Ameriwood HOME 9605337COM Manuel utilisateur

9605337COM

bookcase

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B349605337COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

WARNING

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

LeftPanel

39605337010 RightPanel

39605337020

Top

39605337030

Bottom

39605337040

UpperApron

39605337050

LowerApron

39605337060 x2

VerticalMolding

39605337070

UpperMolding

39605337080

LowerMolding

39605337090

FixedShelf

39605337100

AdjustableShelf

39605337110

BackPanel

K960533700

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

HIJ

5

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

6

ameriwoodhome.com

PartList

ActualSize

Tube

You

NotActualSize

(x12)

#A22570

cam lock

(x12)

#A22510

cam bolt

(x6)

#A21660

wood dowel

(x16)

#A12955

1-1/8" flat head

(x8)

#A80250

shelf support

(x6)

#A53600

angle bracket

(x12)

#A12210

#8 x 1/2" pan head

(x36)

#A21110

nail

12 3 45

9(x1)

#A84050

safety bracket kit

9c 9d

7

ameriwoodhome.com

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Tube

You

(x2)

#A22570

1234

(x4)

#A22510

(x1)

#A21660

(x5)

#A12955

endview

8

ameriwoodhome.com

STEP2

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Tube

You

1234

(x2)

#A22570 (x4)

#A22510

(x1)

#A21660

(x5)

#A12955

endview

9

ameriwoodhome.com

STEP3

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Tube

You

(x4)

#A22570 (x2)

#A21660

10

ameriwoodhome.com

STEP4

Proper orientation of CAM LOCK

Tip

Assembly

Quick

Tube

You

134

(x4)

#A22570 (x2)

#A21660 (x3)

#A12955

endview
