Wearing
Secure the cable over ear
1 2 Move the slider to the base
of the back of the neck for a
secure fit
3
MEMORY FOAM TIP INSTRUCTIONS
HOW TO INSTALL/USE
HOW TO CLEAN
Using only water, gently wipe with a clean, damp cloth.
Let the tips dry completely before use.
To install, firmly hold the Memory Foam tip between your thumb and forefinger. Place the sound port into the
core of the tip at a slight angle. Once the tip engages onto the sound port, straighten out the tip and push the tip
as far back as it will go.
Before inserting into the ear canal, roll the tip between your fingers to compress the foam. Insert the tip as deep
as possible without irritating the ear. Hold in place for 15-30 seconds, allowing the tip to expand and conform to
your ear canal. This will create a custom fit and perfect seal - providing an optimal audio experience.
Type
Magnets
In-Ear Universal Fit
Model S6
Neodymium N50 (Front & Rear)
Transducer Planar Magnetic
Frequency Response
Impedance
Sensitivity
10 - 44,000Hz
18Ω @ 1kHz
108dB
Connectors
Cable
Length
MMCX Gen-2 ( Micro Miniature Coaxial ) connectors
Titanium Kevlar Mono-Crystalline Oxygen-Free Copper
1.2M (4.0ft)
SPECIFICATIONS
Insert the monitors slightly
backwards & turn forward as
shown. If using Surefire
interface, lock the extended
part in to the cymba-concha
flap for a secure fit
www.akoustyx.com
© Artists images courtesy of Mopho, Portugal.
"Akoustyx" & the "Akoustyx logo" are registered trademarks of Akoustyx LLC, registered in the U.S. and other countries.
This is a patented product design & is protected by patents in the U.S. & other countries.
© 2022 Akoustyx LLC. All rights reserved.
WARNING:
HEARING LOSS IS IRREVERSIBLE. LISTENING AT HIGH VOLUME LEVELS FOR EXTENDED PERIODS CAN CAUSE PERMANENT
HEARING DAMAGE. ALWAYS LISTEN AT A REASONABLE AUDIO LEVEL TO AVOID HEARING DAMAGE.
DO NOT USE THESE IN-EAR MONITORS IN ANY ENVIRONMENTS WHICH REQUIRE YOUR ATTENTION SUCH AS TRAFFIC OR
OPERATING MACHINERY.
THIS PRODUCT DOES NOT CONTAIN ANY USER SERVICEABLE PARTS. ANY MODIFICATIONS AND/OR TAMPERING WITH THE
PRODUCT AND/OR PROVIDED ACCESSORIES WILL VOID THE WARRANTY.
* Specifications subject to changes without prior notice
Designed in the Bay Area, California. Assembled & tuned in Nashville, Tenessee.
Made in USA of U.S. and imported parts.
