MPI Magnetostrictive Level Sensors
User Manual
For The MPI-E, MPI-E Chemical, and MPI-R
Intrinsically Safe
ii Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
Table of Contents
Introduction ................................................................................................................ iii
Warranty and Warranty Restrictions.................................................................... iv
Chapter 1: Specications and Options..................................................................... 1
Dimensions ....................................................................................................................................1-3
Specications ................................................................................................................................... 4
MPI-E Model Number Congurator............................................................................................. 5
MPI-E Chemical Model Number Congurator........................................................................... 6
MPI-R Model Number Congurator............................................................................................. 7
System Wiring Diagrams and IS Use Case Diagrams .......................................................... 8-9
Chapter 2: Installation and Removal Procedures and Notes............................ 10
Tools Needed................................................................................................................................... 10
ATEX Stated Conditions of Use................................................................................................... 10
Physical Installation Notes ......................................................................................................... 10
Physical Installation Instructions ..............................................................................................11
Electrical Installation ................................................................................................................... 12
Loss of Signal Indication.............................................................................................................. 12
Removal Instructions ................................................................................................................... 12
Chapter 3: Programming .......................................................................................... 13
Modbus Programming .................................................................................................................. 13
Modbus Programming with RST-6001 and APG Modbus Software .................................... 13
Modbus Register Lists For MPI-E/R .....................................................................................13-14
MPI-E/R Modbus Sensor Parameters...................................................................................15-19
MPI-E/R Modbus Application Type Parameters...............................................................20-24
Chapter 4: Maintenance ...........................................................................................25
General Care.................................................................................................................................... 25
Repair and Returns........................................................................................................................ 25
Chapter 5: Hazardous Location Installation and Certication.........................26
Intrinsically Safe Installation Drawing for Hazardous Locations ......................................26
CSA Certicate of Compliance.............................................................................................. 27-30
IECEX Certicate of Conformity............................................................................................31-34
iii
Introduction
Thank you for purchasing an MPI series magnetostrictive level sensor from APG. We appreciate your
business and your trust. Please take a few minutes to familiarize yourself with your MPI and this manual.
The MPI series magnetostrictive level sensor provides highly accurate and repeatable level readings in a
wide variety of liquid level measurement applications. It is certied for installation in Class I, Division 1 and
Class I, Zones 0 hazardous areas in the US and Canada by CSA, and ATEX and IECEx for Europe and the rest
of the world. The MPI-R’s large, buoyant, and robust oats allow it to be used in harsh applications where
fouling or buildup might otherwise be of concern. The smaller, lighter weight oats of the MPI-E allow it
to be used in applications where space is limited. The MPI-E Chemical has a chemical resistant coating,
allowing for use in corrosive, acidic, and marine environments.
Reading your label
Every APG instrument comes with a label that includes the instrument’s model number, part number,
and serial number. Please ensure that the part number on your label matches your order. The following
electrical ratings and approvals are also listed on the label. Please refer to the Certicate of Compliance at
the back of this manual for further details.
8-24 VDC, Imax = 280 mA
Class I, Division 1, Groups C, D, T4
Class I, Zone 0; AEX ia IIB T4 Ga;
Ex ia IIB T4 Ga, IP65
Ta = -40°C to 85°C
Intrinsically Safe Wiring Requirements:
U
i= 28 VDC, Ii = 280 mA, Pi = 0.850 W , Li = 3.50 μH, Ci = 0.374 μF
ATEX Certicate Number: Sira 19ATEX2072X
II 1G
Ex ia IIB T4 Ga
Ta: -40°C to 85°C
U
i= 28 V, Ii= 280 mA, Pi= 0.850 W, Li = 3.50 μH, Ci = 0.374 μF
IECEx SIR 19.0026X
Ex ia IIB T4 Ga
Ta: -40°C to 85°C
US
C
237484
iv Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
Warranty and Warranty Restrictions
This product is covered by APG’s warranty to be free from defects in material and workmanship under
normal use and service of the product for 24 months. For a full explanation of our Warranty, please visit
https://www.apgsensors.com/about-us/terms-conditions. Contact Technical Support to receive a Return
Material Authorization before shipping your product back.
Scan the QR code below to read the full explanation of our Warranty on your tablet or smartphone.
DANGER: WARNING -- EXPLOSION HAZARD -- SUBSTITUTION OF COMPONENTS MAY IMPAIR INTRINSIC
SAFETY;
AVERTISSEMENT -- RISQUE D’EXPLOSION -- LA SUBSTITION DE COMPOSANT PEUT AMELIORER LA SECURITE
INTRINSIQUE.
DANGER: WARNING -- EXPLOSION HAZARD -- DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS
BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NON-HAZARDOUS;
AVERTISSEMENT -- RISQUE D’EXPLOSION -- AVANT DE DECONNECTER L’EQUIPEMENT, COUPER LE COURANT
OU S’ASSURER QUE L’EMPLACEMENT EST DESIGNE NON DANGEREUX.
DANGER: OPEN CIRCUIT BEFORE REMOVING COVER or KEEP COVER TIGHT WHILE CIRCUITS ARE ALIVE;
AVERTISSEMENT -- COUPER LE COURANT AVANT D’ENLEVER LE COUVERCLE, ou GARDER LE COUVERCLE
FERME TANT QUE LES CIRCUITS SONT SOUS TENSION.
IMPORTANT: MPI level sensor MUST be installed according to drawing 9005491
(Intrinsically Safe Installation Drawing for Hazardous Locations) on page 26 to meet listed
approvals. Faulty installation will invalidate all safety approvals and ratings.
IMPORTANT: Only the combustion gas detection performance of the instrument has
been tested.
1
Chapter 1: Specications and Options
MPI-E Sensor and Float Dimensions
• Dimensions
4.21”
3.74”
7.32-7.44”
6.53-6.65”
5.00”
4.25”
5.71”
4.92”
S1
Dead-Band
(from Zero
Reference to
Float Ref.)
S2
Dead-Band
(from Float
Ref. to bottom
of stem)
3/4” NPT
1/2” NPT
2.38”
4.94”
4.15”
ZERO
REFERENCE
Min. 12”
Max. 153”
GROUND
SCREW
Ø 0.27”
3/4” NPT
1/2” NPT
Housing
Connection
Location
1.91”
1.88”
G
Float Ref.
S1=6”
S2=2.38”
Note:
For dual dimensions, large
housing dimensions are
above small housing
dimensions.
Float Options
2.00”
2.06”
A & B
Float Ref.
S1=6”
S2=1.4”
1.38”
1.63”
C & D
2.20”
1.47”
F
1.87”
1.78”
E
Float Ref.
S1=6”
S2=1.1”
Float Ref.
S1=6”
S2=2.27”
Float Ref.
S1=6”
S2=1.5”
2Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
MPI-E Chemical Sensor and Float Dimensions
4.21”
3.74”
7.07”
6.28”
5.00”
4.25”
5.71”
4.92”
Kynar Float
S1
Dead-Band
(from Zero
Reference to
Float Ref.)
S2
Dead-Band
(from Float
Ref. to bottom
of stem)
3/4” NPT
2.13”
4.94”
4.15”
ZERO
REFERENCE
Min. 12”
Max. 153”
1.91”
1.88”
G
Float Ref.
S1=6”
S2=2.38”
Note:
S2 increases to 2.88” if bottom float stop used.
Ø 0.27”
3/4” NPT
Housing
Connection
Location
Note:
For dual dimensions, large
housing dimensions are
above small housing
dimensions.
3
MPI-R Sensor and Float Dimensions
5.00”
4.25”
5.71”
4.92”
5.00”
5.10”
5.88”4.98”
3.03”
3.00”
5.50”
3.08”
2.80”
3.07”
Float Ref.
S1=10.63”
S2=6”
Float Ref.
S1=12.25”
S2=4.25”
Float Ref.
S1=12.25”
S2=4.25”
Float Options
Y & Z / L & M
W & X
S & T
U & V / I & J
I & J U & V
4.21”
3.74”
6.84” - 6.97”
6.05” - 6.18”
S1
Dead-Band
(from Zero
Reference to
Float Ref.)
S2
Dead-Band
(from Float
Ref. to bottom
of stem)
Float
Ref.
S1=10”
S2=6.5”
3/4” NPT
1/2” NPT
1.90”
4.94”
4.15”
2.00”
Y & Z
L & M
U & V
I & J
Min. 48”
Max. 300”
ZERO
REFERENCE
GROUND
SCREW
Ø 0.27”
3/4” NPT
1/2” NPT
Housing
Connection
Location
Note:
For dual dimensions, large
housing dimensions are
above small housing
dimensions.
4Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
Performance
Resolution 0.04 in. (1 mm)
Accuracy ±0.04 in. (±1 mm)
Digital Temp Sensor Accuracy ±1°C
Environmental
Operating Temperature -40° to 185° F (-40° to 85° C)
Enclosure Protection NEMA 4X, IP65
Maximum Operating Pressure MPI-E Chem: 30 PSIA @ 70° F (21° C)
Electrical
Supply Voltage 8-24 VDC on sensor
Typical Current Draw 24 mA (MPI-E)
25 mA (MPI-R)
Protection Reverse Polarity and Surge (per IEC 61000-4-5, 4-6, 4-7)
Materials of Construction
Housing Cast aluminum, epoxy coated
Stem MPI-E: 0.5” Ø 316L SS
MPI-E Chemical: 0.5” Ø 316L SS with chemical
resistant coating
MPI-R: 1” Ø 316L SS
Mounting (slide) 316L SS
Compression Fitting (slide) Aluminum with Neoprene bushing
Connectivity
Output Modbus RTU (RS-485)
Programming
RS-485 Optional RST-6001 USB-to-RS-485 converter
• Specications
5
• MPI-E Model Number Congurator
Model Number: MPI - _E_ __5__ _____ - _____ _____ - _____ _____ _____ __B__ - _____ - _____ - _____
A B C D E F G H I J K L
A. Stem Type
□E 0.5 in. diameter, rigid
B. Output
□5 Modbus RTU, with surge protection, Intrinsically Safe
C. Housing Type
All Housing Die-cast Aluminum, NEMA 4X, IP65, Blue
□__ Large Housing
□A▲ Small Housing
D. Float 1 (Top Float)
□A 316L SS Round (0.65 SG)
□B 316L SS Round (0.92 SG)
□C 316L SS Cylindrical (0.65 SG)
□D 316L SS Cylindrical (0.92 SG)
□E Buna-N (0.5 SG)
□F 316 SS 3A Cylindrical (0.5 SG)
□G Kynar Cylindrical (0.66 SG)
E. Float 2 (optional)
□N None
□B 316L SS Round (0.92 SG)†
F. Mounting Type
□P▲ NPT Plug 150#
□N None
G. Mounting Size
□1.5 1.5 in. (welded or slide connection)
□2▲ 2 in. (welded or slide connection)
□3 3 in. (slide connection)
□N None
H. Mounting Connection
□W Welded (xed)
□S Slide with Compression Fitting (adjustable)
I. Stem Finish Material
□B 316L SS
J. Total Stem Length in Inches
□__ Min. 12 in. - Max. 153 in.
K. Temperature Sensor Options
□N▲ None
□1D Digital Temperature Sensor A, 12 in. from bottom of
probe
□2D Digital Temperature Sensors A, B
□3D Digital Temperature Sensors A, B, C
□4D Digital Temperature Sensors A, B, C, D
□5D Digital Temperature Sensors A, B, C, D, E
□6D Digital Temperature Sensors A, B, C, D, E, F
□7D Digital Temperature Sensors A, B, C, D, E, F, G
Note: Temperature sensors B - G are spaced evenly between A
and probe’s zero reference.
L. Custom Housing-Electrical Connection††
□N▲ None
□B Cable Gland (Cable sold separately)
□C 4-pin M12 Micro Connector Female
□D 4-pin M12 Micro Connector Male - 90°
□F 4-pin M12 Micro Connector Female - 90°
□G 90° Elbow
□M 4-pin M12 Micro Connector Male
Note: ▲This option is standard.
Note: †Must be used with Top Float A.
Note: ††Connectors available for use with Small Housing only.
For Large Housing, choose N None.
6Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
Model Number: MPI - _E_ __5__ _____ - __G__ __N__ - __P__ __2__ __W__ __E__ - _____ - _____ - _____
A B C D E F G H I J K L
A. Stem Type
□E 0.5 in. diameter, rigid
B. Output
□5 Modbus RTU, with surge protection, Intrinsically Safe
C. Housing Type
All Housing Die-cast Aluminum, NEMA 4X, IP65, Blue
□__ Large Housing
□A▲ Small Housing
D. Float 1
□G Kynar Cylindrical (0.66 SG)
E. Float 2
□N None
F. Mounting Type
□P NPT Plug 150#
G. Mounting Size
□2 Size 2
H. Mounting Connection
□W Welded (xed)
I. Stem Finish Material
□E ETFE Fluon Coating
J. Total Stem Length in Inches
□__ Min. 12 in. - Max. 153 in.
K. Temperature Sensor Options
□N▲ None
□1D Digital Temperature Sensor A, 12 in. from bottom of
probe
□2D Digital Temperature Sensors A, B
□3D Digital Temperature Sensors A, B, C
□4D Digital Temperature Sensors A, B, C, D
□5D Digital Temperature Sensors A, B, C, D, E
□6D Digital Temperature Sensors A, B, C, D, E, F
□7D Digital Temperature Sensors A, B, C, D, E, F, G
Note: Temperature sensors B - G are spaced evenly between A
and probe’s zero reference.
L. Custom Housing-Electrical Connection†
□N▲ None
□B Cable Gland (Cable sold separately)
□C 4-pin M12 Micro Connector Female
□D 4-pin M12 Micro Connector Male - 90°
□F 4-pin M12 Micro Connector Female - 90°
□G 90° Elbow
□M 4-pin M12 Micro Connector Male
Note: ▲This option is standard.
Note: †Connectors available for use with Small Housing only. For
Large Housing, choose N None.
Autres manuels pour MPI-E
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels APG Instrument de mesure
APG
APG DST-2421 Manuel utilisateur
APG
APG ACF-10 Series Manuel utilisateur
APG
APG PG2 Series Manuel utilisateur
APG
APG PG-2000 Manuel utilisateur
APG
APG PG10 Manuel utilisateur
APG
APG PG5 Manuel utilisateur
APG
APG RPX Series Manuel utilisateur
APG
APG PG-7 Manuel utilisateur
APG
APG PG-5000 Manuel utilisateur
Manuels Instrument de mesure populaires d'autres marques
Endress+Hauser
Endress+Hauser Proline Promag 50 Caractéristiques techniques
Siemens
Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces
KLINGER
KLINGER CMF V Series Manuel utilisateur
EXFO
EXFO FTB-2 Manuel d'exploitation et d'entretien
Keysight
Keysight M8290A Manuel utilisateur
ADTEK
ADTEK MW-5 Manuel utilisateur
