Akuvox E21V Manuel utilisateur

E21A/E21V

Quick Guide

Unpacking

Please make sure the package contains the following items:

E21A/V x 1 Screw x 4 Screwdriver x 1 Back cover x 1（Optional）

Product Overview

E21V

E21A

E21A/E21V

Installation

Back cover installation

Regarding the size of back cover, use the cement to fix the back cover in the wall, make sure the path for

power and Ethernet has been reserved.

E21A/E21V

Connect to the power and Internet

Fix the panel with screws

Note: If Power over Ethernet

is being used, do not plug in

another power supply.

E21A/E21V

Configuration

1. Access the Web UI: Input the IP address into browser to configure the phone. The default IP address is

192.168.1.100.

2. Account Registration: On web UI, go to the path: Account -> Basic to register an account and fill in the

account information. (Please refer to user manual for more information)

3. Configure the Push Button: On web UI, go to the path: Intercom -> Basic -> Push Button to configure the

call number.

4. Configure the DTMF code: On web UI, go to the path: Intercom -> Relay&Input -> Relay and choose the

DTMF code number in corresponding area.

IP Announcement

1. While E21 startup normally, hold the call button for several seconds after LED light turns blue, voice

system will enter IP announcement mode.

2. In announcement mode, the IP address will be announced periodically.

3. Press Call Button again to exit the announcement mode.

4. In announcement mode, phone announces "IP 0.0.0.0" if no IP address is gained.

Operation

Make a call:

1. Press the call button to call indoor SIP Phone, video call is only for E21V.

2. During the talk, called party can press predefine DTMF code number to open the door.

Receive a call:

E21 supports Auto Answer by default. Incoming call from indoor device will be answered automatically.

E21A/E21V

LED Status Information

LED Status

Description

Blue

Always on

Normal status

Flashing

Calling

Red

Flashing

Network is unavailable

Green

Always on

Talking on a call

Flashing

Receiving a call

Pink

Flashing

Firmware upgrading

Note: For more LED settings, please refer to E21 web interface.

Notice Information

Information contained in this document is believed to be accurate and reliable at the time of

printing. This document is subject to change without notice, any update to this document can be

reserved.
