Ameriwood HOME Franklin 5062918COM Manuel utilisateur

DateofPurchase___/___/___

B345062918COM00NN

LotNumber:

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

WARNING

FollowAmeriwoodHome

Tube

You

AssemblyDifficultyMeter

Easy Tough

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

5062918COM

Franklin Accent Table

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.com

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.

‐Identify,sortandcountthepartsbeforeattemptingassembly.

‐Compressiondowelsarelightlytappedinwithahammer.

‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.

‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.

‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.

‐Backpanelmustbeusedtomakesureyourunitissturdy.

‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.

‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You

Readthrougheachstepcarefullyandfollowtheproperorder

Separateandcountallyourpartsandhardware

Giveyourselfenoughroomfortheassemblyprocess

Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

A B D

Top Panel

T5062918010NN Left Side Panel

T5062918020NN Shelf

T5062918040NN

Right Side Panel

T5062918030NN

E F H

Back Frame

T5062918050NN Front Frame

T5062918060NN Drawer Left Side Panel

T5062918080NN

Drawer Face Panel

T5062918070NN

IJK

Drawer Right Side Panel

T5062918090NN Drawer Bottom Panel

T5062918100NN Drawer Back Panel

T5062918110NN

X 1 X 1 X 1 X 1

X 1 X 1 X 2 X 2

X 2

5

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

6

ameriwoodhome.com

PartList

ActualSize

Tube

You

6 X 35 mm

15 X 11 mm 8 X 30 mm

4 X 57 mm 4 X 30 mm 8 X 8 mm

4 X 20 mm.

Dia 24 X 24 mm

HardwareBag Reference Number:

250629180NN

x12

Cam bolt

TNN0001 x12

Cam lock

TNN0002

Wood dowel

TNN0003

Allen wrench

TNN0004

x20

Wood screw

TNN0005 x16

Plastic nut

TNN0006

Metal knob

TNN0013

Bolt for knob

TNN0008

7

ameriwoodhome.com

STEP1

Tube

You

*rawedgesareshaded

Insertfourcamlocksintoeachshelfasshown.

2x8

Proper orientation of CAM LOCK

Tip

Assembly

Quick

8

ameriwoodhome.com

STEP2

Tube

You

*rawedgesareshaded

9

ameriwoodhome.com

STEP3

Tube

You

*rawedgesareshaded

Proper orientation of CAM LOCK

Tip

Assembly

Quick

10

ameriwoodhome.com

STEP4

Tube

You

*rawedgesareshaded

Proper orientation of CAM LOCK

Tip

Assembly

Quick
