Ameriwood HOME 6701025COM Manuel utilisateur

6701025COM

6DrawerDresser

B346701025COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

AssemblyDifficultyMeter

Easy Tough

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuries

canoccurfromtippingfurniture.

SecureYourFurniture

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BeforeYouStart

Quick

Assembly

Tip

5

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

LeftPanel

36701025010

RightPanel

36701025020

Top

36701025040

Bottom(x2)

36701025050

Kick(x2)

36701025070 DrawerFront(x4)

36701025090

BackPanel

K670100000

DrawerBack(x6)

39992149051390B

DrawerBottom(x6)

39992341052410D

DrawerSide(x12)

39992149346200C

DEF

TopRail(x2)

36701025060

UpperDrawerFront(x2)

36701025080

HIDWR

SIDE

DWR

BACK DWR

BTM

BACK

PNL

Partition

36701025030

6

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

DWR

BACK

DWR

BTM

BACK

PNL

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

DWR

SIDE

DWR

SIDE

HDWR

SIDE

DWR

BTM

DWR

BACK

DWR

SIDE

7

ameriwoodhome.com

PartList

ActualSize

Tube

You

(x18)

#A22620

camlock

(x18)

#A22610

cambolt

(x18)

#A21660

wooddowel

(x24)

#A21970

drivefastener

(x60)

#A12120

7/16"screw

(x60)

#A11080

7/16"screw

(x12)

#A17400

7/8"bolt

(x30)

#A21110

nail

(x4)

#A22820

connector

(x4)

#A22810

connector bolt

8

ameriwoodhome.com

PartList

Notactualsize

Tube

You

(x1)

#A84050

wall anchor kit

(x6)

#A54900

drawerbrace

13d

13c

13b

13a 14

12d

12c

12b

12a

leftcabinetmember

rightcabinetmember

leftdrawermember

rightdrawermember

(x6)

#A56720

slide

(x6)

#A51405

handle

(x12)

#A54520

drawerbracket

9

ameriwoodhome.com

STEP1

(x2)

(x3) (x2) (x9)

(x3)

"L"

12a

Proper orientation of CAM LOCK

Tip

Assembly

Quick

10

ameriwoodhome.com

STEP2

12b

(x2) (x3) (x2) (x9)

(x3)

"R"

12b

Proper orientation of CAM LOCK

Tip

Assembly

Quick
