CERT Communications Team Procedures

Alinco DJ-191 QUICK REFERENCE

Page 1

To: Do the following

Turn the radio on Press the POWER key

Adjust the volume Repeated press the UP or DOWN keys

Adjust the squelch While holding the FUNCTION button, repeatedly

press either the UP or DOWN keys.

Set the frequency 1. If Mor Cis displayed, press the Akey.

2. Using the keypad, enter all 6 digits of the desired

frequency

Change to Simplex If a +or –is displayed, hold the FUNCTION button

and press the 2key until they disappear.

Set offset for repeater

(duplex) operation 1. Hold the FUNCTION button and press the 2key

until either a +(for positive offset) or a –(for

negative offset appears. Release the FUNCTION

button.

2. The offset frequency 0.60 should be displayed.

If it is not, or a different frequency is desired,

rotate the dial until the desired offset frequency

is displayed.

3. Briefly press PUSH TO TALK.

Set tone encode (PL) 1. Press and hold the FUNCTION button, then

press the 4key until a Tis displayed. Release the

FUNCTION key.

2. Rotate the dial until the desired tone frequency is

displayed.

3. Briefly press PUSH TO TALK.

Change power Press and hold the FUNCTION button, then press

the LAMP H/L key. An Lis displayed when the

radio is set to low power.

CERT Communications Team Procedures

Alinco DJ-191 QUICK REFERENCE

Page 2

To: Do the following

Recall a pre-programmed

frequency 1. If an Mis not displayed, press the Akey.

2. Rotate the dial until the desired memory is

displayed.

Store settings in memory 1. If a Mis not displayed, press the Akey.

2. Rotate the dial to select the desired memory.

3. Press the Akey to enter VFO mode.

4. Set up all radio parameters: frequency, offset,

tone, etc.

5. Press and hold the FUNCTION button, then

press the Akey. Release the FUNCTION button.

CERT Communications Team Procedures

Alinco DJ-191 QUICK REFERENCE

Page 3

Standard CERT Channels

The following frequencies should be stored in the memory of CERT radios

CHNL Frequency

(MHz) and

offset

PL Tone

(Hz) Remarks

1 147.015 + 103.5 Resource Repeater (Used by ARES to

find who is available for assignment.)

2 147.015 Repeater output frequency (Simplex).

Use when repeater fails

3 146.940 - 123.0 Tactical Repeater. (Primary channel for

CERT out-of-district communications).

4 146.940 Repeater output frequency (Simplex).

Use when repeater fails

5 145.700 ARES Simplex Frequency

6 145.030 Packet frequency for emergency

communications in Alameda County

7 146.505 CERT Simplex #1

(Use for in-district communications)

Ardenwood, Irvington, Warm Springs

8 147.450 CERT Simplex #2

(Use for in-district communications)

Centerville, Niles, Mission San Jose

9 146.520 National Calling Frequency (Simplex)

10 162.550 Bay Area Weather, Emergency Alerts

NOAA/NWS Radio Frequencies (MHz):

162.400, 162.425, 162.450, 162.475, 162.500, 162.525, 162.550

CERT Communications Team Procedures

Alinco DJ-191 QUICK REFERENCE

Page 4

FRS Radio Information

District FRS Channel

Ardenwood 10

Centerville 1

Irvington 3

Niles 2

Mission San Jose 4

Warm Springs 5
