Alcatel-Lucent 735x ISAM FTTB Product Portfolio2

The delivery of premium video services — be it IPTV or over-the-top (OTT)

video — produces nearly an order of magnitude increase in bandwidth

demands. As a result, service providers have been looking at deep ﬁber

deployments: some operators deploy DSLAMs in cabinets or in buildings

to shorten the copper loops, enabling them to deliver the required high

bitrates over VDSL2 or ADSL2plus; others remove the copper loop altogether

and connect subscribers with Fiber to the Home. Alcatel-Lucent’s strategy

for more than the past two years has been “Fiber to the most Economical

Point”. Our strategy and this ISAM product portfolio recognize that

operators will deploy a mix of CO, FTTN, FTTC, FTTB, and FTTH technolo-

gies to serve their subscribers with very high speed broadband services in

the most cost-effective way.

Alcatel-Lucent 735x ISAM FTTB Product Portfolio 3

Brokering the

new world of triple play

Video has become a key agent of change. Service providers

are being forced to innovate by offering competitively

differentiated services and by exploring new business

models based on targeted advertising, e-commerce integra-

tion, and revenue sharing with application and content

providers. While services such as these are boosting ARPU

(average revenue per user), they are also placing unprec-

edented stress on the traditional high-speed Internet

infrastructure.

Consider these facts: end users downloaded 100 billion

Internet video clips in 2007; by 2011, streaming video content

will increase from 0.3 Exabytes (EBs) to 10 EB. What’s

more, analysts are predicting 55 million IPTV subscribers

in three years time. Just as signiﬁcant, Youtube currently

accounts for 10 percent of all Internet trafﬁc, while over-the-

top streaming comprises 20 percent. All of this, coupled

with the fact that the top four user generated content (UGC)

providers — Youtube, Google, Yahoo, and MSN — with a

combined audience of 94 million, is driving service providers

to provide not only the required bandwidth but also the

necessary quality of experience (QoE) that their end users

want and expect.

To meet this challenge — to provide the scalability and

quality that these video applications require — service

providers need to determine the best strategy to meet

escalating bandwidth requirements. Among other things,

they need to identify the most economical point for ﬁber

deployment, while also leveraging their existing copper

assets. Put somewhat differently, they need to ﬁnd a cost-

effective solution capable of assuring the QoE required to

deliver triple play services in both high and low density

areas. The good news is that, in combination with Alcatel-

Lucent ISAM portfolio, the Alcatel-Lucent 735x FTTB

ISAM Product Family is letting service providers extend

the triple play offer to all subscribers in order to achieve

100-percent coverage.

The Alcatel-Lucent 735x ISAM FTTB Product Family

is the newest addition to the ISAM family, and gives

service providers the ﬂexibility and scalability neces-

sary for the successful delivery of triple play services.

By allowing operators to deploy DSLAM equipment

closer to the subscriber — typically in building, curb,

or cabinet deployments — the Alcatel-Lucent 735x

ISAM FTTB Product Family enables cost-effective

delivery of triple play services. Besides the standard

Ethernet and GPON aggregation technologies, the

735x family also supports the unique Distributed

DSLAM concept, which allows operators to manage

small DSLAMs as remote linecards of a central host,

resulting in low aggregation CAPEX and low OPEX.

Alcatel-Lucent 735x ISAM FTTB Product Portfolio4

Leveraging the ISAM family advantage

As part of the Alcatel-Lucent ISAM portfolio, the 735x Intelligent Services

Access Manager (ISAM) Fiber to the Building (FTTB) Product Family plays a

critical role in extending coverage for premium services to all subscribers. This

is made possible with a family of small DSLAMs — also known as remotes —

which can be placed in cabinets, buildings, or at the curb. The net result is that

service providers shorten the copper loop, thus enabling high bitrates over VDSL2

or ADSL2plus.

Together with the CO/FTTN products of the ISAM portfolio, the Alcatel-

Lucent 735x FTTB Product Family lets operators build a ﬂexible architecture —

quickly and cost-effectively — with a highly targeted triple play offer. Whether

they choose CO, FTTN, FTTB/C, FTTH or a combination of these, service

providers are able to take advantage of the ISAM family’s wide ranging portfolio —

designed to deliver ﬁber to the most economical point.

As members of the ISAM portfolio, the Alcatel-Lucent 735x ISAM Product Family

also provides the same service intelligence on any line or any box, shares a

common network management, and enjoys the same environmental and electro-

magnetical hardening. The remotes, which support the Distributed DSLAM

concept, even use the same linecards as the 7302 and 7330, resulting in reduced

OPEX with easier software upgrades, better aggregation, faster training, and

simpliﬁed qualiﬁcation cycles and stock management.

Alcatel-Lucent 735x ISAM FTTB Product Portfolio 5

Introducing the Alcatel-Lucent

735x ISAM FTTB product family members

With the Alcatel-Lucent 735x ISAM Product Family, service providers have a broad choice of

densities, aggregation technologies, and deployment models capable of bringing ﬁber to the most

economical point. Moreover, the variety of form factors lets service providers maximize their

customer base with a full triple play offer.

ALCATEL-LUCENT 735xISAM FTTB PRODUCT FAMILY ROLE AND FUNCTION

The Alcatel-Lucent 7352 Intelligent Services Access Manager (ISAM) Fiber to

the Building (FTTB) optical network terminal (ONT) is a compact GPON-fed 24p

VDSL2 remote for the Alcatel-Lucent ISAM 7342 FTTU. It allows operators to

deliver very high speed services using small DSLAMs (remotes) deployed close to

subscribers — either in cabinets or in buildings.

The Alcatel-Lucent 7354 ISAM FTTB RU is an Ethernet-fed 24p VDSL2 remote

with 30a profile support and ADSL backward compatibility, using GE Ethernet

uplinks for easy integration in Ethernet aggregation networks. It is ideal for

service providers involved in a gradual fiber migration.

The Alcatel-Lucent 7356 ISAM FTTB REM is a 48p/96p mini MSAN with 2 LT slots

and 1 or 2 splitter slots, hosted from the Alcatel-Lucent 7330 ISAM FTTN or

Alcatel-Lucent 7330 ISAM Remote Aggregator (RA). It is managed as a remote

linecard of a 7330 host, resulting in lower aggregation CAPEX, lower OPEX, and

faster roll-out. The 7356 ISAM FTTB REM accepts ISAM line cards, including the

VDSL2, multi-ADSL, point-to-point Ethernet, and voice boards.

The Alcatel-Lucent 7357 ISAM FTTB SEM is a 48p sealed VDSL2 remote hosted

from the Alcatel-Lucent 7330 ISAM FTTN or Alcatel-Lucent 7330 ISAM Remote

Aggregator (RA). It is designed for flexible large-scale outdoor FTTB deployments,

with passive cooling and remote powering. It is managed as a remote linecard of a

7330 host, resulting in lower aggregation CAPEX, lower OPEX, and faster roll-out.

The Alcatel-Lucent 735x FTTB portfolio is launched together with the

Alcatel-Lucent 7330 ISAM Remote Aggregator, which offers cost-effective

aggregation for hosted remotes (7356 REM and 7357 SEM), and for mixed

hosted Ethernet-fed remote deployments. The Alcatel-Lucent 7330 ISAM RA

reduces aggregation CAPEX by reducing the number of ports required on the

metro aggregation network nodes.

Alcatel-Lucent 7352 ISAM FTTB ONT

Alcatel-Lucent 7354 ISAM FTTB RU

Alcatel-Lucent 7356 ISAM FTTB REM

Alcatel-Lucent 7330 ISAM RA

Alcatel-Lucent 7357 FTTB SEM

Alcatel-Lucent 735x ISAM FTTB Product Portfolio6

Unique advantages of the

Alcatel-Lucent 735x ISAM FTTB family

With the 735x ISAM FTTB Product Family’s unique advantages, in combination

with other members of the ISAM family, service providers can deliver on any

FTTX deployment model with reduced CAPEX and OPEX. They are also

positioned to capture new revenue from over-the-top application content providers

looking to assure their customers of superior QoE.

Figure 1. Alcatel-Lucent 735x ISAM FTTB product family – GPON, Ethernet and distributed DSLAMs

7356 ISAM

FTTB REM

7357 ISAM

FTTB SEM

Internet

IPTV

VoIP

7357 ISAM

FTTB SEM

VDSL2

DSL/voice/P2P

GPON

Expansion

link

12x

24x

Expansion link

Remote

LTs

Expansion

link

Expansion

link

Ethernet

7352 ISAM

FTTB ONT

7354 ISAM

FTTB RU

7330 ISAM

FTTN

Distributed

DSLAM

Ethernet-fed

GPON-fed

7342

ISAM FTTU

7330 ISAM

FTTN RA

7750 SR 7450 ESS

7356 ISAM

FTTB REM

Alcatel-Lucent 735x ISAM FTTB Product Portfolio 7

Distributed DSLAMs – 24x fewer nodes to manage

The 735x FTTB product family not only supports the

standard ﬁber and Ethernet aggregation technologies, it

also offers the unique “Distributed DSLAMs” concept.

With this approach to aggregation, the Alcatel-Lucent 7330

Remote Aggregator serves as a host for remote REMs and

SEMs. As a result, the number of nodes in a remote deploy-

ment is reduced by a factor of 24x. This is because the

remotes are managed, not as individual nodes, but as

remote host linecards. This brings three advantages:

•Low aggregation CAPEX — The number of costly

aggregation ports in the Ethernet MAN is reduced

by the same factor of 24x.

•Cheaper and faster operations — Alarm management,

software upgrades, and system conﬁguration and mainte-

nance are reduced by the same factor, reducing required

staff and maintenance duration.

•Faster roll-out — Using the same line cards across the

ISAM family not only means that the same service can

be offered, but also results in faster qualiﬁcation, easier

training, simpler stock management, and faster feature

availability roll-outs.

Virtual ONT – Consolidated management

of copper and ﬁber users

By incorporating the Virtual ONT concept, the Alcatel-

Lucent 7352 ISAM FTTB ONT lets service providers

manage QoS for ﬁber and copper users in precisely the

same way. Each VDSL copper user has the same QoS

management as FTTH/GPON users, and is treated, in

effect, as if each is a ﬁber user (i.e., with the same type

of GPON T-CONTs mechanism). As a consequence,

service providers enjoy signiﬁcantly reduced OPEX.

Alcatel-Lucent Smart DSL –

Unprecedented line stability

Line stability is crucial for IPTV and streaming video,

because each technology is highly sensitive to errors.

Anything less than superior quality will meet with

subscribers’ complaints. To meet this challenge, the

Alcatel-Lucent 7354 ISAM FTTB RU, the 7356 ISAM

FTTB REM, and the 7357 ISAM FTTB SEM are designed

to take advantage of Alcatel-Lucent’s Smart DSL, an

innovative technology, which signiﬁcantly increases DSL

line stability. Compared to the standard technique of

increasing the noise margin, which often leads to much

lost bandwidth, Alcatel-Lucent Smart DSL stabilizes lines

at as much as 30 percent higher bit rates.

Smallest MSAN on the market –

Reduced footprint and multiservice access

The Alcatel-Lucent 735x Product Family also boasts the

smallest Multi-service Access Node (MSAN) available

today. As such, the Alcatel-Lucent 7356 ISAM FTTB

REM is ideal for service providers rolling out Very High

Speed broadband services from remote deployments with

a smooth migration for existing ADSL and voice customers.

Its support for the P2P Ethernet line card also provides a

path toward mixed DSL/ﬁber deployments from the cabinet,

and also offers voice termination. For ease of deployment,

training, and stocking, the FTTB family’s DSL, ﬁber,

splitter and voice cards are the same ones as those being

used in the CO/FTTN members of the ISAM portfolio.

Alcatel-Lucent 735x ISAM FTTB Product Portfolio8

More about the 735x FTTB family members

Up to 100 Mb/s – 24p VDSL2, 30a and 17a proﬁles

Flexible FTTB/FTTH mix – Serve FTTB/FTTH subscribers

from the same ﬁber, line card or shelf

Smallest box on the market – 19” form factor, 1RU

Indoor/outdoor – EMC and industrial temperature

hardened (-40ºC to +65ºC)

Virtual ONT – Same QoS management for FTTB

as for FTTH subscribers

Up to 100 Mb/s – 24p VDSL2, 30a/17a/12b/12a, back-

wards ADSL/ADSL2+ compatible

Low barrier for VDSL2 rollout – Plug ‘n’ Play Ethernet-

fed VDSL2 remote

Carrier-grade pizza box – ISAM management and

service intelligence

Indoor/outdoor – EMC and industrial temperature

hardened (-40ºC to +65ºC)

Smart DSL – Stabilize DSL lines at up to 30 percent higher

rate than traditional way

The Alcatel-Lucent 7352 ISAM FTTB ONT is ideal for

service providers pursuing an FTTB strategy or a combi-

nation of FTTH and FTTB. Typically such service provid-

ers are deploying FTTH to single-dwelling units, but for

economical and time-to-market reasons they want to re-use

existing in-building copper in multi-dwelling units. With

the Alcatel-Lucent 7352 FTTB ONT’s Virtual ONT con-

cept, the QoS for FTTB subscribers can be managed in

the same way as for FTTH ﬁber-connected users. This FTTB

model completely complies with the FSAN GPON standards.

The Alcatel-Lucent 7354 ISAM FTTB RU is designed

for service providers involved in gradual ﬁber migration.

Instead of deploying ﬁber to the home, many service provid-

ers are choosing to re-use the existing copper pairs where

available, and to deploy VDSL2 service from the cabinet

or FTTB deployments. In this respect, the Alcatel-Lucent

7354 ISAM FTTB RU is ideal for both Tier 1 and smaller

operators. It provides a compact Ethernet-fed ISAM DSLAM

for FTTB or cabinet deployments, and is an ideal comple-

ment to existing (CO) ISAM deployments, offering the

same management and service intelligence as other members

of the ISAM family. For smaller operators, the Alcatel-

Lucent 7354 ISAM FTTB RU provides the lowest barrier

to high-speed VDSL2 deployments with 30a proﬁle support

and standard Ethernet uplink, while still offering Alcatel-

Lucent’s expertise in carrier-grade DSL products.

Alcatel-Lucent 735x ISAM FTTB Product Portfolio 9

The Alcatel-Lucent 7356 ISAM FTTB REM has been

especially designed for service providers rolling out Very

High Speed Broadband services using VDSL2 or ADSL2+

from remote deployments, with a smooth migration for

existing ADSL and voice customers. The Distributed

DSLAM concept makes the Alcatel-Lucent 7356 ISAM

FTTB REM particularly well suited for large-scale deploy-

ments and for the extension of an existing ISAM deployment

to FTTB/FTTN remotes. Support for P2P Ethernet line

card provides a path towards mixed DSL/ﬁber deploy-

ments from the cabinet. The 7356 ISAM FTTB REM

accepts two ISAM line cards (VDSL2, multi-ADSL, P2P

Ethernet, and voice), and one or two ISAM splitter boards.

The Alcatel-Lucent 7357 ISAM FTTB SEM meets the

challenges of service providers deploying Very High Speed

Broadband services using VDSL2 from outdoor remote

deployments. It is weatherproof and hardened for outdoor

deployments (wall/pole mounted), which is extremely

cost-effective and allows for a faster-time-to-market because

operators do not have to build cabinets or negotiate building

access with landlords. It’s also optimized for residential

deployments being absolutely silent (thanks to passive

cooling), with a small footprint. In addition, the unique

hosted concept makes the Alcatel-Lucent FTTB SEM

particularly well-suited for large-scale deployments and for

extension of an existing ISAM deployment to FTTB/

FTTC remotes. The Alcatel-Lucent 7357 ISAM FTTB

SEM is an ideal complement for cabinet deployments,

allowing operators to reach 100 percent coverage in a

cost-effective way.

ISAM VDSL2 LT – Up to 70 Mb/s – 48 p VDSL2, all/12/17

proﬁles, backwards ADSL/ADSL2+ compatible

Fast rollout – 100 percent coverage – remote power,

passive cooling; no cabinets required

Distributed DSLAM –Low OPEX/aggregation CAPEX;

full feature parity with CO/FTTN

Outdoor/residential areas – Absolutely silent; small

footprint; weatherproof, +45 plus solar load

Smart DSL – Stabilize lines at up to 30 percent higher rate

than traditional way

ISAM VDSL2 LT – Up to 70 Mb/s – 48p VDSL2, all 8/12/17

proﬁles, backwards ADSL/ADSL2+ compatible

Smallest MSAN on the market – ISAM LTs – DSL, voice

and P2P Ethernet; clock synchronization over ﬁber

Distributed DSLAM – Low OPEX/aggregation CAPEX, full

feature parity with CO/FTTN

Indoor/outdoor – EMC and industrial temperature hardened

(-40ºC to +70ºC)

Smart DSL – Stabilize lines at up to 30 percent higher rate

than the traditional way

Alcatel-Lucent 735x ISAM FTTB Product Portfolio10

Table 1. Comparison of the Alcatel-Lucent 735x FTTB family features

735xISAM FTTB PORTFOLIO 7352 7354 7356 7357

Type GPON MDU ONT Pizza Box 3-slot/4-slot shelf Sealed remote

Uplink GPON 2xGigE Distributed DSLAM

Aggregated on 7342 ISAM FTTU Eth Switch 7330 FTTN (12p) or 7330 RA (24p)

Max. DSL Subs 24 24 48-96 48

VDSL2 profiles 17a, 30a 12a/b, 17a, 30a All 8/12/17 profiles

Backwards ADSL comp N ADSL/ADSL2+ ADSL/ADSL2+

Splitters 1RU splitter unit Integrated Splitter LT Integrated

POTS/ISDN Termination N N Y N

Other line cards N/A N/A m-ADSL, Eth, Voice N/A

Access Mgmt System Y Y Y Y

Stacking Optical (splitter) 4 units – 96 subs N N

Cooling Active Active Active Passive

Hardening and Sealing Industrial Industrial Industrial Industrial/Sealed

Outdoor deployments Y (in cabinets) Y (in cabinets) Y (in cabinets) Y (weatherproof)

Rack mount ETSI and 19” ETSI and 19” ETSI and 19” N/A

Height 1RU 1.5RU 2.5RU N/A

Ce manuel convient aux modèles suivants

Autres manuels Alcatel-Lucent Matériel réseau

Alcatel-Lucent

Alcatel-Lucent ISAM FTTN 7330 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent Service Aggregation Router 7705 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent vitalqip 5000 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 9364 Mode d’emploi

Alcatel-Lucent

Alcatel-Lucent 1677 SONET Link Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent Rainbow Office Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7342 ISAM FTTU Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent VitalQIP 500 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent Network Device K-12 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7330 Manuel d'installation et d'exploitation

Alcatel-Lucent

Alcatel-Lucent 1353 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5750 SSC Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7310 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OAW-AP85 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7302 Guide d'installation

Alcatel-Lucent

Alcatel-Lucent 7302 Manuel technique

Alcatel-Lucent

Alcatel-Lucent 9764 Series Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent Broadband 700 MHz Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 100 GbE Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent Metrospan Edge 1692 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel technique

Alcatel-Lucent

Alcatel-Lucent 9764 Series Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent OmniAccess 700 Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur

Lanner

Lanner NCA-1525 Manuel utilisateur
