Ameriwood HOME 1362807COM Manuel utilisateur

B341362000COM0

THIS INSTRUCTION BOOKLET CONTAINS

IMPORTANT

SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

Follow Ameriwood Home

Tube

You

Date of Purchase ___ / ___ / ___

Lot Number:

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Assembly Difficulty Meter

Easy Tough

1362807COM WITH PINK BINS

1362810COM WITH BLUE BINS

1362811COM WITH GREEN BINS

1362813COM WITH ORANGE BINS

Nightstand

- Unit can tip over causing severe injury or death

- Anchor unit to stud in wall

- Do Not allow children to climb on unit

- Put heavy items on lower shelves or drawers

Helpful Hints

ameriwoodhome.com

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com to view the

limited warranty valid in the U.S. and Canada.

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a

(right) and

(left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

Tube

You

PEOPLE NEEDED FOR ASSEMBLY: 1-2

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Parts are labeled on the surface or edge of the part

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

ameriwoodhome.com

Before You Start

Quick

Assembly

Tip

Please Note:

You may need to lightly tap the wood dowels into the holes during

your assembly process.

ameriwoodhome.com

Board Identification

Not actual size

This piece is paperboard

construction. It is not made

from wood, but is required for

the assembly of your unit.

Left Panel

31362015010 Right Panel

31362015020

Left Shelf

31362015060

Top

31362015040

Kick

31362015080 Back Panel

K136201500

Partition

31362015030

Bottom

31362015050

Right Shelf

31362015070

BACK

PNL

ameriwoodhome.com

Board Identification

Not actual size

Fabric Bin

BACK

PNL

ameriwoodhome.com

Part List

Actual Size

Not Actual Size

(x20)

#A22610

cam bolt

(x20)

#A22620

cam lock

(x13)

#A21670

wood dowel

(x2)

#A53510

angle bracket

(x4)

#A12120

7/16" pan head

(x22)

#A21110

nail

(x2)

#A91690 (Pink)

#A91700 (Blue)

#A91670 (Green)

#A91680 (Orange)

fabric bin

(x2)

#A51712 (Pink)

#A51710 (Blue)

#A51711 (Green)

#A51713 (Orange)

knob

Note: You will only have 1 color of the fabric bin and knob

depending on the purchased model number.

(x2)

#A23030

confirmat screw

ameriwoodhome.com

STEP1

(x5)

(x2) (x2)

Proper orientation of CAM LOCK

Tip

Assembly

Quick

ameriwoodhome.com

STEP2

(x5) (x2) (x2)

Proper orientation of CAM LOCK

Tip

Assembly

Quick

ameriwoodhome.com

STEP3

(x4)

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x2) (x4)

Right Side

Left Side
