QUICK START GUIDE
Apollo4 Plus EVB Display Kit
(Shield Board Revision 1)
Ultra-low Power Apollo SoC Family
Doc. ID: QS-A4PDK-1p0
Doc. Revision: 1.0, September 2022
Apollo4 Plus Display Kit Quick Start Guide
QS-A4PDK-1p0 Page 2 2022 Ambiq Micro, Inc.
All rights reserved.
Legal Information and Disclaimers
AMBIQ MICRO INTENDS FOR THE CONTENT CONTAINED IN THE DOCUMENT TO BE ACCURATE AND RELI-
ABLE. THIS CONTENT MAY, HOWEVER, CONTAIN TECHNICAL INACCURACIES, TYPOGRAPHICAL ERRORS
OR OTHER MISTAKES. AMBIQ MICRO MAY MAKE CORRECTIONS OR OTHER CHANGES TO THIS CONTENT
AT ANY TIME. AMBIQ MICRO AND ITS SUPPLIERS RESERVE THE RIGHT TO MAKE CORRECTIONS, MODIFI-
CATIONS, ENHANCEMENTS, IMPROVEMENTS AND OTHER CHANGES TO ITS PRODUCTS, PROGRAMS AND
SERVICES AT ANY TIME OR TO DISCONTINUE ANY PRODUCTS, PROGRAMS, OR SERVICES WITHOUT
NOTICE.
THE CONTENT IN THIS DOCUMENT IS PROVIDED "AS IS". AMBIQ MICRO AND ITS RESPECTIVE SUPPLIERS
MAKE NO REPRESENTATIONS ABOUT THE SUITABILITY OF THIS CONTENT FOR ANY PURPOSE AND DIS-
CLAIM ALL WARRANTIES AND CONDITIONS WITH REGARD TO THIS CONTENT, INCLUDING BUT NOT LIM-
ITED TO, ALL IMPLIED WARRANTIES AND CONDITIONS OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, TITLE AND NON-INFRINGEMENT OF ANY THIRD PARTY INTELLECTUAL PROPERTY RIGHT.
AMBIQ MICRO DOES NOT WARRANT OR REPRESENT THAT ANY LICENSE, EITHER EXPRESS OR IMPLIED, IS
GRANTED UNDER ANY PATENT RIGHT, COPYRIGHT, MASK WORK RIGHT, OR OTHER INTELLECTUAL PROP-
ERTY RIGHT OF AMBIQ MICRO COVERING OR RELATING TO THIS CONTENT OR ANY COMBINATION,
MACHINE, OR PROCESS TO WHICH THIS CONTENT RELATE OR WITH WHICH THIS CONTENT MAY BE USED.
USE OF THE INFORMATION IN THIS DOCUMENT MAY REQUIRE A LICENSE FROM A THIRD PARTY UNDER
THE PATENTS OR OTHER INTELLECTUAL PROPERTY OF THAT THIRD PARTY, OR A LICENSE FROM AMBIQ
MICRO UNDER THE PATENTS OR OTHER INTELLECTUAL PROPERTY OF AMBIQ MICRO.
INFORMATION IN THIS DOCUMENT IS PROVIDED SOLELY TO ENABLE SYSTEM AND SOFTWARE IMPLE-
MENTERS TO USE AMBIQ MICRO PRODUCTS. THERE ARE NO EXPRESS OR IMPLIED COPYRIGHT
LICENSES GRANTED HEREUNDER TO DESIGN OR FABRICATE ANY INTEGRATED CIRCUITS OR INTE-
GRATED CIRCUITS BASED ON THE INFORMATION IN THIS DOCUMENT. AMBIQ MICRO RESERVES THE
RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE TO ANY PRODUCTS HEREIN. AMBIQ MICRO MAKES
NO WARRANTY, REPRESENTATION OR GUARANTEE REGARDING THE SUITABILITY OF ITS PRODUCTS FOR
ANY PARTICULAR PURPOSE, NOR DOES AMBIQ MICRO ASSUME ANY LIABILITY ARISING OUT OF THE
APPLICATION OR USE OF ANY PRODUCT OR CIRCUIT, AND SPECIFICALLY DISCLAIMS ANY AND ALL LIABIL-
ITY, INCLUDING WITHOUT LIMITATION CONSEQUENTIAL OR INCIDENTAL DAMAGES. “TYPICAL” PARAME-
TERS WHICH MAY BE PROVIDED IN AMBIQ MICRO DATA SHEETS AND/OR SPECIFICATIONS CAN AND DO
VARY IN DIFFERENT APPLICATIONS AND ACTUAL PERFORMANCE MAY VARY OVER TIME. ALL OPERATING
PARAMETERS, INCLUDING “TYPICALS” MUST BE VALIDATED FOR EACH CUSTOMER APPLICATION BY CUS-
TOMER’S TECHNICAL EXPERTS. AMBIQ MICRO DOES NOT CONVEY ANY LICENSE UNDER NEITHER ITS PAT-
ENT RIGHTS NOR THE RIGHTS OF OTHERS. AMBIQ MICRO PRODUCTS ARE NOT DESIGNED, INTENDED, OR
AUTHORIZED FOR USE AS COMPONENTS IN SYSTEMS INTENDED FOR SURGICAL IMPLANT INTO THE
BODY, OR OTHER APPLICATIONS INTENDED TO SUPPORT OR SUSTAIN LIFE, OR FOR ANY OTHER APPLICA-
TION IN WHICH THE FAILURE OF THE AMBIQ MICRO PRODUCT COULD CREATE A SITUATION WHERE PER-
SONAL INJURY OR DEATH MAY OCCUR. SHOULD BUYER PURCHASE OR USE AMBIQ MICRO PRODUCTS
FOR ANY SUCH UNINTENDED OR UNAUTHORIZED APPLICATION, BUYER SHALL INDEMNIFY AND HOLD
AMBIQ MICRO AND ITS OFFICERS, EMPLOYEES, SUBSIDIARIES, AFFILIATES, AND DISTRIBUTORS HARM-
LESS AGAINST ALL CLAIMS, COSTS, DAMAGES, AND EXPENSES, AND REASONABLE ATTORNEY FEES ARIS-
ING OUT OF, DIRECTLY OR INDIRECTLY, ANY CLAIM OF PERSONAL INJURY OR DEATH ASSOCIATED WITH
SUCH UNINTENDED OR UNAUTHORIZED USE, EVEN IF SUCH CLAIM ALLEGES THAT AMBIQ MICRO WAS
NEGLIGENT REGARDING THE DESIGN OR MANUFACTURE OF THE PART.
Apollo4 Plus Display Kit Quick Start Guide
QS-A4PDK-1p0 Page 3 2022 Ambiq Micro, Inc.
All rights reserved.
Table of Content
1. Introduction ........................................................................................................... 6
2. Document Revision History ................................................................................... 7
3. Reference Documents and Software .................................................................... 8
4. Quick Start ............................................................................................................ 9
5. Overview of the Apollo4 Display Kit .................................................................... 10
6. Software Development Tools .............................................................................. 14
7. Graphics Development Tools .............................................................................. 15
8. Hardware Configuration Options ......................................................................... 16
9. Ordering Information ........................................................................................... 18
Apollo4 Plus Display Kit Quick Start Guide
QS-A4PDK-1p0 Page 4 2022 Ambiq Micro, Inc.
All rights reserved.
List of Figures
Apollo4 Plus Display Kit .............................................................................................. 6
Apollo4 Plus Display Kit Block Diagram - MSPI0 Hex to PSRAM Only .................... 10
Apollo4 Plus Display Kit Block Diagram - MSPI0/MSPI1 Octal to PSRAM/Flash..... 11
Apollo4 Plus Display Shield Parts Locations ............................................................ 12
PSU page of the Display Shield schematic............................................................... 16
GPIO79 Pin Connection Options .............................................................................. 17
Apollo4 Plus Display Kit Quick Start Guide
QS-A4PDK-1p0 Page 5 2022 Ambiq Micro, Inc.
All rights reserved.
List of Tables
Document Revision History......................................................................................... 7
EVB / Shield Ordering Information............................................................................ 18
MCU Ordering Information........................................................................................ 18
Apollo4 Plus Display Kit Quick Start Guide
QS-A4PDK-1p0 Page 6 2022 Ambiq Micro, Inc.
All rights reserved.
1. Introduction
This document provides guidance in setting up the Display Kit hardware, part number AMAP4PDISP,
revision 1, on the Apollo4 Plus Evaluation Board (EVB), revision 2, to get started executing memory and
display examples and measuring power consumption in various configurations. The Apollo4 Plus Display
Kit is also intended to provide an introduction to the GUI Builder.
Figure 1. Apollo4 Plus Display Kit
Apollo4 Plus Display Kit Quick Start Guide
QS-A4PDK-1p0 Page 7 2022 Ambiq Micro, Inc.
All rights reserved.
2. Document Revision History
Table 1: Document Revision History
Rev # Date Description
1.0 September 2022 Document initial public release
Apollo4 Plus Display Kit Quick Start Guide
QS-A4PDK-1p0 Page 8 2022 Ambiq Micro, Inc.
All rights reserved.
3. Reference Documents and Software
The following items may be useful in understanding and using the EVB.
▪ EVB Schematic
▪ Apollo4 Plus SoC Datasheet
▪ Apollo4 Family Programmer’s Guide
▪ Apollo4 Plus Errata List
▪ AmbiqSuite SDK
Apollo4 Plus Display Kit Quick Start Guide
QS-A4PDK-1p0 Page 9 2022 Ambiq Micro, Inc.
All rights reserved.
4. Quick Start
The Apollo4 Plus Display Kit comes with the following items:
▪ Apollo4 Plus Evaluation Board (EVB), revision 2
▪ Apollo4 Plus Display Shield, revision 1
▪ USB Type C cable
▪ Four adhesive-backed rubber feet
▪ Extra jumpers
Caution: The EVB has components loaded on the back of the board. Care should be taken to not damage
these components. The included rubber feet should be applied to the bottom of the board to prevent direct
contact between the components and a desk surface.
The EVB in the Apollo4 Plus Display Kit comes with jumpers pre-configured for default operation. Also, it
has been pre-programmed with the Binary Counter example program. To begin EVB program execution,
first carefully attach the Apollo4 Plus Display Shield to the Apollo4 Plus EVB if not already attached. To do
this, press the two boards together as evenly as possible until the display shield is fully seated on the
connectors of the EVB. Then connect the USB-C cable from a USB port on a PC to the J-Link USB
connector (J6) on the EVB, and make sure the power switch (SW4) has been turned on. The LEDs on the
bottom of the EVB should begin to count up in binary, from 0 to 7.
The AmbiqSuite SDK provides many example programs that may be run on the Display Kit. To run these
examples, download the SDK via the link provided above and select any of the pre-built examples in the
SDK at /boards/apollo4p_evb_disp_shield_rev2/examples.
Apollo4 Plus Display Kit Quick Start Guide
QS-A4PDK-1p0 Page 10 2022 Ambiq Micro, Inc.
All rights reserved.
5. Overview of the Apollo4 Display Kit
The Apollo4 Plus Display Kit consists of two PCB assemblies:
1. The Apollo4 Plus EVB (AMAP4PEVB), revision 2 or later
2. The Apollo4 Plus Display Shield revision 1
Please note that the Apollo4 Plus Display Kit is only compatible with the (non-blue) Apollo4 Plus EVB, part
number AMAP4PEVB.
The combined features of the two-board assembly are shown in the block diagrams of Figure 2 and
Figure 3. When MSPI0 is used in hex mode (16-bit interface), MSPI1 cannot be used, as the MSPI0 upper
data lines use the same pins on the Apollo4 Plus that MSPI1 uses. An Apollo4 Plus GPIO pin, GPIO34, is
used to select between using this set of pins as MSPI1 connections or as the upper data lines of MSPI0 in
hex mode.
Figure 2 represents the two-board assembly’s feature set when connected to the APS256XXN PSRAM
device over MSPI0 in hex mode. MSPI1 is not used in this configuration.
Figure 2. Apollo4 Plus Display Kit Block Diagram - MSPI0 Hex to PSRAM Only
Apollo4
Plus
EVB
APS256XXN
PSRAM
THGBMNG5D1LBAIT
e-MMC
ADXL362
Accel
454*454
AMOLED
Display
EVB Headers
Hex-MSPI0
MIPI DSI
Quad-MSPI2
I2C
Touch
ALS
SDIF
SPI
J-Link
Debugger
USB
User LEDs
Power
Headers
Audio Jack
Debug
In/Out
Connectors
MCU USB
Connector
Apollo4
Plus
Display
Shield
MSPI1
not used
