray waste container. Empty waste container and check drainpipe is
not blocked.
Water lying in bottom of
machine.
Leak in pipe work and/ or lter. Contact your distributor.
Bleeping Noise Level sensor tted and tank full. Empty level sensor tank.
For full distributor
service manual visit:
www.youraquaessentials.com
Customer services:
Email: [email protected]
Call: 1 (615) 942-7867
Fax: 1 (615) 345-0500
Aqua Essentials
1416 Antioch Pike, Suite 103
Nashville, TN 37013
Verson: 010219
