SET UP THE RCU
Step 1 Take the inner member (smaller slide channel) apart by
sharply pulling the front activating release latch forward.
Step 2 Each slide is pre-attached with front and rear adjustable
brackets. Loosen the nuts on the both brackets, and
decide the proper setback distance to the opening, then
tighten the nuts on the front brackets.
Step 3 Extend the rear brackets to where it reaches the rear rack.
Do not fully tighten rear bracket screws until final adjustment is made.
Repeat step 2 & step 3 above for other side of outer slide member.
Step 4 For chassis width of 430mm, attach the L-shaped bracket to
the front mounting flange using screw & nylon ring from
screw kit (bar nut kit is optional for your selection).
For chassis width over 430mm, attach the L-shaped bracket
to the back of the mounting flange using screw & nylon ring
from screw kit.
Step 5 For chassis width of 430mm, attach the L-shaped bracket to
the rear mounting flange using & nylon ring from screw kit,
then tighten rear bracket mounting.
For chassis width over 430mm, attach the L-shaped bracket
to the back of the mounting flange screw & nylon ring from
screw kit.
Repeat step 4 & step 5 for the other side of the slide.
Step 6 Attach the inner slide member to your RCU using screw from
screw kit.
