Akko 3061 BT5.0 Manuel utilisateur
用户手册
User Manual
BT5.0
RGB蓝牙版
292 x 101 x 37mm
Approximately 0.5KG
PBT Material
Bluetooth / Wired
Type-C To USB
1800mAh
YES
YES
YES (use Akko Marco V1.0)
Mechanical Keyboard
China
3061 Technical Specifications
13
Dimensions
Weight
Keycap
Connection
Interface
Battery Capacity
Multimedia Keys
N-Key Rollover
Custom Keys
Type
Country of Origin
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 Delete
~
Insert PrtSc
Menu
Cal
12 3 4
1Esc 2 3 4 5 6 7 8 9 10 - = Backspace
W
M < >
I P
Ctrl
L
C
Fn
3061 HotKeys
14
Swap W A S D with ↑↓ ← →
Fn+ W
Revert Ctrl into Menu (APP) key
Hold down FN and press right Ctrl
Calculator
Mute
Decrease Volume
Increase Volume
C
M
<
>
Fn+ =
~
F1 - F10
F11
F12
Delete
Fn+
Esc
1 - 0
-
=
Backspace
=
↑↓ ← →
Bluetooth Device 1~4
Insert
PrtSc
Light On/Off
W / A /S / D
E / R / T / Y
I
P
L
Fn+ =
Win
Win Win
～
Press Fn and left Win key
Lock Windows Key
Hold down left Win and right Win key for 5s
Restore Factory Settings
3061 System Commands
15
Fn
3061 Backlight Settings
16
L ; : ’ ” Enter
\[ { ] }
Fn
Dim
Bright
Enter
Fn+ =
In Bluetooth mode, the light is
turned off by default for power
saving.
Press Fn+L to turn on the light.
Switch between 18
different lighting effects
Change RGB backlit color
in certain lighting effects
Slower Animation
Faster Animation
[
]
; :
’”
\
3061 Bluetooth Feature Overview
17
Fn
E R T Y
～
Turn the switch on the back panel to “OFF” to disable Bluetooth and enable the Wired mode.
Turn the switch on the back panel to “ON” to enable Bluetooth and disable the Wired mode.
Wired/BT Mode Switch
Pairing Bluetooth device with keyboard. The light will keep blinking during the pairing process
and restore to the previous light status when pairing succeeds.
Long Press Fn+E/R/T/Y
Switch between Bluetooth devices. The light will blink once and restore to the previous light
status when device switch succeeds.
Press Fn+E/R/T/Y
The power indicator LED is under the spacebar. The LED turns on when keyboard is charging
and turns off when keyboard is fully charged.
Charging Indicator
Press any key and the LED under the space bar will flash for 3 times as low battery warning.
Low Battery Indicator
18
3061 Bluetooth Setup Instruction 1
1.Switch to Bluetooth mode
Turn the switch on the back panel to “ON” to enable Bluetooth and disable the Wired mode.
2.Set the Bluetooth profile
The keyboard can memorize 4 switchable Bluetooth devices, which are saved in 4 Bluetooth profiles through
short-cuts Fn+E/R/T/Y (corresponds to BT1/BT2/BT3/BT4); When you first use the keyboard, select a desired
Bluetooth profile by pressing Fn+E/R/T/Y to initialize device searching ; Once it’s been setup and paired,
whenever you use the keyboard again, it would memorize the last Bluetooth device it has been worked on,
trying to send Bluetooth signal to communicate with the specific device.
3.Bluetooth Pairing
When you use your PC/ PAD/iPhone to pair with the keyboard, and the Bluetooth mode of the keyboard and
PC/PAD/iPhone have all been turned on, the keyboard would show up based on the Bluetooth profile you set in
step 2 such as Akko 3061-BT1 / Akko 3061-BT2 / Akko 3061-BT3 / Akko 3061-BT4.
19
3061 Bluetooth Setup Instruction 2
4.Switch the Bluetooth device
After 4 Bluetooth devices have been paired with the keyboard, long press Fn+E / Fn+R / Fn+T / Fn+Y for at
least 3 seconds to quickly switch between them.
5.Shut off the keyboard
Turn the power off on the keyboard back panel while unused for power saving;
If the keyboard remains unused for over 10 mins, it would go to sleep mode and you can activate it by
pressing any key.
Note: The battery saver mode for Windows system would affect/delay the sleep activation time of the keyboard.
6.Reset the keyboard
If you forgot the specific paired front-end device or if there remains disorder in Bluetooth conneciton and
communication, you can press Fn + ~ to reset the keyboard. This action erases all pairing information stored
in your keyboard.
Akko Macro V1.0
Macro Setup Instruction 1
20
1. Akko Macro V1.0 is hardware-based and works without software-driven.
2. The following keys cannot be programmed: "Esc", "Fn" ，"Left Win"and "Right Win".
3. Akko Macro V1.0 does not support simultaneous trigger, that is, pressing "AB" at the same time will trigger the
two keys in the order of A followed by B.
4. Akko Macro V1.0 does not support customized interval time, that is, the trigger interval between key A and key
B cannot be defined and will follow the system's default trigger time.
Akko Macro V1.0
Macro Setup Instruction 2
21
Enter Macro Mode Start Macro Editor Macro Recording Fn + Custom Key
Exit Macro EditorExit Macro Mode
Fn + Custom Key
Record the next Key
Back to Default Mode Fn+Esc
Long Press Fn +Left Win Fn+Esc (End Recording)(Press Keys to Store)
Clear Macro：
If a key has been defined, after entering the Macro editor, you can press “FN + the key” to
clear its definition.
If you want to re-customize that key, press “FN + the key”again to start the new Macro
recording after clearing its old definition.
