DATA SHEET

ADC720 Series

Color Specialty Cameras

Features That Make a Difference:

1/3-inch interline color imager, NTSC format

330-line color imager

Sharp picture

Sensitive to IR illumination and weather resistant (ADC722WP)

Discreet housings

Automatic electronic shutter

Automatic gain control

Auto tracing white balance

12 VDC input via included regulated power supply

The ADC720 camera series features color imagers that deliver

sharp pictures at a budget-friendly price and offer several

unique camera housings.

The ADC720D features a dome housing that makes it an

economical and discreet alternative to a standard camera.

It is easy to install and provides the 330 TVL pictures

you need.

The ADC722WP features a weather-resistant tube design.

Twelve built-in infrared (IR) illumination LEDs allow this camera

to produce a quality picture with 0 lux ambient light up to

10 meters (30 ft). The IR illuminators enable the camera to

electronically switch from color to black and white, making

them ideal for variable light applications, such as outside,

or indoor rooms that receive considerable sunlight.

The ADC723PIR is a standard motion detector shell

with a camera mounted discreetly inside, effectively

disguising it as a security system device that easily blends

with its surroundings.

ADC720D

ADC722WP

ADC723PIR

Product offerings and specifications are subject to change without notice. Actual products may vary from photos.

Not all products include all features. Availability varies by region; contact your sales representative.

Certain product names mentioned herein may be trade names and/or registered trademarks of other companies.

www.americandynamics.net

SPECIFICATIONS

Model Numbers

ADC720D . . . . . . . . . . . . . . . . . Color camera, 4-inch micro dome, 3.6 mm lens

ADC722WP. . . . . . . . . . . . . . . . Color camera, weather-resistant bullet housing,

6.0 mm lens, IR illuminators and mount

ADC723PIR. . . . . . . . . . . . . . . . Color camera, non-functional PIR detector

housing, 3.7 mm lens

Operational

NTSC Imager . . . . . . . . . . . . . . Interline transfer 1/3-inch CCD

Video Output . . . . . . . . . . . . . . 1.0 Vp-p 75

Active Pixels Count. . . . . . . . . . 512 (H), 492 (V)

Minimum Scene Illumination. . . 2.0 lux max at F2.0

Horizontal Resolution . . . . . . . . 330 TVL

Light Compensation Modes . . . Auto electronic shutter 1/60 to 1/100,000

Synchronization Modes . . . . . . Internal

White Balance. . . . . . . . . . . . . . Automatic

S/N Ratio . . . . . . . . . . . . . . . . . -48 dB

Electrical

Input Voltage. . . . . . . . . . . . . . . 120 VAC @ 60 Hz (regulated 12 VDC)

Included Power

Supply Output . . . . . . . . . . . . . 12 VDC (±10%)

Power Consumption. . . . . . . . . ADC720D 110 mA, ADC722WP 110 mA (IR off),

260 mA (IR on), ADC723PIR 80 mA

Regulatory

Emissions . . . . . . . . . . . . . . . . . FCC Part 15, Class B, ICES-003

Safety . . . . . . . . . . . . . . . . . . . . UL 1310 (power supply only)

Environmental

Operating Temperature. . . . . . . 0º to 50º C (32º to 122º F)

Humidity . . . . . . . . . . . . . . . . . . 90% RH (non-condensing)

Storage Temperature . . . . . . . . -20º to +60º C (-4º to 140º F)

RoHS Compliant

ADC720D ADC722WP ADC723PIR

Dimensions 100 x 57 mm

3.94 x 2.2 in (D x H) 65 x 105 mm

2.5 x 4.1 in (D x L) 70 x 110 x 49 mm

2.7 x 4.3 x 1.9 in (W x H x D)

Weight .18 kg (.40 lbs) .55 kg (1.20 lbs) .18 kg (.40 lbs)

Shipping Weight .43 kg (.90 lbs) .80 kg (1.80 lbs) .43 kg (.90 lbs)

Environmental Indoor Only Indoor/Outdoor Indoor Only

Lens/Horizontal FOV 1/3 inch / 92° 1/3 inch / 54° 1/3 inch / 90°
