Ameriwood HOME 6667214COM Manuel utilisateur

6667214COM

BeverageCabinet

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B346667214COM

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

WARNING

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com AssemblyDifficultyMeter

Easy Tough

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You



Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.

4

ameriwoodhome.com

BeforeYouStart

Quick

Tip

Assembly

Tube

You

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

LeftPanel

36667214010 RightPanel

36667214020

Partition

36667214030

Top

36667214040

Bottom

36667214050

Support(x2)

36667214060 Shelf(x2)

36667214070

ShelfRail(x2)

36667214080

ShelfDivider(x12)

36667214090

DrawerFront(x2)

36667214100

BackPanel

K666721400

LeftDrawerSide(x2)

39991120346010L

RightDrawerSide(x2)

39991120346010R

DrawerBack(x2)

39991120042500B

DrawerBottom(x2)

39991340043610D

LFT

DRW

SIDE

RGT

DRW

SIDE

DWR

BTM

DWR

BACK

PNL

BCD

EFGH

6

ameriwoodhome.com

BoardIdentification

Tube

You

Thispieceispaperboardconstruction.

Itisnotmadefromwood,butis

requiredfortheassemblyofyourunit.

LFT

DRW

SIDE

DWR

BTM

DWR

BACK

RGT

DRW

SIDE

BACK

PNL

7

ameriwoodhome.com

PartList

ActualSize

Tube

You

(x10)

#A22610

cam bolt

(x10)

#A22620

cam lock

(x10)

#A21670

wood dowel (x6)

#A23030

confirmat

(x4)

#A17300

3/4" bolt

(x8)

#A80250

shelf support

(x30)

#A21110

nail

(x8)

#A12120

7/16" screw

(x20)

#A11080

7/16" screw

(x20)

#A14220

1/2" screw

345

(x6)

#A21960

hidden fastener

(x12)

#A21980

hidden face connector

(x8)

#A11600

1-1/4" screw

8

ameriwoodhome.com

PartList

Tube

You

NotActualSize

LeftCabinetMember

14a

RightCabinetMember

14b

14c

LeftDrawerMember

RightDrawerMember

14d

(x2)

#A56750

slide

(x5)

#A44620

hair pin leg

(x4)

#A54210

drawer bracket

(x2)

#A50340

pull

9

ameriwoodhome.com

STEP1

(x1)

Proper orientation of CAM LOCK

Tip

Assembly

Quick

14a

(x2) (x2) (x3)

(x1)

Markedwitha"L"

14a

10

ameriwoodhome.com

STEP2

123

514b

(x1) (x2) (x2) (x3)

(x1)

Markedwitha"R"

14b

Proper orientation of CAM LOCK

Tip

Assembly

Quick
