Alliance Laundry Systems 802734R6 Mode d’emploi

Installation/Operation

www.comlaundry.com

Frontload Washers

Metered Commercial

FLW1526C

Part No. 802734R6

September 2012

Keep These Instructions for Future Reference.

(If this machine changes ownership, this manual must accompany machine.)

Para bajar una copia de estas instrucciones

en español, visite www.comlaundry.com.

802734 1

NOTE: The WARNING and IMPORTANT instructions appearing in this manual are not meant to cover all

possible conditions and situations that may occur. It must be understood that common sense, caution, and

carefulness are factors which cannot be built into these washers. These factors MUST BE supplied by the

person(s) installing, maintaining, or operating the washer.

Always contact the distributor, service agent, or the manufacturer about any problems or conditions you do not

understand.

Failure to install, maintain, and/or operate this machine according to the manufacturer's

instructions may result in conditions which can produce bodily injury and/or property

damage.

W030

WARNING

means without the expressed written consent of the publisher.

802734

2© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Table of

Contents

Safety Information.............................................................................. 4

Explanation of Safety Messages........................................................... 4

Important Safety Instructions ............................................................... 4

Installation........................................................................................... 6

Dimensions and Specifications............................................................. 6

Before You Start ................................................................................... 7

Tools ................................................................................................ 7

Installing the Washer ............................................................................ 8

Step 1: Position Washer Near Installation Area .............................. 8

Step 2: Position and Level the Washer ............................................ 8

Step 3: Connect Fill Hoses............................................................... 9

Step 4: (Non-Gravity Drain Models Only)

Connect Drain Hose to Drain Receptacle....................................... 11

Step 5: (Gravity Drain Models Only)

Connect Drain Outlet to Drain System........................................... 12

Step 6: Remove the Shock Sleeves and Shipping Brace ................. 13

Step 7: Wipe Out Inside of Wash Drum .......................................... 14

Step 8: Plug In the Washer............................................................... 14

Step 9: Check Installation ................................................................ 15

Vending................................................................................................. 16

Meter Case ....................................................................................... 16

Slide Extension Assembly – Models through Serial No. 1211........ 16

Slide Extension Assembly – Models Starting Serial No. 1211 ....... 17

Models Prepped for Card Reader..................................................... 19

Operation............................................................................................. 20

Operation Instructions for Coin Slide Operated Washers .................... 20

Step 1: Load Laundry....................................................................... 20

Step 2: Close Loading Door............................................................. 20

Step 3: Add Laundry Supplies ......................................................... 21

Step 4: Set Fabric Selector............................................................... 21

Step 5: Set WASH/RINSE Temperatures........................................ 21

Step 6: Insert Money........................................................................ 21

Indicator Lights................................................................................ 22

Rapid Advance................................................................................. 22

Operation Instructions for MDC Washers............................................ 23

Step 1: Load Laundry....................................................................... 23

Step 2: Close Loading Door............................................................. 23

Step 3: Add Laundry Supplies ......................................................... 24

Step 4: Set Fabric Selector and Wash Temperature......................... 24

Step 5: Insert Coin(s) or Card .......................................................... 25

Step 6: Start Washer......................................................................... 25

Indicator Lights................................................................................ 26

Operation Instructions for NetMaster Washers .................................... 27

Step 1: Load Laundry....................................................................... 27

Step 2: Close Loading Door............................................................. 27

Step 3: Add Laundry Supplies ......................................................... 27

Step 4: Set Fabric Selector............................................................... 28

Step 5: Set Wash Temperature......................................................... 28

802734 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Step 6: Insert Coin(s) or Card .......................................................... 28

Step 7: Start Washer......................................................................... 29

Indicator Lights................................................................................ 29

Maintenance ........................................................................................ 30

User-Maintenance Instructions............................................................. 30

Lubrication....................................................................................... 30

Cold Weather Care........................................................................... 30

Care of Your Washer ....................................................................... 30

Cleaning Glass Sealing Area ........................................................... 30

Replacing Hoses............................................................................... 30

Filter Screens ................................................................................... 30

Vacations and Extended Non-Use ................................................... 30

Reinstallation of Shipping Materials ............................................... 31

Cleaning Foreign Object Trap ......................................................... 31

Troubleshooting .................................................................................. 32

Contact Information........................................................................... 34

Installer Checklist................................................................ Back Cover

Safety Information

Explanation of Safety Messages

Throughout this manual and on machine decals, you

will find precautionary statements (“DANGER,”

“WARNING,” and “CAUTION”) followed by specific

instructions. These precautions are intended for the

personal safety of the operator, user, servicer, and

those maintaining the machine.

Additional precautionary statements (“IMPORTANT”

and “NOTE”) are followed by specific instructions.

IMPORTANT: The word “IMPORTANT” is used

to inform the reader of specific procedures where

minor machine damage will occur if the procedure

is not followed.

NOTE: The word “NOTE” is used to communicate

installation, operation, maintenance or servicing

information that is important but not hazard

related.

Important Safety Instructions

(Save These Instructions)

1. Read all instructions before using the washer.

2. Install the washer according to the

INSTALLATION INSTRUCTIONS. Refer to the

GROUNDING INSTRUCTIONS in the

INSTALLATION manual for the proper

grounding of the washer. All connections for

water, drain, electrical power and grounding must

comply with local codes and be made by licensed

personnel when required. Do not do it yourself

unless you know how!

3. Do not install or store the washer where it will be

exposed to water and/or weather.

4. Do not add the following substances or textiles

containing traces of the following substances to

the wash water: gasoline, kerosene, waxes,

cooking oils, vegetable oils, machine oils, dry-

cleaning solvents, flammable chemicals, thinners

or other flammable or explosive substances.

These substances give off vapors that could

ignite, explode or cause the fabric to catch on fire

by itself.

5. Under certain conditions, hydrogen gas may be

produced in a hot water system that has not been

used for two weeks or more. HYDROGEN GAS

IS EXPLOSIVE. If the hot water system has not

been used for such a period, before using a

washing machine or combination washer-dryer,

turn on all hot water faucets and let the water

flow from each for several minutes. This will

release any accumulated hydrogen gas. THE

GAS IS FLAMMABLE, DO NOT SMOKE OR

USE AN OPEN FLAME DURING THIS TIME.

6. To reduce the risk of an electric shock or fire, DO

NOT use an extension cord or an adapter to

connect the washer to the electrical power

source.

Indicates an imminently hazardous

situation that, if not avoided, will cause

severe personal injury or death.

DANGER

Indicates a hazardous situation that, if not

avoided, could cause severe personal

injury or death.

WARNING

Indicates a hazardous situation that, if not

avoided, may cause minor or moderate

personal injury or property damage.

CAUTION

To reduce the risk of fire, electric shock,

serious injury or death to persons when

using your washer, follow these basic

precautions:

W023

WARNING

Safety Information

802734

7. Do not allow children to play on or in the washer.

Close supervision of children is necessary when

the washer is used near children. This appliance

is not intended for use by persons (including

children) with reduced physical, sensory or

mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning the use of

the appliance by a person responsible for their

safety. This is a safety rule for all appliances.

8. Do not reach into the washer if the washtub is

moving.

9. Never operate the washer with any guards, panels

and/or parts removed or broken. DO NOT tamper

with the controls or bypass any safety devices.

10. DO NOT operate individual units if they have

been separated from a stack unit.

11. Use your washer only for its intended purpose,

washing clothes. Always follow the fabric care

instructions supplied by the garment

manufacturer.

12. Always read and follow manufacturer’s

instructions on packages of laundry and cleaning

aids. To reduce the risk of poisoning or chemical

burns, keep them out of the reach of children at

all times (preferably in a locked cabinet). Heed

all warnings or precautions.

13. Do not use fabric softeners or products to

eliminate static unless recommended by the

manufacturer of the fabric softener or product.

14. Loading door MUST BE CLOSED any time the

washer is to fill, tumble or spin. DO NOT bypass

the loading door switch by permitting the washer

to operate with the loading door open.

15. Be sure water connections have a shut-off valve

and that fill hose connections are tight. CLOSE

the shut-off valves at the end of each wash day.

16. Keep your washer in good condition. Bumping or

dropping the washer can damage safety features.

If this occurs, have your washer checked by a

qualified service person.

17. Do not repair or replace any part of the washer, or

attempt any servicing unless specifically

recommended in the user-maintenance

instructions or in published user-repair

instructions that you understand and have the

skills to carry out. ALWAYS disconnect the

washer from electrical supply before attempting

any service.

18. Disconnect the power cord by grasping the plug,

not the cord. If the supply cord is damaged, it

must be replaced by a special cord or assembly

available from the manufacturer or its service

agent.

19. Before the washer is removed from service or

discarded, remove the lid or door to the washing

compartment.

20. Failure to install, maintain, and/or operate this

washer according to the manufacturer’s

instructions may result in conditions which can

produce bodily injury and/or property damage.

NOTE: The WARNING and IMPORTANT

SAFETY INSTRUCTIONS appearing in this

manual are not meant to cover all possible

conditions and situations that may occur. Common

sense, caution and care must be exercised when

installing, maintaining, or operating the washer.

Always contact your dealer, distributor, service agent

or the manufacturer about any problems or conditions

you do not understand.

Installation

Dimensions and Specifications

FLW2201N

Standard Capacity Meter Case

43 in. (109.2 cm)

High Capacity Meter Case

43.875 in. (111.44 cm)

28 in. (71.1 cm)

24 in.

(61.0 cm)

26.875 in. (68.3 cm)

13.1 in.

(33.3 cm)

31.1 in. (79 cm)

2 in.

(5.1 cm)

36 in. (91.44 cm)

14.6 in.

(37.08 cm)

MODELS EQUIPPED WITH DRAIN HOSE

Coin Slide Models 40.19 in. (102.08 cm)

Electronic Control Models 38.19 in. (97 cm)

Coin Slide Models

21.56 in. (54.76 cm)

Electronic Control Models

22.06 in. (56.03 cm)

29.6 in. (75.1 cm)

1.5 in.

(3.8 cm)

FLW2202N

11.5 in. (3.81 cm) Inside Diameter

1.86 in. (4.72 cm) Outside Diameter

28 in. (71.1 cm)

24 in.

(61.0 cm)

26.875 in. (68.3 cm)

13.1 in.

(33.3 cm)

31.1 in. (79 cm)

4.1 in.

(10.41cm)

36 in. (91.44 cm)

14.6 in.

(37.08 cm)

MODELS WITH GRAVITY DRAIN

Coin Slide Models 40.19 in. (102.08 cm)

Electronic Control Models 38.19 in. (97 cm)

Coin Slide Models

21.56 in. (54.76 cm)

Electronic Control Models

22.06 in. (56.03 cm)

29.6 in. (75.1 cm)

4.2 in.

(10.67cm)

1.5 in.

(3.8 cm)

Standard Capacity Meter Case 43 in. (109.2 cm)

High Capacity Meter Case 43.875 in. (111.44 cm)

Installation

802734

Before You Start

Tools

For most installations, the basic tools you will need

are:

Figure 1

NOTE: If the washer is delivered on a cold day

(below freezing), or is stored in an unheated room

or area during the cold months, do not attempt to

operate it until the washer has had a chance to

warm up.

NOTE: Install dryer before washer. This allows

room for attaching exhaust duct.

NOTE: Some moisture in the wash drum is normal.

Water is used during testing at the manufacturer.

D074I

1Wrench

2Screwdriver

3Pliers

4Socket Wrench

5Level

123

Installation

802734

Installing the Washer

Step 1: Position Washer Near Installation

Area

Move washer so that it is within 4 feet (1.2 meters) of

the desired area of installation.

NOTE: For best performance and to minimize

vibration or movement, install washer on a solid,

sturdy and level floor. Some floors may need to be

reinforced, especially on a second floor or over a

basement. Do not install the washer on carpeting,

soft tile, a platform or other weakly supported

structures.

Figure 2

Step 2: Position and Level the Washer

Position washer so it has sufficient clearance for

installation and servicing.

NOTE: Use of the dispenser drawer or washer door

as a handle in the transportation of the washer may

cause damage to the dispenser or door.

Place washer in position on a solid, sturdy and level

floor. Installing the washer on any type of carpeting,

soft tile, a platform or other weakly supported

structures is not recommended.

Place a level on the cabinet top and check if the

washer is level from side to side and front to back.

NOTE: Level must rest on raised portion of top

panel. Refer to Figure 3.

If washer is not level, tilt washer to access the front

and rear leveling legs. For easier access to leveling

legs, prop up washer with a wooden block. Refer to

Figure 3. Loosen 7/8 in. locknut and adjust legs until

the washer is level from side to side and front to back

(using a level). Washer should not rock.

Tighten the locknuts securely against the washer

base using the 7/8 in. wrench. If the locknuts are not

tight, washer will move out of position during

operation.

H135I

Washers elevated above floor level must

be anchored to that elevated surface,

base or platform. The material used to

elevate the washer should also be

anchored to the floor to ensure that the

washer will not walk or that the washer

can not be physically pulled, tipped or

slid from its installed position. Failure to

do so may result in conditions which can

produce serious injury, death and/or

property damage.

W306

WARNING
