OAW-AP85 Field Replaceable Mount Kit

Installation Guide

0510359-01 | October 2007 1

Introduction

This installation guide covers the installation procedure for a field replaceable OAW-AP85 mount kit

only. This document does not include pre-installation and post-installation requirements, such as

minimum software requirements, AP provisioning, connecting power cables, and other network

requirements for an OAW-AP85 installation. Refer to the Alcatel-Lucent OAW-AP85 Outdoor Access

Point Series Installation Guide that shipped with your OAW-AP85 unit for complete details.

Package Checklist

zOAW-AP85 wall/pole/mast mount kit (fixture with hardware)

Mount Kit Replacement and OAW-AP85 Installation

CAUTION

Alcatel-Lucent Access Points are required to be installed by a professional installer. The

professional installer is responsible for ensuring that grounding is available and it meets applicable

local and national electrical codes.

WARNING

Do not work on an AP and do not connect or disconnect cables during periods of lightning activity.

CAUTION

Access Points are radio transmission devices and as such are subject to governmental regulation.

Network administrators responsible for the configuration and operation of Access Points must

comply with local broadcast regulations. Specifically, Access Points must use channel assignments

appropriate to the location in which the Access Point will be used.

CAUTION

RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits.

This equipment should be installed and operated with a minimum distance of 7.9 inches (20 cm)

between the radiator and your body for 2.4 GHz and 5 GHz operations. This transmitter must not be

co-located or operating in conjunction with any other antenna or transmitter. When operated in the

5.15 to 5.25 GHz frequency range, this device is restricted to indoor use to reduce the potential for

harmful interference with co-channel Mobile Satellite Systems.

2OAW-AP85 Field Replaceable Mount Kit | Installation Guide

Removing the Existing Mount Kit

1. Disconnect existing power and cable connections.

2. Remove the existing mount kit from the OAW-AP85.

Mounting the OAW-AP85

Preparing the OAW-AP85 for Installation

1. Install the four included mounting bolts (M8 bolts with captive flat washer) into the four mounting

holes on the rear of the OAW-AP85 (see Figure 1). Leave approximately two to three threads

showing on the mounting bolts.

Figure 1 Installing the Mounting Bolts

Wall Mounting the OAW-AP85

To wall mount an OAW-AP85:

1. Secure the mounting plate to a flat wall using the appropriate screws and anchors for your mounting

application (see Figure 2).

WARNING

Disconnect the AC mains before handling the AC power cable and connecting it to or disconnecting

it from the OAW-AP85.

Mounting Holes

Mounting Bolts

(M8 bolts, 4x)

NOTE

Wall mount hardware is not included with the mounting plate and must be purchased separately for

your mounting application. The mounting plate accepts the following screw/bolt sizes: M4, M5,

SAE #8, and SAE #10.

OAW-AP85 Field Replaceable Mount Kit | Installation Guide 3

Figure 2 Attaching the Mounting Plate

2. Seat the OAW-AP85 into the four keyholes on the mounting plate and tighten down the four

mounting bolts (M8 bolts) to secure the OAW-AP85 in place (see Figure 3). The mounting plate

should rest between the captive flat washer on each of the mounting bolts and the rear of the OAW-

AP85.

Figure 3 Wall Mounting the OAW-AP85

0128

Anchors (4x)

Mounting Plate

Screws (4x)

Wall

NOTE

The positioning of the keyholes on the mounting plate supports horizontal or vertical mounting of the

OAW-AP85, which is achieved by rotating the device by 90 degrees and securing it to the mounting

plate.

Mounting Bolts

Mounting Plate

OAW-AP85

Wall

4OAW-AP85 Field Replaceable Mount Kit | Installation Guide

Pole Mounting the OAW-AP85 (1.5” to 3.5” Diameter)

To mount an OAW-AP85 to a pole with a diameter of 1.5” to 3.5”:

1. Slide the long T-bolt through the opening in the mounting bracket (see Figure 4).

2. Attach the included retaining clip to the T-bolt (see Figure 4).

3. Screw the included nut onto the end of the T-bolt (see Figure 4).

4. Secure the mounting plate to the mounting bracket using the four included phillips head screws (see

Figure 4).

Figure 4 Assembling the Pole Mounting Bracket

5. Wrap the pole mounting bracket around a 1.5” to 3.5” diameter pole and secure the bracket in place

(see Figure 5).

a. Wrap the pole mounting bracket around the pole.

b. Slip the end of the T-bolt with nut through the opening in the pole mounting bracket.

c. Maneuver the T-bolt to the top slot in the pole mounting bracket and tighten down the nut.

Ensure that the nut is tightly secured and that the bracket cannot move. It must be secure to

support the weight of the OAW-AP85.

Figure 5 Securing the Pole Mounting Bracket

arun 0137

Nut (1x)

T-Bolt (1x)

Phillips Head Screws (4x)

Mounting Bracket

Mounting Plate

Retaining Clip

arun_0130

arun_0129

Step A Step B Step C

OAW-AP85 Field Replaceable Mount Kit | Installation Guide 5

6. Seat the OAW-AP85 into the four keyholes on the mounting plate and tighten down the four

mounting bolts (M8 bolts) to secure the OAW-AP85 in place (see Figure 6). The mounting plate

should rest between the captive flat washer on each of the mounting bolts and the rear of the OAW-

AP85.

Figure 6 Pole Mounting the OAW-AP85 (1.5” to 3.5” Diameter)

Figure 7 Horizontal Pole Mount Position (1.5” to 3.5” Diameter)

NOTE

The pole mounting bracket can be secured to a horizontal or vertical pole. The positioning of the

keyholes on the bracket supports horizontal or vertical mounting of the OAW-AP85 on either pole

type, which is achieved by rotating the device by 90 degrees and securing it to the bracket. Refer to

Figure 6 and Figure 7 for details.

Secured

Mounting Bracket

Tightened Mounting Bolts

OAW-AP85

Vertical Pole

arun_0131C

Secured

Mounting Bracket

Tightened Mounting

Bolts

OAW-AP85

Horizontal Pole

6OAW-AP85 Field Replaceable Mount Kit | Installation Guide

Pole Mounting the OAW-AP85 (>3.5” Diameter)

To mount an OAW-AP85 to a pole with a diameter greater than 3.5”:

1. Attach the mounting plate to the pole using outdoor rated straps (see Figure 8). Outdoor rated straps

are not included with the unit and must be purchased separately.

2. Seat the OAW-AP85 into the four keyholes on the mounting plate and tighten down the four

mounting bolts (M8 bolts) to secure the OAW-AP85 in place (see Figure 8). The mounting plate

should rest between the captive flat washer on each of the mounting bolts and the rear of the OAW-

AP85.

Figure 8 Pole Mounting the OAW-AP85 (>3.5” Diameter)

Positioning the OAW-AP85

To adjust the angle of an OAW-AP85 on a vertical pole:

1. Loosen the four M8 bolts on the side of the mounting plate and rotate the AP to the desired angle

and tighten down the M8 bolts (see Figure 9).

Figure 9 Positioning the OAW-AP85 on a Vertical Pole

NOTE

The mounting plate can be secured to a horizontal or vertical pole. The positioning of the keyholes

on the mounting plate supports horizontal or vertical mounting of the OAW-AP85 on either pole

type, which is achieved by rotating the device by 90 degrees and securing it to the mounting plate.

Outdoor Rated Straps

Mounting Plate

Mounting Bolts

OAW- Pole

M8 Positioning Bolts

(4x, 2x per side)

OAW-AP85 Field Replaceable Mount Kit | Installation Guide 7

To adjust the angle of an OAW-AP85 on a horizontal pole:

1. Rotate the entire mounting bracket to the desired angle and tighten the bracket into place (see

Figure 9).

Figure 10 Positioning the OAW-AP85 on a Horizontal Pole

Completing the Installation

Refer to the Alcatel-Lucent OAW-AP85 Outdoor Access Point Series Installation Guide that shipped

with your OAW-AP85 unit for complete installation details, such as connecting cables and power,

verifying connectivity, and configuration.

Safety and Regulatory Compliance

Alcatel-Lucent provides a multi-language document containing country specific restrictions and

additional safety and regulatory information for Alcatel-Lucent hardware products. The Alcatel-Lucent

Safety and Regulatory Addendum can be viewed or downloaded from the following location:

https://service.esd.alcatel-lucent.com.

arun_0131D

arun_0131E

8OAW-AP85 Field Replaceable Mount Kit | Installation Guide

Proper Disposal of Alcatel-Lucent Equipment

For the most current information on Global Environmental Compliance and Alcatel-Lucent products

please see our website at www.alcatel-lucent.com.

Waste of Electrical and Electronic Equipment

Alcatel-Lucent products at end of life are subject to separate collection and

treatment in the EU Member States, Norway, and Switzerland and therefore are

marked with the symbol shown at the left (crossed-out wheelie bin). The treatment

applied at end of life of these products in these countries shall comply with the

applicable national laws of countries implementing Directive 2002/96EC on Waste of

Electrical and Electronic Equipment (WEEE).

European Union RoHS

Alcatel-Lucent products also comply with the EU Restriction of Hazardous

Substances Directive 2002/95/EC (RoHS). EU RoHS restricts the use of specific

hazardous materials in the manufacture of electrical and electronic equipment.

Specifically, restricted materials under the RoHS Directive are Lead (including Solder used in printed

circuit assemblies), Cadmium, Mercury, Hexavalent Chromium, and Bromine. Some Alcatel-Lucent

products are subject to the exemptions listed in RoHS Directive Annex 7 (Lead in solder used in printed

circuit assemblies). Products and packaging will be marked with the “RoHS” label shown at the left

indicating conformance to this Directive.

China RoHS

Alcatel-Lucent products also comply with China environmental declaration requirements

and are labeled with the “EFUP e” label shown at the left.

Contacting Alcatel-Lucent

Web Site Support

Main Site http://www.alcatel-lucent.com/wps/portal/enterprise

Support Site https://service.esd.alcatel-lucent.com

Support Email support@ind.alcatel.com

Telephone Support

North America 1-800-995-2696

Latin America 1-877-919-9526

Europe +33 (0) 38 855 6929

Asia Pacific +65 6240 8484

Worldwide 1-818-880-3500
