Ameriwood HOME 3799341COM Manuel utilisateur

3799341COM

FireplaceMantel

B343799341COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

SecureYourFurniture

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



PresspartstogethersoCAMBOLTinserts

intoedgehole.

PressCAMBOLTintohole. PressCAMLOCKintohole.

Endhole

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

Arrowtopointtowardsend

holeinedgeofpart.

4

ameriwoodhome.com

BeforeYouStart

Quick

Assembly

Tip

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

33799341010

RightPanel

33799341020

Top

33799341030 Bottom

33799341040

ABCD

LeftRail

33799341050

RightRail

33799341060

RearSideRail(x2)

33799341070

Kick

33799341080

FireplaceRail(x2)

33799341090

FireplaceLongRail

33799341100

UpperMolding

33779341110

FrontPanel

33799341120

EFG

LCenterMolding

33799341130

LeftCenterMolding

33799341140

RightCenterMolding

33799341150

6

ameriwoodhome.com

BoardIdentification

Notactualsize

RearSupport

33799000160

7

ameriwoodhome.com

PartList

ActualSize

NotActualSize

(x12)

#A22700

cam lock

(x12)

#A22710

cam bolt

(x4)

#A21670

wood dowel

(x7)

#A12120

7/16" screw

(x1)

#A84000

safety strap kit

(x14)

#A22761

quickloc

12a

(x1)

#A95090

fireplace insert

12e

12d

12c

12b

(x12)

#A12820

1" screw

(x3)

#A23030

confirmat

(x6)

#A22790

lock bolt

(x6)

#A22795

lock sleeve

(x6)

#A21960

hidden fastener

(x1)

#A53655

"L" bracket

678

8

ameriwoodhome.com

STEP1

(x2)

(x3)

(x2)

(x1)

Proper orientation of CAM LOCK

Tip

Assembly

Quick

9

ameriwoodhome.com

STEP2

123

(x2) (x2) (x1) (x3)

Proper orientation of CAM LOCK

Tip

Assembly

Quick

10

ameriwoodhome.com

STEP3

(x4)

(x6) (x6)
