AMC iMIX 5 Manuel utilisateur
User
Manual
iMIX 5
Matrix router
Safety instructions
USER MANUAL iMIX 5 Matrix router
When using this electronic device, basic precautions
should always be taken, including the following:
1Read all instructions before using the product.
2Do not use this product near water also do not install WC iMIX controllers
and MIC iMIX call station in the high humidity areas etc. near a bathtub,
wash bowl, kitchen sink, in a wet basement or near a swimming pool.
3 Use this device when you are sure that iMIX5, WC iMIX controllers and MIC
iMIX call station have a stable base and it is fixed securely.
4This product, in combination with amplifier and audio source may be
capable of producing sound levels that could cause permanent hearing
loss. Do not operate for a long period of time at a high volume level or at
a level that is uncomfortable. If you experience any hearing loss or ringing
in the ears, you should consult with otorhinolaryngologists.
5The product should be located away from heat sources such as radiators,
heat vents, or other devices that produce heat.
6The product should be connected to a power supply that is described
in the operating instructions or are marked on the product.
7The power supply should be undamaged and never share an outlet
or extension cord with other devices. Never leave device plugged
into the outlet when it is not being used for a long period of time.
8Care should be taken that objects do not fall into liquids and liquids
would not be spilled on the device.
9The product should be serviced by qualified service personnel if:
– The power supply or the plug has been damaged.
– Objects have fallen into or liquid has been spilled on the product.
– The product has been exposed to rain.
– The product has been dropped or the enclosure damaged.
10 There are some areas with high voltage inside, iMIX 5 to reduce the risk of
electric shock do not remove cover of the microphone receiver or power
supply. The cover should be removed by the qualified personnel only.
CAUTION
To reduce the risk of electric shock, do not remove screws.
No user-serviceable parts inside. Refer servicing to qualied
service personnel. To reduce the risk of re, electric shock
or product damage, do not expose this apparatus to rain,
moisture, dripping or splashing and that no objects lled
with liquids, such as vases, shall be placed on the apparatus.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
x
y
y
x
25
o
Maximum Usage 65mm
Minimum Usage 18mm
Minimum Usage 18mm
y
y
25
x
x
y
Minimum Usage 18mm
Minimum Usage 18mm
Minimum Usage 18mm
Maximum Usage 65mm
Maximum Usage 65mm
25
25
o
x
x
M
M
M
Ma
Mi
M
M
M
M
M
M
y
Max
Min
y
Mi
a
a
axi
ni
n
n
n
n
x
x
xim
nim
i
i
mu
mu
m
m
m
m
m
m
mu
mum
u
u
u
u
u
u
um
um
m
m
m
m
m
m
m U
m U
m
m
m
U
U
U
U
U
U
Us
Us
Us
U
U
sa
sa
a
ag
ag
g
g
g
g
g
ge
ge
g
g
g
g
g
g
ge 6
e 1
e
e
e
65
18
1
6
6
65
18m
8
8
8
8
65
5
5m
8m
8m
5m
m
y
mm
mm
m
y
y
m
m
m
m
m
mm
m
m
m
m
m
m
m
x
Table of contents
USER MANUAL iMIX 5 Matrix router
Before you start
Introduction......................................................................................................................................................2
Features................................................................................................................................................................2
Operation
Front panel ........................................................................................................................................................3
Rear panel...........................................................................................................................................................4
Media player.....................................................................................................................................................5
Front panel operation................................................................................................................................6
Media player operation........................................................................................................................6-7
Rear panel operation..................................................................................................................................7
FM radio receiver...........................................................................................................................................8
Rear panel operation..................................................................................................................................9
Control protocol .........................................................................................................................................10
Feedback protocol....................................................................................................................................11
Controls.............................................................................................................................................................12
WC iMIX wall control................................................................................................................................13
Front/Rear panel operation ................................................................................................................14
MIC iMIX page station.............................................................................................................................15
Front/Rear panel operation ........................................................................................................16-17
Chime.................................................................................................................................................................17
Specifications
General specifications.....................................................................................................................18-19
USER MANUAL iMIX 5 Matrix router
Before you start
iMIX5 is audio router designed to support 5 audio outputs with option to choose one of 4 audio source in
each output individually. It’s stereo device controllable via RS232 interface or wall-mounted touchpads for
main functions control. iMIX5 have integrated USB player with Bluetooth and FM receivers. Priority input for
emergency audio, external mute contact in emergency case.
FEATURES
• Fivestereooutput
• Threelinelevelstereoinputs
• Microphoneinputwithphantompower
• RS232interface
• IntegratedUSB/FM/Bluetoothplayer
• Longdistancesupportingbetweenwall-mounted
touchpads, call station and iMIX5
02
• RJ45connectorsforwall-mountedtouchpads
• Externalmutecontacts
•Priorityinput
•Monitoroutput
•AUXinput
•Statusindicatorforeachoutput
• LocalaudioinputsinWCMIXtouchpads
USER MANUAL iMIX 5 Matrix router
Front Panel
1. Output status indication |2.AUXinput|3. Media player |4. Monitor source selector | 5. Monitor output
Operation
1 2 3 4 5
03
USER MANUAL iMIX 5 Matrix router04
Operation
Rear Panel
1. Connectors for WC iMIX wall control |2. Connector for MIC iMIX page station |3. RS232 serial interface | 4.Externalmute| 5. Priority
audio input |6. Stereo audio outputs |7. Stereo audio inputs |8. Inputs gain control |9. Microphone gain control |10. Phantom power
switch |11. Microphone input |12. Power switch |13. Main power connector
1 2 3 4 5 6 7
8 9
10 11 12 13
USER MANUAL iMIX 5 Matrix router
Operation
Media Player
1.LCDscreen|2. USB slot |3. Mode button | 4. Backward / Set FM frequency and preset | 5. Play-pause / Radio frequency scanning mode
6. Forward / Set FM frequency and preset |7. Repeat button / Save FM preset |8.Mute-powerbutton/Exit
1
2 3 4 5 6 7 8
05
USER MANUAL iMIX 5 Matrix router
Front panel operation
OUTPUT STATUS INDICATOR
Allveaudiooutputshaveaseparateindicationbasedonabi-colorLEDin
ordertodisplayaudiooutputstatus.GreencolorLEDindicatesdetectedaudio
signal.Redcolor-mute.Audiointheoutputismutedinordertoconnectaudio
from the priority input to all iMIX5 outputs. Yellow color indicates call station
activity.
AUX INPUT
Linelevelstereoinputwith3.5mmTRSjackconnector.AUXinputhaveapriority
overUSB,FMandBluetooth.Audiofromlistedmusicsourcestopsatones
media player detects inserted 3.5mm jack connector.
MEDIA PLAYER
Plays audio from Bluetooth devices, USB flash and FM receiver. Device supports
up to 32GB USB flash drives.
MONITOR SOURCE SELECTOR
Allowschooseaudioinmonitoroutputfortestingpurpose.
Media player operation
06
Operation
MONITOR OUTPUT
Balanced audio output designed to check audio in any output.
LCD SCREEN
LCDscreendisplaysmaininformationaboutmediaplayerstatus:tracknumber
and time, media player volume level, music source, FM frequency.
USB FLASH DRIVE
Supportsupto32GBUSBashdrivesformattedinFAT32lesystem,alsosup-
ports compressed audio formats.
MODE
Button switch player between Bluetooth mode, FM mode and Music mode
(USB).
USER MANUAL iMIX 5 Matrix router
Media player operation
BACKWARD
Single short press of this button in music and Bluetooth modes will change
currently playing soundtrack to previously track. Button reduces volume level
of media player after holding this button for a few seconds. Backward button in
FM mode decrease FM frequency by 0.1 MHz steps, also switch radio presets.
PLAY/PAUSE
Switch player mode between play and pause. Hold this button at FM mode in
order to start radio station auto scan. Press this button rapidly in order to toggle
FM frequency auto/manual scanning mode.
FORWARD
Single short press of this button in music and Bluetooth modes will change cur-
rently playing soundtrack to next track. Increase volume level of media player
after holding button for a few seconds. Forward button in FM mode increase FM
frequency by 0.1 MHz steps, also switch radio presets.
REPEAT
There is choice to select one of three modes:
RTA–Repeatalltracks.
RT1 - Repeat one track.
RND – Random play
Second this button function is save FM radio frequency to selected preset.
MUTE AND POWER ON/OFF
Press this button rapidly to mute audio. Hold this button longer in order to
turn off/on media player. FM mode enables second function, it allows exit from
frequency adjusting without saving radio station frequency to preset.
Operation
07
USER MANUAL iMIX 5 Matrix router
FM radio receiver
FM radio receiver allows save up to 26 presets with selected radio stations. FM
control is made with the same buttons like media player. Backward, forward,
play/pause, repeat and power buttons have different functions for media player
and for FM receiver.
BACKWARD
DecreaseFMfrequencyby0.1MHzstepifmanualmodeisselected.Allowsto
select radio preset.
FORWARD
IncreaseFMfrequencyby0.1MHzstepinmanualmode.Allowstoselectradio
preset.
PLAY/PAUSE
Press this button rapidly in order to toggle FM frequency auto/manual scanning
mode.
REPEAT
Designed to save FM radio frequency to selected preset.
MUTE AND POWER ON/OFF
Allowsexitfromfrequencyadjustingwithoutsavingradiostationfrequencyto
preset.
Manual radio frequency setting guide
1. Hold Play/pause button in order enter manual scanning mode.
2. Set frequency by using backward and forward buttons by 0.1 MHz steps.
3. Press repeat button to start save procedure.
4. Select preset number by using backward and forward buttons.
5. Save radio station to selected preset by pressing repeat button. Screen
displays“OK” in order confirm successfully recording to memory.
6. Press Mute button to exit manual frequency scanning.
Please use backward and forward buttons in auto scan mode to switch saved
radio stations.
Operation
MODE
DOWN
HIDDEN FUNCTIONS
EXITSAVEUP
MANUAL/
AUTO SCAN
REPEAT
08
