Allen MSP450A Guide d'application

OPERATIONS-PARTS

MANUAL

061090 - 12/2013

Riding Trowel

ALSO INCLUDES 450C

05/2016

061090 - 12/2013

This manual, or a copy of it, must be kept with the machine at all times.

There is a manual storage container located on the machine for your convenience.

061090 - 12/2013

Riding Trowel

OPERATIONS - PARTS MANUAL

Page i

This manual covers the products listed below:

Part No. Description

060800 RIDER MSP450

065150 RIDER MSP450C

All information, speciﬁcations, and illustrations in this manual are subject to change without notice and

are based on the latest information at the time of publication. No part of this manual may be reproduced

or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the

express written permission of Allen Engineering Corporation (AEC). AEC assumes no responsibility or

liability for any errors or inaccuracies that may appear in this manual.

Allen Products are covered under one or more of the following patent numbers:

U.S. Design Patents: 344,736; 400,542; 400,544; 402,998; 402,999; 403,332; 404,041; 404,042;

410,931; 413,127; 416,564; 465,897; 466,909; 474,203.

U.S. Utility Patents: 5,108,220; 5,238,323; 5,328,295; 5,352,063; 5,405,216; 5,476,342; 5,480,257;

5,480,258; 5,533,831; 5,562,361; 5,567,075; 5,613,801; 5,658,089; 5,685,667; 5,803,658; 5,816,739;

5,816,740; 5,890,833; 5,934,823; 5,967,696; 5,988,938; 5,988,939; 6,019,433; 6,019,545; 6,048,130;

6,053,660; 6,089,786; 6,106,193; 6,857,815; 5,288,166; 6,582,153 B1, 7,108,449; 7,114,876;

7,316,523; 7,690,864 B2

Canadian Patents: 2,039,893.

NOTE: This machine (MSP450) is classiﬁed as “Patent Pending”.

First Issue: December 2013 (Amended October 2014: Gen 2)

(Amended May 2016: Gen 3 - 450C)

AEC Manual Part No.: 061090

Printed in U.S.A.

061090 - 12/2013

Page ii

Limited Warranty

Allen Engineering Corporation (“Allen”) warrants its products to be free of defects in material or workmanship for:

TWO YEARS FROM END USER’S DATE OF PURCHASE

Warranty period begins on the date of purchase by the End User of the product. All warranty is based on the following limited

warranty terms and conditions, including the disclaimer of implied warranties and consequential damages.

1. Allen’s obligation and liability under this warranty is limited to repairing or replacing parts if, after Allen’s inspection, there is

determined to be a defect in material or workmanship. Allen reserves the choice to repair or replace.

2. If Allen chooses to replace the part, it will be at no cost to the customer and will be made available to the Allen Distributor,

Dealer, or Rental Center from whom the End User purchased the product.

3. Replacement or repair parts, installed in the product, are warranted only for the remainder of warranty period of the product

as though they were the original parts.

4. Allen does not warranty engines or batteries. Engine warranty claims should be made directly to an authorized factory

service center for the particular engine manufacturer. Batteries are not warranted due to unknown treatment during transport,

etc, and any battery claims should be directed to the battery manufacturer.

5. Allen’s warranty does not cover the normal maintenance of products or its components (such as engine tuneups and oil &

ﬁlter changes). The warranty also does not cover normal wear and tear items (such as belts and consumables).

6. Allen’s warranty will be void if it is determined that the defect resulted from operator abuse, failure to perform normal main-

tenance on the product, modiﬁcation to product, alterations or repairs made to the product without the written approval of

Allen. Allen speciﬁcally excludes from warranty any damage to any trowels resulting from an impact to the rotors.

7. Impact damage to gear boxes is not covered under the Allen warranty and is deemed customer abuse.

8. Allen will pay shop labor on warranty items at the Allen Shop Labor Rate in existence on the date of the warranty claim. An

Allen labor chart will determine the time allowed to complete a repair and will govern the shop labor hours that will be allowed.

9. Allen will pay freight on warranty replacement parts at worldwide standard ground rates. No warranty replacement parts will

be shipped air freight at the expense of Allen. Allen only pays outbound freight charges when sending warranty replacement

parts to the customer via ground service. Allen does not pay any inbound freight. However, if Allen determines this to be a

warranted item, only then will Allen reimburse the customer for inbound freight at standard ground rates.

10. ALLEN ENGINEERING CORPORATION’S WARRANTY POLICY WILL NOT COVER THE FOLLOWING: TAXES;

SHOP SUPPLIES; ENVIRONMENTAL SURCHARGES; AIR FREIGHT; TRAVEL TIME; LOSS OF TIME; INCONVENIENCE;

LOSS OF RENTAL REVENUE; RENTAL COSTS OF EQUIPMENT USED TO REPLACE THE PRODUCT BEING REPAIRED;

LOSS OF USE OF THE PRODUCT; COMMERCIAL LOSS; OR ANY OTHER CHARGES WHATSOEVER OR ANY LIABILI-

TIES FOR DIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGE OR DELAY.

11. ALLEN ENGINEERING CORPORATION MAKES NO OTHER WARRANTY, EXPRESSED OR IMPLIED. THIS LIMITED

WARRANTY IS IN LIEU OF THE WARRANTY OF MERCHANTABILITY AND FITNESS. THERE ARE NO OTHER WARRAN-

TIES THAT EXTEND BEYOND THE DESCRIPTION ON THIS DOCUMENT.

12. No Allen employee or representative is authorized to change this warranty in any way or grant any other warranty

unless such change is made in writing and signed by an ofﬁcer of Allen Engineering Corporation.

061090 - 12/2013 Page iii

Table of Contents

Title Page

Limited Warranty ii

Table of Contents iii

Information Contained In This Manual v

Dealer Information vi

Ordering Parts vii

Model Number - Serial Number Codes viii

Unit Identiﬁcation ix

Technical speciﬁcations x

Engine Speciﬁcations xi

Machine Dimensional Speciﬁcations xii

Section 1 - Safety 1-1

State Regulations 1-2

Federal Regulations 1-3

Safety Information 1-4

Safety Symbols 1-5

General Safety 1-6

Safety Labels and Decals 1-11

Transportation Safety 1-15

Section 2 - Operations 2-1

Pre-Operating Instructions 2-2

Starting 2-3

Operating 2-4

Section 3 - Service 3-1

Maintenance Instructions 3-2

Air Filter Maintenance 3-3

Engine Oil Maintenance 3-5

Maintenance Schedule 3-6

Filter Replacement 3-7

Troubleshooting 3-8

061090 - 12/2013

Page iv

Table of Contents - Continued

Title Page

Parts 4-1

Factory Service Information 4-2

Replacement Part Procedure 4-3

Seat Frame Assembly 4-4

Right Rotor Assembly 4-8

Left Rotor Assembly 4-10

Right Spider Assembly 4-12

Left Spider Assembly 4-13

Right Gearbox Assembly 4-14

Left Gearbox Assembly 4-16

Pitch Control Assembly 4-18

Kill Switch Pedal Assembly 4-20

Throttle Pedal Assembly 4-22

Steering Assembly 4-24

Spray System Assembly 4-28

Mainframe Assembly 4-30

Fuel System Assembly 4-32

Power Drive Assembly 4-34

Engine Mounting Assembly 4-40

450C Engine Assembly 4-44

Electrical Schematic 4-48

Front Dolly Jack Assembly 4-50

Rear Dolly Jack Assembly 4-52

Trowel Arm Alignment Jig Assembly 4-54

Accessories 4-56

061090 - 12/2013

Information Contained in this

Manual

This manual provides information and procedures to safely operate and maintain the Allen Machine.

For your own safety and protection from personal injury, carefully read, understand, and observe the

safety instructions described in this manual. Keep this manual or a copy of it with the machine at all

times.

Always operate this machine in accordance with the instructions described in this manual. A well main-

tained piece of equipment will provide many years of trouble free operation.

This manual is divided into the following sections:

SECTION 1

SAFETY

SECTION 3

SERVICE

SECTION 2

OPERATIONS

SECTION 4

PARTS

Complete any warranty requirements as speciﬁed by the engine manufacturer in their instructions

found inside the manual box located on the operator’s control panel.

Your engine is not manufactured by Allen Engineering Corporation, Inc, and therefore is not covered

under Allen Engineering Corporation, Inc warranty.

Your engine manufacturer should be contacted if you wish to purchase a parts manual or a repair

manual for your engine.

Refer to enclosed owners engine manual for complete O&M instructions. See your battery manufac-

turer for battery warranty.

Page v

061090 - 12/2013

Dealer Name: _____________________________________________________________

Phone #: (____) - ____ - ____________________________________________________

Address: ________________________________________________________________

City:__________________________________State:________ Zip:___________________

Salesman: _______________________________Mobile Phone _____________________

Additional Comments: ______________________________________________________

________________________________________________________________________

Your Dealer has Allen Engineering Corporation trained mechanics and original Allen replacement parts.

Always contact the Allen Dealer who sold you this machine for Allen Certiﬁed repairs and replacement

parts.

Place Allen Dealer information below for future reference.

Dealer Information

Page vi

061090 - 12/2013

Ordering Parts

Page vii

Section 4.0 contains illustrated parts lists for help in ordering replacement parts for your machine. Fol-

low the instructions below when ordering parts to insure prompt and accurate delivery:

1. All orders for service parts - include the serial number for the machine. Shipment

will be delayed if this information is not available.

2. Include correct description and part number from the “PARTS” section of this

manual.

3. Specify exact shipping instructions, including the preferred routing and complete

destination address.

4. DO NOT return parts to AEC without receiving written authorization from AEC. All

authorized returns must be shipped pre-paid.

5. When placing an order, please contact the AEC dealer nearest you.

All information, speciﬁcations, and illustrations in this manual

are subject to change without notice and are based

on the latest information at the time of publication.

VISIT US!!! www.alleneng.com

LIKE US!!! www.facebook.com/AllenEngineering

WATCH US!!! www.youtube.com/AllenMachinery

061090 - 12/2013

Page viii

Model Number - Serial Number Codes

Manufacturer’s Codes:

When ordering parts or requesting service information, you will always be asked to specify the model

and serial numbers of the machine. The legends below speciﬁcally deﬁnes each signiﬁcant character

or group of characters of the Model Number and Serial Number codes.

Model Number

MSP 450

Series

450

Mechanical Super Professional

Serial Number

The serial number found on the identiﬁcation plate is a ten digit format. The model number identiﬁes

your machine and will ensure that you receive the correct replacement parts.

Serial Number Example

450 02 13 001

Series

450

Month

Year

Sequence Number
