Models Covered By This Guide

This Quick Install Guide includes information on the following models:

■AT-9812T V2

■AT-9816GB V2

Package Contents

The following items are included with each AT-9800 Series switch. Contact

your sales representative if any items are damaged or missing.

■One AT-9800 Series switch

■One AC power cord (for AC models)

■One serial cable for connecting the switch to a terminal or PC

■One 19 inch rack-mount kit

■One AT-9800 Series Switch Quick Install Guide

■One AT-9800 Series Safety and Statutory Information booklet

■One AT-9800 Series Switch Documentation and Tools CD-ROM (which

includes the complete AT-9800 Series document set and utilities)

■One warranty card

Selecting a Site

The switch can be installed in a standard 19-inch rack or on a level surface such

as a desktop or bench. When installing the switch, choose a site that:

■allows adequate airflow around the switch and its vents.

■is free of dust and moisture.

■will maintain an ambient temperature range of 0–40º C (32–104º F) and a

humidity range of 5–95% non-condensing.

■has a reliable and earthed (grounded) power supply circuit, preferably

dedicated and filtered.

■does not expose cabling to sources of electrical noise, such as radio

transmitters, broadband amplifiers, power lines, electric motors, and

fluorescent fixtures.

■allows easy access to the switch’s power and cable connections.

■will allow all related network devices to be connected to the switch

without exceeding maximum cable length limitations. See the AT-9800

Series Switch Hardware Reference for cable length specifications.

4AT-9800 Series Switch

C613-04038-01 REV H

Installing the Switch

This equipment must be earthed.

Follow these steps to install the switch:

1. Read the safety information

For safety information, see the AT-9800 Series Safety and Statutory

Information booklet. A copy of this booklet is supplied with each switch,

and can also be found on the Documentation and Tools CD-ROM or at

www.alliedtelesis.com/support/software.

2. Gather the tools and equipment you will need

If installing a DC version of the switch, you will need a DC power source,

DC supply cable, and ring connectors (see Step 8).

If the switch is to be connected to a redundant power supply, you will need

a redundant power supply unit and cable (see Step 10).

3. Choose a suitable site for the switch

Either a flat surface or 19-inch rack.

4. Unpack the switch

Verify the package contents. If any items are damaged or missing, contact

your sales representative.

5. Install CAM (Optional)

If you purchased a Content Addressable Memory (CAM) module, install it

now by following the instructions in the CAM Quick Install Guide.

The CAM Quick Install Guide can be found on the AT-9800 Series Switch

Documentation and Tools CD-ROM, or can be downloaded from

www.alliedtelesis.com/support/software.

6. Place the switch in its operating location

If installing the switch in a rack:

• Remove the rubber feet

• Attach the rack-mounting brackets

• Mount the switch in the rack

7. Apply AC power to the switch (for AC models)

Plug the power cord into the AC power connector on the rear panel of the

switch (Figure 1 on page 5). The Fault LED should flash for approximately

10 seconds as the switch runs internal tests.

If the LED continues to flash or remains lit, refer to the AT-9800 Series

Switch Hardware Reference for troubleshooting information.

Quick Install Guide 5

C613-04038-01 REV H

Figure 1: AT-9816GB front panel and rear panel with AC power inlet

8. Apply DC power to the switch (for DC models)

Read the AT-9800 Series Safety and Statutory Information booklet before

connecting a DC power supply. A copy of this booklet is included with

each switch. It is also included on the Documentation and Tools CD-ROM,

or can be downloaded from www.alliedtelesis.com/support/software.

Only trained and qualified personnel should connect a DC power supply. Due

to exposed terminals, DC powered switches should only be installed in

Restricted Access Areas.

DC supply cable specifications (one cable is required for each PSU):

• Number of wires (cores): 3

• Minimum size: 2.1mm2(14 AWG)

• Minimum cable rating: 600V, 90 degrees Celsius

DC power supply specifications:

• 48V DC (40–60 VDC is acceptable)

• Either positive grounded or negative grounded

Circuit protection:

• Use a 10 Amp circuit breaker

Ensure the supply cable is not live.

a) Strip the supply cable wires to expose 8mm (0.31in) of bare conductor

b) At the switch, connect the ground wire to the ground terminal. The

terminals can be identified by the diagram on the rear panel of the

switch. Tighten the terminal to between 0.6 and 0.8Nm (0.041 to 0.055

pound force per foot).

c) At the switch, connect the positive feed to the + (positive) terminal and

the negative feed to the - (negative) terminal. Tighten the terminal to

between 0.6 and 0.8Nm (0.041 to 0.055 pound force per foot).

CLASS 1

LASER

AC INPUT

100-240V

50/60

AMPS

5.0/2.5

RPS INPUT VDC A Max

0.5

+3.3

+12

COMPACT FLASH

ACTIVITY

AC Power AT-RPS9000 RPS Connector Compact FLASH

STATUS

RESET

FAULT

PWR

RPS

12345678

910111213141516

RS-232

TERMINAL PORT

L/A

GBIC

L/A

GBIC

ASYN0

1000BASE-X GBIC

PORT ACTIVITY

L/A

LINK / FULL DUP ACTIVITY

LINK / HALF DUP ACTIVITY

L/A

ENABLED DISABLED FAULT

GBIC

L/A

GBIC

AT-9816GB V2 Layer 3 Fast Ethernet Switch

6AT-9800 Series Switch

C613-04038-01 REV H

d) Ensure that there are no exposed conductor strands.

e) Secure the supply cable to the rack framework or similar object so that

the connections are isolated from any forces applied to the cable.

f) Ensure that the circuit breaker is in the OFF position.

g) Connect the supply cable wires to the circuit breaker.

h) Energise the circuit breaker.

The Fault LED should flash for approximately 10 seconds as the switch runs

internal tests. If the LED continues to flash or remains lit, refer to the AT-9800

Series Switch Hardware Reference for troubleshooting information.

9. Check that the Power LED on the switch’s front panel lights green

If the LED fails to light, refer to the AT-9800 Series Switch Hardware Reference

for troubleshooting information.

10. Connect the Redundant Power Supply (Optional)

AC models of AT-9800 Series switches have a Redundant Power Supply

(RPS) connector on their rear panel, and can be used with an AT-RPS9000

Redundant Power Supply. The AT-RPS9000 must be purchased separately.

Contact your authorised Allied Telesis distributor or reseller for more

information.

11. Install GBICs

Any combination of copper and fibre GBICs can be installed in AT-9812T

and AT-9816GB switches. Slide the GBICs into the GBIC slots. Press each

GBIC firmly into place.

A range of GBICs have been tested and approved for use with AT-9800 Series switches.

For more information, contact your authorised Allied Telesis distributor or reseller, or

visit www.alliedtelesis.com.

RX and TX terminal locations on SC fibre GBIC ports are the reverse of RX and TX

terminal locations on fixed SC fibre ports. When looking at an SC fibre GBIC from the

front, the RX terminal is on the left and the TX terminal is on the right.

12. Connect the data cables

Make sure each cable connection is secure. The switch will now perform

basic Layer 2 switching functions.

Quick Install Guide 7

C613-04038-01 REV H

Configuring the Switch

Some configuration is necessary to enable the advanced switching capabilities

of the switch. The switch can be configured via the Command Line Interface

(CLI) or Graphical User Interface (GUI).

Using the CLI to configure a switch

1. Connect a terminal or PC to RS-232 (ASYN0)

Using the supplied RS-232 DB9 straight-through cable, connect your

terminal or PC to the RS-232 Terminal Port on the switch’s front panel.

2. Set the communication parameters

Set the communication parameters on your terminal or terminal emulation

program to:

• Baud rate: 9600

• Data bits: 8

•Parity:None

• Stop bits: 1

• Flow control: Hardware

3. Check the power supply

Ensure that the On/Off switch (AC models) or Run/Standby switch (DC

models) is in the On or Run position and that the switch is receiving power

(Power LED lights green).

4. Log in

After the switch has booted, the log in prompt appears. If the log in prompt

doesn’t appear, press [Enter] two or three times.

When the switch boots for the first time it automatically creates an account

with manager privileges. The account has the log in name “manager” and

the password is “friend”.

At the log in prompt, enter the log in name and password.

Password: friend

The command prompt appears and you can now configure the switch

using the command line interface.

Change the password as soon as possible. Leaving the manager account with

the default password is a serious security risk. Make sure you remember the

new password as there is no way to retrieve it if it is lost.

Use the following command to change the account password:

set password

To display a list of help topics, enter:

help

To display help on a specific topic, enter:

help topic

8AT-9800 Series Switch

C613-04038-01 REV H

Alternatively, type a question mark (?) at the end of a partially completed

command to see a list of valid options.

See the AT-9800 Series Switch AlliedWare™ Operating System Software

Reference for more information on configuring the switch.

Using the GUI to configure a switch

This section describes how to establish a connection to the switch through the

GUI, so you can configure the switch before installing it in your LAN.

1. Select a PC to browse to the switch from

You can browse to the switch from any PC that is running a supported

operating system with a supported browser installed, with JavaScript

enabled. If you are using a toolbar or plug-in on your browser to block

pop-ups, disable it while using the GUI. The GUI displays detailed

configuration options and information in pop-up windows.

You need to know the PC’s subnet.

2. Connect the PC to the switch

Use an Ethernet cable to connect an Ethernet card on the PC to any one of

the switch ports.

You can browse to the router through any VLAN, as long as you give that VLAN an IP

address. These instructions assume you will use vlan1. The switch ports all belong to

vlan1 by default.

3. Access the switch’s command line interface

Access the CLI from the PC, as described in the previous “Using the CLI to

configure a switch” section.

4. Enable IP

enable ip

5. Assign the vlan1 interface an IP address in the same subnet as the PC

add ip interface=vlan1 ip=ipaddress mask=mask

6. Save the configuration and set the switch to use it on bootup

create config=your-name.cfg

set config=your-name.cfg

7. On the PC’s web browser, bypass the HTTP proxy server, if necessary

8. Point your web browser at vlan1’s IP address

9. At the login prompt, enter the user name and password

The default username is manager:

User Name: manager

Password: friend

The System Status page is displayed. Select options from the sidebar menu

to configure and manage the switch.

For context-sensitive online help, click on the Help button at the top of the

sidebar menu or on any pop-up page.

Quick Install Guide 9

C613-04038-01 REV H

System LEDs

The following LEDs report operations and faults on AT-9800 Series switches

(Table 1 ).

The AT-9800 Series Switch Hardware Reference has further troubleshooting

information, including information on switch port LEDs.

Table 1: System LEDs on AT-9800 Series switches

LED State Function

PWR

(Power)

Green The switch is receiving power

Fault Red The switch or management software is malfunctioning

1 Flash A switch fan has failed or is operating below the

recommended speed

2 Flashes If RPS monitoring is enabled, an RPS fan has failed or is

operating below the recommended speed

3 Flashes If an RPS is connected, the switch’s PSU (Power Supply

Unit) has failed

4 Flashes If RPS monitoring is enabled, the RPS PSU has failed

5 Flashes If RPS monitoring is enabled, an RPS is not connected or

is not operational

6 Flashes The switch’s temperature has exceeded the

recommended threshold

RPS (Redundant

Power Supply)

Green An RPS is connected to the switch and is receiving

power

CompactFlash

Activity

(Rear panel)

Green The compact flash memory is active. Do not eject the

flash memory module

10 AT-9800 Series Switch

C613-04038-01 REV H

Documentation and Tools CD-ROM

The Documentation and Tools CD-ROM bundled with each switch contains the

complete Documentation Set for AT-9800 Series switches and their expansion

options, as well as tools for managing the Switch. The CD-ROM includes:

■The AT-9800 Series Statutory and Safety Information booklet, which provides

safety and statutory information for the Switch and its expansion options.

■The AT-RPS9000 Statutory and Safety Information booklet, which includes

important safety information and statutory declarations for the

AT-RPS9000 chassis and AT-PWR9000 power unit.

■The AT-9800 Series Switch Hardware Reference, which provides detailed

information on the hardware features of AT-9800 Series switches.

■This Quick Install Guide.

■The AT-RPS9000 & AT-PWR9000 Quick Install Guide, which outlines the

procedure for installing AT-RPS9000 chassis and AT-PWR9000 power

units.

■The AT-9800 Series Switch AlliedWare™ Operating System Software Reference,

which provides detailed information on configuring the switch and its

software.

■The CAM Quick Install Guide, which outlines the procedure for installing

Content Addressable Memory.

■AT-TFTP Server for Windows, for downloading software releases.

■Adobe Acrobat Reader, for viewing online documentation.

Autres manuels pour AT-9812T V2

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Allied Telesis Changer

Allied Telesis

Allied Telesis AT-9448Ts Manuel utilisateur

Allied Telesis

Allied Telesis 8100L Series Manuel utilisateur

Allied Telesis

Allied Telesis AT FH812U AT-FH812U AT-FH812U Manuel utilisateur

Allied Telesis

Allied Telesis x530DP Series Manuel utilisateur

Allied Telesis

Allied Telesis AT-GS900/16 Manuel utilisateur

Allied Telesis

Allied Telesis AT-9000/28 Manuel utilisateur

Allied Telesis

Allied Telesis AT-9724TS Manuel utilisateur

Allied Telesis

Allied Telesis AlliedWare Plus x530DP Series Manuel utilisateur

Allied Telesis

Allied Telesis AT-8000S/48 Manuel utilisateur

Allied Telesis

Allied Telesis AT-x230-10GP Manuel utilisateur

Allied Telesis

Allied Telesis AT-FSW724 Manuel utilisateur

Allied Telesis

Allied Telesis x900-12X Series Manuel utilisateur

Allied Telesis

Allied Telesis AT-9448T/SP AC Manuel utilisateur

Allied Telesis

Allied Telesis AT-8600 Series Guide d'application

Allied Telesis

Allied Telesis AT-DC2552XS Manuel utilisateur

Allied Telesis

Allied Telesis Rapier Switch Manuel utilisateur

Allied Telesis

Allied Telesis AT-FS909M Manuel utilisateur

Allied Telesis

Allied Telesis Switchblade AT-x900-12 Manuel utilisateur

Allied Telesis

Allied Telesis AT-FS201 Series Manuel utilisateur

Allied Telesis

Allied Telesis AT-GS950/24 Manuel utilisateur

Allied Telesis

Allied Telesis AT-8624T/2M, AT-8624PoE Manuel utilisateur

Allied Telesis

Allied Telesis AT-FS238 Series Manuel utilisateur

Allied Telesis

Allied Telesis AT-8000S/24POE Manuel utilisateur

Allied Telesis

Allied Telesis AT-x930-28GTX Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
