American Dynamics AD615 Manuel utilisateur

DeltaDome™ Programmable Surveillance Camera

Configuration Utility Quick Reference Guide

8000-2613-02, Rev. B Quick Reference Guide

This Quick Reference Guide illustrates the screens found in the

DeltaDome Programmable Surveillance Camera Configuration

Utility. The large numbers in the circles represent the number of

the screen. The small numbers appearing to the right of the menu

choices represent the screen you will see if you pick that choice.

Note: The numbers in the circles do not actually appear on the

screens.

To start the configuration utility, do one of the following:

•For SensorNet or RS-422, press and hold Iris Open, press and

hold a Focus button, then press Zoom Out.

•For Manchester, turn the key switch to Prog (or disable the

system lock on the TOUCH TRACKER®), use the keypad to enter

66, then press Set Preset..

Refer to the keyboard or TOUCH TRACKER operating instructions

for the locations of the control buttons.

DOME CONFIGURATION MENU

PAN/TILT/ZOOM OPTIONS

CAMERA / LENS FUNCTIONS

ALARMS / AREAS / HOME

ON-SCREEN TEXT DISPLAY

LANGUAGE / PASSWORD

EXIT AND SAVE CHANGES

QUIT WITHOUT SAVING

RESET TO FACTORY SETTINGS

NOTE: If password protection is enabled, you must enter the

password before the Dome Configuration Menu will display.

Refer to screen 19 for information.

The following table describes the functions of the controls used

to interact with the screens. Where a specific Focus button is not

specified, either the Focus Near or Focus Far button may be used.

Function Control

Display configuration menu (SensorNet and RS-422

only) Iris Open, Focus,

then Zoom Out

Display configuration menu (Manchester only) Key switch to Prog,

66, then Set Preset

Save and exit utility from any screen (not supported

on Manchester) Iris Close then

Focus

Moves highlight bar up Tilt Up

Moves highlight bar down Tilt Down

Moves highlight bar right Pan Right

Moves highlight bar left Pan Left

Selects the highlighted item Focus Far

Increases the value or displays the next choice

During naming, moves the cursor to the right of the

current character in the name

Zoom In

(Zoom Tele)

Decreases the value or displays the previous choice

During naming, moves the cursor to the left of the

current character in the name

Zoom Out

(Zoom Wide)

PAN / TILT / ZOOM OPTIONS

PROPORTIONAL FLIP OFF

1ST ZOOM STOP X 24

MAX TOTAL ZOOM X 128

EXIT

RESET TO FACTORY SETTINGS

Settings (Defaults in Bold)

Proportional Flip ON / OFF

1st Zoom Stop X 16 / 24

Max Total Zoom X 32 / 48 / 64 / 80 / 96 / 112 / 128

CAMERA / LENS FUNCTIONS

LINE LOCK OFF

AGC MODE ON

AGC GAIN 112

EXIT

RESET TO FACTORY SETTINGS

AUTO WHITE BAL ON

RED WHITE BAL 457

BLUE WHITE BAL 563

Settings (Defaults in Bold)

Line Lock ON / OFF

AGC Mode ON / OFF

AGC Manual Gain: 0 - 1128*

Auto White Bal ON/OFF

Red White Bal 128-1023**

Blue White Bal 128-1023**

* AGC Mode must be OFF to change

** Auto White Bal must be OFF to change

2 8000-2613-02, Rev. B Quick Reference Guide

ALARMS / AREAS / HOME

SET ALARM ACTIONS

CONFIGURE NORMAL STATES

CONFIGURE HOME POSITION

EXIT

PROGRAM AREA BOUNDARIES

PROGRAM PRESETS

Select an item, then press Focus Far to make the changes.

Alarm inputs and outputs are not supported for Manchester.

ON-SCREEN TEXT DISPLAY

STATUS DISPLAY OFF

EXIT

DISABLE ALL NAMES? NO

NAME CONFIGURATION MENU

TEXT ATTRIBUTE OPTIONS

DIAGNOSTICS DISPLAY ON

Settings (Defaults in Bold)

Status Display ON / OFF

Disable All Names? YES / NO

Diagnostic Display ON / OFF

LANGUAGE / PASSWORD

LANGUAGE SELECTION

EXIT

SET PASSWORD

PASSWORD PROTECTION OFF

Press Focus Far to display Language Selection (screen 17) or Set

Password (screen 18).

Settings (Defaults in Bold)

Password Protection ON / OFF

SET ALARM ACTIONS

EXIT

INPUT NO. ACTION

SEND INPUTS TO HOST? YES

NO ACTION

1PRESET 96

2PATTERN 33NO ACTION4

INTERNAL ALARMS

Settings (Defaults in Bold)

Input 1 - 4 Actions NO ACTION / PRESET / PATTERN

Send Inputs to Host? YES / NO

Preset Number 1-96; Pattern Number 1-3

Note: Do not assign input action on both dome and controller.

8000-2613-02, Rev. B 3

CONFIGURE NORMAL STATES

EXIT

INPUT NO. NORMAL STATE

OPEN1OPEN

2CLOSED3OPEN4

Settings (Defaults in Bold)

Input 1 - 4 Normal State OPEN / CLOSED

Note: Do not assign input action on both dome and controller.

CONFIGURE HOME POSITION

EXIT

HOME POSITION PRESET 96

RETURN TIME MINS

Settings (Defaults in Bold)

Return to Home Position NO ACTION / PRESET/ PATTERN

Return Time Mins 1 - 60 (Default is 10 minutes)

Preset Number 1-96; Pattern Number 1-3

PROGRAM AREA BOUNDARIES

ZOOM to mark BOUNDARY

PAN to start of BOUND 3

PAN RIGHT ONLY

FOCUS saves and exits

•Up to 16 areas can be programmed.

•Press Zoom In or Zoom Out to set area boundary

•Press Focus Far when finished setting areas

SELECT PRESET TO PROGRAM

EXIT

PRESET NAME

PRESET

NUMBER

PRESET 9696

FOCUS FAR to program preset

•Use Zoom In or Zoom Out choose the correct preset number.

•Press Focus Far to perform preset programming.

12 PROGRAM PRESET

PRESET 1

EXIT

Position camera with PAN,

TILT, ZOOM, and IRIS

FOCUS FAR to save and exit

This screen appears under two circumstances:

•By selecting a preset number and pressing Focus Far on the Select

Preset To Program screen (see screen 11).

•By selecting a preset that has not been programmed as the Home

Position (see screen 9).

Use Pan, Tilt, Zoom, and Iris controls to set the view for the preset.

Press Focus Far when finished.

Press Focus Far

twice to return to

screen 4.

If Preset is selected and

no preset exists, you will

see screen 12.

11 or 4

4 8000-2613-02, Rev. B Quick Reference Guide

NAME CONFIGURATION MENU

OFF

CAMERA NAME OFFAREA NAME OFFPRESET NAME OFFPATTERN NAME ON

ALARM NAME

FOCUS FAR to program name

EXIT 5

RESET PROGRAMMABLE NAMES

Settings (Defaults in Bold)

Camera Name ON / OFF

Area Name ON / OFF

Preset Name ON / OFF

Pattern Name ON / OFF

Alarm Name ON / OFF

•Use Zoom In or Zoom Out to change setting for highlighted item.

•Press Focus Far to perform name programming for highlighted item.

In this example, Camera Naming would be started.

SELECT NAME TO PROGRAM

EXIT

CURRENT NAME

PATTERN

NUMBER

FOCUS FAR to program names

PATTERN 11

Example Select Name to Program Screen (for Patterns)

•Use Zoom In or Zoom Out choose the correct area, preset, pattern or

alarm number.

•Dome moves to start of specified area, preset, or pattern (if

programmed)

•Press Focus Far to display Name Programming Screen

Available Settings:

Area Number 1-16

Preset Number 1-96

Pattern Number 1-3

Alarm Number: 1-4

NAME PROGRAMMING

PATTERN 1

NAME: PATTERN 1. . . . . . . . . .

EXIT

UNDO CHANGES AND QUIT

A B C D E F G H I J K L M N O P Q R S T

U V W X Y Z a b c d e f g h i j k l m n

o p q r s t u v w x y z 0 1 2 3 4 5 6

7 8 9 / -

Example Name Programming Screen (for Patterns)

•Names can have up to 19 characters

•Use Zoom In to move cursor one space to right in Name

•Use Zoom Out to move cursor one space to left in Name

•Use Pan and Tilt to move highlight around character field

•Press Focus Far to accept highlighted character

•The SPACE character is located between zand 0 (zero)

TEXT ATTRIBUTE OPTIONS

CHARACTER OUTLINE OFF

EXIT

TRANSLUCENT NAMES OFF

Settings (Defaults in Bold)

Character Outline ON / OFF

Translucent Names ON / OFF

13 or 14

Blank

Space

8000-2613-02, Rev. B 5

LANGUAGE SELECTION

ENGLISH

SPANISH

FRENCH

GERMAN

ITALIAN

PORTUGUESE

EXIT

•Default setting is English.

•Characters ãand õare not available in Portuguese.

SET PASSWORD

PASSWORD: * *

CONTINUE

CANCEL 6

A B C D E F G H I J K L M N O P Q R S T

U V W X Y Z a b c d e f g h i j k l m n

o p q r s t u v w x y z 0 1 2 3 4 5 6

7 8 9 / -

•Passwords can be from 1 to 8 characters.

•Asterisks appear when characters are selected.

•Use Zoom In to move cursor one space to right in Password

•Use Zoom Out to move cursor one space to left in Password

•Use Pan and Tilt to move highlight around character field

•Press Focus Far to accept highlighted character

•The SPACE character is located between the zand 0(zero).

•To accept password, move highlight to Continue, then press Focus

Far. Re-enter for Verification appears on screen.

•To cancel password programming, move highlight to Cancel, then

press Focus Far.

•To set or change password, the same password must be entered twice.

After 2nd successful entry, screen 6 appears

•Password Protection must be set to ON for password to be

activated. See screen 6.

ENTER PASSWORD

PASSWORD: * *

CONTINUE

CANCEL

A B C D E F G H I J K L M N O P Q R S T

U V W X Y Z a b c d e f g h i j k l m n

o p q r s t u v w x y z 0 1 2 3 4 5 6

7 8 9 / -

•Passwords can be from 1 to 8 characters.

•Asterisks appear when characters are selected.

•Use Zoom In to move cursor one space to right in Password

•Use Zoom Out to move cursor one space to left in Password

•Use Pan and Tilt to move highlight around character field

•Press Focus Far to accept highlighted character

•The SPACE character is located between the zand 0(zero).

•To accept password, move highlight to Continue, then press Focus

Far. If password is correct, screen 1appears. Otherwise, Enter

Password screen remains.

•To cancel password entry, move highlight to Cancel , then press

Focus Far. The dome resumes normal operating mode.

SELECT CONTINUE TO RESET

CONTINUE

CANCEL

DOME MUST RESET TO

CHANGE LANGUAGE

•Dome must reset for language change to occur. With highlight bar on

Continue, press Focus Far to continue with language change.

•To cancel language change, use the Tilt control to move highlight bar

to Cancel. The Language Selection screen (screen 18) displays.

AD, American Dynamics, DeltaDome, and the AD logo are trademarks

of Sensormatic Electronics Corporation. Other product names (if any)

mentioned herein may be trademarks or registered trademarks of other

companies.

No part of this guide may be reproduced in any form without written

permission from Sensormatic Electronics Corporation.

1 or 19

Blank

Space

Reset Dome

Blank

Space

18 or 6

Autres manuels pour AD615

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels American Dynamics Caméra de sécurité

American Dynamics

American Dynamics AD615 Manuel utilisateur

American Dynamics

American Dynamics Tyco ADC770 Manuel utilisateur

American Dynamics

American Dynamics SpeedDome Ultra VI Instructions d'installation et d'entretien

American Dynamics

American Dynamics SpeedDome Ultra Manuel

American Dynamics

American Dynamics SpeedDome Ultra VII RAS917LS Guide rapide

American Dynamics

American Dynamics ADCSHR2412N Manuel utilisateur

American Dynamics

American Dynamics ADC 660N Manuel utilisateur

American Dynamics

American Dynamics ADCTDN0230P Manuel utilisateur

American Dynamics

American Dynamics Tyco ADC770 Manuel utilisateur

American Dynamics

American Dynamics Illustra 1MP Manuel utilisateur

American Dynamics

American Dynamics SpeedDome Ultra VII Manuel utilisateur

American Dynamics

American Dynamics illustra 400 Manuel utilisateur

American Dynamics

American Dynamics VideoEdge IP Indoor Mini-dome 8200-2646-02... Instructions d'utilisation d'origine

American Dynamics

American Dynamics ADC660 Manuel utilisateur

American Dynamics

American Dynamics ADCA330CN Manuel utilisateur

American Dynamics

American Dynamics SensorRail IIIe ADRL3TRK Series Manuel utilisateur

American Dynamics

American Dynamics IP speedDome Ultra 8 Instructions d'installation et d'entretien

American Dynamics

American Dynamics ADC722WP Manuel utilisateur

American Dynamics

American Dynamics AD715LS Series Manuel du propriétaire

American Dynamics

American Dynamics SpeedDome Optima LT Manuel utilisateur

American Dynamics

American Dynamics ADC780 Instructions de montage

American Dynamics

American Dynamics IP speedDome Ultra 8 Instructions d'installation et d'entretien

American Dynamics

American Dynamics ADC710 Manuel utilisateur

American Dynamics

American Dynamics illustra 600 Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
