Ameriwood HOME 8760500EBL Manuel utilisateur

8760500EBL

NIGHTSTAND



‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B348760500EBL0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

WARNING

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

DWR

SIDE

DWR

BACK

BoardIdentification

A B

GHI

Left Panel

38760341010

Right Panel

38760341020

Top

38760337030

Bottom

38760341040

Rear Molding

38760341080

Front Molding

38760341070

Drawer Front

38760341090

Drawer Bottom

K876033160

Drawer Side

39991167346200C

Drawer Back

39991167035540B

Tube

You

DWR

BOTTOM

BACK

PANEL

Back Panel

K876034100

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

5

ameriwoodhome.com

DWR

BACK

DWR

SIDE

DWR

SIDE

BoardIdentification

Notactualsize

Tube

You

Drawersidesanddrawerbackare

labledwithpartdescription.

DWR

BOTTOM

BACK

PANEL

6

ameriwoodhome.com

PartList

ActualSize

Tube

You

NotActualSize

(x4)

#A22620

camlock

710

13a

13b

13c

13d13d13d

(x4)

#A22610

cambolt

(x4)

#A22900

connector

(x4)

#A22910

connector bolt

(x2)

#A21660

wood dowel

(x4)

#A23030

confirmatscrew

(x20)

#A21110

nail

(x2)

#A17030

5/16"bolt

(x4)

#A21970

drivefastener

(x12)

#A12930

1‐1/8"panhead

(x8)

#A12120

7/16"panhead

(x10)

#A11080

7/16"flathead

LeftCabinetMember

RightCabinetMember

LeftDrawerMember

RightDrawerMember

(x1)

#A56770

DrawerSlideKit

(x2)

#A54520

DrawerBracket

(x1)

#A50408

handle

(x4)

#A44420

foot

Note that your unit may contain extra hardware

7

ameriwoodhome.com

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Tube

You

(x2)

#A22620

(x2)

#A22900 (x1)

#A21660

Youwillneedtotaptheconnector

(3)withahammertofullyinsert.

Besuretheconnectorispositioned

asshownbeforepushingintohole.

8

ameriwoodhome.com

STEP2

Tube

You

*rawedgesareshaded

13a

(x1)

#A56770

LeftCabinetMember

(x3)

#A11080

Attachleftcabinetmember(13a)totheleftpanel(A)withscrews(7)asshown.

Marked with a "L".

13a

9

ameriwoodhome.com

STEP3

Tube

You

(x2)

#A12930

Attachtherearmolding(H)totheleftpanel(A)withtwoscrews(9)asshown.

Note: You will screw into the groove of the rear molding (H).

Besurethetopedgeoftheleftpanel(A)and

rearmolding(H)areflushwitheachother.

10

ameriwoodhome.com

STEP4

Tube

You

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x2)

#A22620

(x2)

#A22900 (x1)

#A21660

Youwillneedtotaptheconnector

(3)withahammertofullyinsert.

Besuretheconnectorispositioned

asshownbeforepushingintohole.
