APS GR18GEC00U Manuel utilisateur

Grille Installation Instruction

The instruction here is for your reference only. You may need to bend the grille a little bit to

adjust to fit. We strongly recommend the professional installer for best result.

Part#

Application

05~10 Chrysler 300/300C

Parts List

Item

Part Name

QTY

Description

Item

Part Name

QTY

Description

Grille

SS./ AL

Washer

Stud

6-32×1 1/2″

Plastic Body Retainers

For replacing the OEM

Retainers

Lock Nut

6-32

Install Notes: Overlay × Replacement Drill Cut 

Step

Description

illustration

Identify the grille & hardware with parts list.

Pop hood, remove the black plastic cover (on top of OEM grille / front panel) from vehicle. This will allow access to the

rear of the grille shell.

Option: If necessary, according to the factory menu, remove the front bumper (with OEM grille) from vehicle.

According to the factory menu, remove

the OEM grille shell from vehicle.

Secure the studs to the welded nut on the

rear of the grille.

6-32×1 1/2"

Center the grille into the opening on the

factory front bumper. Be sure the studs

are through the factory holes on the front

bumper.

*if necessary, drill holes on the lip of the

front bumper according to the position of

the studs.

GR18GEC00U

Please use masking tape and tape the OEM grille shell along the edge to protect your vehicle during

installation.

We are not responsible for any damage caused by the installation. Thank you for choosing our product!

Grille Installation Instruction

Part#

GR18GEC00U

Application

05~10 Chrysler 300/300C

Secure grille onto the front bumper using

the washers & lock nuts from the back

side of the OEM front bumper.

(10)Lock Nuts & (10) Washers

Make sure the grille is centered and tighten the fasteners.

Re-install the front bumper with grille on to the vehicle.

Reinstall the black plastic cover which was removed in step 2

Installation completed!!!

The instruction here is for your reference only. You may need to bend the grille a little bit to

adjust to fit. We strongly recommend the professional installer for best result.

Please use masking tape and tape the OEM grille shell along the edge to protect your vehicle during

installation.

We are not responsible for any damage caused by the installation. Thank you for choosing our product!

Discover other car and truck custom grilles on our website.
