Ameriwood HOME 6925015COM Manuel utilisateur

6925015COM

Kids Desk With Chair

- Unit can tip over causing severe injury or death.

- Anchor unit to stud in wall (if instructed to).

- Do Not allow children to climb on unit.

- Put heavy items on lower shelves or drawers.

B34 6925015 COM00SF

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

WARNING

Follow Ameriwood Home

Date of Purchase ___ / ___ / ___

Lot Number:

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Assembly Difficulty Meter

Easy Tough

Follow Ameriwood Home

Helpful Hints

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a R (right) and L (left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

PEOPLE NEEDED FOR ASSEMBLY: 1-2

ESTIMATED ASSEMBLY TIME: 1 HOUR

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

ameriwoodhome.com

Board Identification

Not Actual Size

Hutch back panel

T6925015010SF

Hutch side panel

T6925015020SF

Hutch partition panel

T6925015030SF

Hutch fixed shelf

T6925015040SF

Hutch divider

T6925015050SF

QTY: 4 PCS

Desk top

T6925015060SF

Board Identification

Not Actual Size

Leg frame

T6925015070SF

Support

T6925015080SF

QTY: 2 PCS

Partition

T6925015090SF

Right side panel

T6925015100SF

Fixed panel

T6925015110SF

Bottom panel

T6925015120SF

GHI

JKL

ameriwoodhome.com

Board Identification

Not Actual Size

Adjustable shelf

T6925015130SF

Back panel

T6925015140SF

Door

T6925015150SF

Leg

T6925015160SF

QTY: 4 PCS

Drawer front

T6925015170SF

Drawer back

T6925015180SF

Left drawer side

T6925015190SF

Right drawer side

T6925015200SF

Drawer bottom

T6925015210SF

MNO

STU

ameriwoodhome.com

Board Identification

Not Actual Size

Chair back

T6925015220SF

Chair seat

T6925015230SF

Chair left front leg

T6925015240SF

Chair right front leg

T6925015250SF

VWX

ameriwoodhome.com

Board Identification

Not Actual Size

Actual Size

ameriwoodhome.com

Part List

Hardware Bag Reference Number:

26925015COM0SF

x 30

Ø6X30mm

Wood dowel

TSF0003

Bolt

TSF0451

x 6

Ø1/4X35mm

Bolt

TSF0452

x 10

Ø1/4X50mm

Bolt

TSF0453

x 4

Ø1/4X73mm

x 30

3.8X32mm

Screw

TSF0951

x 2

3X12mm

Screw

TSF0953

Ø5/32X19mm

Screw bolt

TSF2014

7x 2

Not Actual Size

ameriwoodhome.com

Part List

Hardware Bag Reference Number:

26925015COM0SF

x 4

x 1

Ø15X9.5mm

Cam lock

TSF0311

8x 8 10

Shelf support

TSF0008

Ø7X15mm

Glue

TSF0015

x 1

Magnetic catch

TSF0052

x 8

Cam bolt

TSF0359

x 1

M4X54mm

Hex key

TSF2810

x 8 x 8

Ø7X18XT1.5mmØ7 X10XT1.5mm

Spring washer

TSF2404

Washer

TSF2405

13 14

x 2

Knob

TSF2217

x 8

Ø1/4*11*9.2mm

Nut

TSF0310
