Akuvox R20A Manuel utilisateur
Allen Wrench x 1
Rope x 1
R20A x 1
ST4x20 screw x 4 Screw fixing seat x 4
M2.5x6 screw x 6Back cover x 1
Universal Accessories:
Wall-mounting screw x 4
Rubber Plug x 3 （S,M,L）
Camera
RF card reader
Mic
R20A
Infrared sensor
Cable locking plate x 1
M3x6 screw x 2
M4x30 screw x 2 Wall-mounting bracket x 1
R20A
Fix the wall-mounting bracket on
embedded box with two M4x30
screws.
Mark the two holes of the
wall-mounting bracket on the
wall.
Take down two M4x30 screws
and remove the wall-mounting
bracket.
Fix the wall-mounting bracket with two
ST4x20 screws and two M4x30 screws.
Insert two screw fixing
seats into the holes.
Use a hand drill with 5mm diameter bit to
make two 25mm depth holes in the
marked positions.
2
Mark the four holes of the
wall-mounting bracket on
the wall for the screws.
Use a hand drill with 5mm diameter
bit to make four 25mm depth holes
in the marked positions.
Fix the wall-mounting bracket
with four ST4x20 screws.
Insert four screw fixing seats into
the holes.
R20A
60
56
60
Fasten the back cover with four
M2.5x6 screws, then fix four
wall-mounting screws on the
back of R20A.
For convenient wiring, hang
R20A on the wall-mounting
bracket with rope.
Make cables go through the back
cover, connecting to the corresponding
interfaces of the main board.
3
Select a suitable size rubber plug
to push all the cables into the back
cover. Fix cable locking plate to
the back cover with two M2.5x6
screws.
After successful installation,
check the stability of device.
Insert the four wall-mounting screws on
the device into the corresponding holes
on the wall-mounting bracket, and then
press down to slide the wall-mounting
screws into the groove. Then use the
Allen Wrench to tighten the device with
two M3x6 screws.
R20A
4
Network Video Recorder
(third party)
SIP Video Phone
LAN
PoE PoE
R20A R20A
PoE PoE
R20A R20A
PC(third party)
PoE PoE
Indoor Monitor
1. While R20A starts up normally, hold the call button for several seconds after the Status
LED turns blue, voice system will enter IP announcement mode.
2. In announcement mode, the IP address will be announced periodically.
3. Press Call Button again to quit the announcement mode.
4. In announcement mode, phone announces "IP 0.0.0.0" if no IP address is gained.
R20A
5
1. Access the Web UI: Input the IP address into web browser to configure the phone.
2. Account Registration: On web UI, go to the path: Account -> Basic page
Register Account and fill in the account information. ( Please refer to user manual for
more information)
3. Configure the Push Button: On web UI, go to the path: Intercom -> Basic -> Push Button
to configure the call number.
4. Configure the code to open the relay: On web UI, go to the path: Intercom -> Relay
-> Relay ID/DTMF and choose the DTMF code number in corresponding area.
Make a call:
1. Press the call button to call indoor SIP Phone.
2. During the talk, called party can press pre-configured code number to unlock the door.
Receive a call:
R20A supports Auto Answer by default. Incoming call will be answered automatically.
R20A
6
Note: For more LED settings, please refer to R20 webUI: Intercom -> LED Setting.
R20A
AKUVOX (XIAMEN) NETWORKS CO., LTD.
ADD: 10/F, NO.56 GUANRI ROAD, SOFTWARE PARK II, XIAMEN 361009, CHINA
www.akuvox.com
Notice Information
Akuvox R20A firmware contains third-party open source software under the terms of the GNU General Public License(G-
PL). Akuvox is committed to meeting the requirements of the GNU General Public License (GPL) and will make all
required source code available.
The source code of software under the terms of GNU GPL can be downloaded online: http://www.akuvox.com/gpl.
Information contained in this document is believed to be accurate and reliable at the time of printing. This document is
subject to change without notice, any update to this document can be viewed on Akuvox’ s website: http://www.akuvox-
.com © Copyright 2019 Akuvox Ltd. All rights reserved.
