Akko Sakura Jelly Manuel utilisateur

Acrylic Mechanical Keyboard

User Manual

Sakura Jelly

Technical Speciﬁcations

HotKeys

System Commands

Backlight Settings

Akko Macro V1.0 Macro Setup Instruction 1

Akko Macro V1.0 Macro Setup Instruction 2

Akko Macro V1.0 Macro Setup Instruction 3

Akko Macro V1.0 Calling Macros

Akko Warranty and Service Statement

Technical Speciﬁcations

Dimensions

Model

Weight

Keycap

Interface

Multimedia Keys

N-Key Rollover

Custom Keys

Type

Country of Origin

Sakura Jelly

364 x 135 x 30mm

Approximately 0.83KG

China

Mechanical Keyboard

PBT Material

Type-C To USB

YES

YES (use Akko Marco V1.0)

Hold down FN and press right Ctrl Revert Ctrl into Menu (APP) key

HotKeys

F1 F2 F3 F4 F5 F6 F7 F8

C M < >

Ctrl

Cal

Fn+ =

Fn+ =Fn+ =Previous Song

Next Song

Calculator

Mute

Decrease Volume

Increase Volume

E-mail

Windows Search

Browser Homepage

File Explorer Media

Pause/Playback

System Commands

Win Win

Win

Press Fn and left Win key

Lock Windows Key

Hold down left Win and right Win key for 5s

Restore Factory Settings

Lighting Eﬀect 1

Lighting Eﬀect 2

Lighting Eﬀect 3

Lighting Eﬀect 4

Lighting Eﬀect 5

Lighting Eﬀect 6

“↑”

“↓”

“←”

“→”

“-”

“+”

Ins

Home

PgUp

PgDn

Del

End

F10

F11

F12

ScrLK

Backlight Settings

Fn+ Fn+=Fn+ = =

The adjustments on

the left is for generic

lighting eﬀects. Some

lighting eﬀects cannot

be tweaked.

For example,eﬀects

with constant light can

only adjust brightness

as they don’t have

animation speed and

direction.

F9 F10 F11 F12 ScrLK

Ins Home PgUp

PgDnEndDel

↑

Bright

Dim

Slower Animation

Faster Animation

Acrylic Case Light

Animation Faster

Acrylic Case Light

Animation Slower

Acrylic Case Light

Dimmer

Acrylic Case Light

Brighter

Turn Oﬀ Backlight

Change the Animation Direction

for Some Lighting Eﬀects

Change the Color for Some

Lighting Eﬀects

Akko Macro V1.0

Macro Setup Instruction 1

1. Akko Macro V1.0 is hardware-based and works without software-driven.

2. The following keys cannot be programmed: "Esc", "Fn", "Left Win".

3. Press and hold Fn + Win for 3 seconds to switch to the Macro mode. When the keyboard is re-connected or the

system is restarted, the Macro mode will be exited. You need to switch to the Macro mode again to use

programmed keys.

4. Akko Macro V1.0 does not support simultaneous trigger, that is, pressing "AB" at the same time will trigger the

two keys in the order of A followed by B.

5. Akko Macro V1.0 does not support customized interval time, that is, the trigger interval between key A and key

B cannot be deﬁned and will follow the system's default trigger time.

Akko Macro V1.0

Macro Setup Instruction 2

Enter Macro Mode Start Macro Editor Macro Recording Fn + Custom Key

Exit Macro EditorExit Macro Mode

Fn + Custom Key

Record the next Key

Back to Default Mode Fn+Esc

Long Press Fn +Le� Win Fn+Esc (End Recording)(Press Keys to Store)

Clear Macro：

ot ”yek eht + NF“ sserp nac uoy ,rotide orcaM eht gniretne retfa ,denﬁed neeb sah yek a fI

clear its deﬁnition.

orcaM wen eht trats ot niaga”yek eht + NF“ sserp ,yek taht ezimotsuc-er ot tnaw uoy fI

recording after clearing its old deﬁnition.

Akko Macro V1.0

Macro Setup Instruction 3

Step 1: Press Fn + right Win for 3 seconds to enter the Macro mode.

Step 2: Press Fn + ESC to launch Macro editor.

.drocer ot ”A“ yek esoohc ew snaem sihT .A + nF sserP :3 petS

.”A“ fo noitinﬁed tnemecalper sa redro ni R ,A ,E ,G ,O ,K ,K ,A sserP :4 petS

.”A“ yek fo gnidrocer orcaM eht dne ot niaga A + nF sserP :5 petS

.”RAEGOKKA“ yalpsid lliw dapeton ni ”A“ gnisserp ,tniop siht tA

.gnidrocer orcaM eht trats ot B + nF sserp ,”B“ yek rof orcaM a etaerc ot tnaw uoy fI

Step 6: Press Fn + Esc to exit Macro editor.

Under the Macro mode, you can conﬁgure the keys and Macros you set.

Step 7: Press and hold Fn + Left Win for 3 seconds to exit the Macro mode and return to the default key deﬁnition.

”RAEGOKKA“ sa ”A“ enﬁeD :elpmaxE gnidroceR orcaM

Akko Macro V1.0 Calling Macros

Method A:

Enter the Macro mode by long pressing Fn+left Win. Then all keys will turn to pre-conﬁgured deﬁnitions with

locked Win key. Press Fn+Win to unlock Win key if necessary. In the Macro mode, you can use keys with

customized deﬁnitions.

Note, everytime you reboot or re-plugged the cable of the keyboard, the Macro mode will be turned oﬀ by

default and all keys will return to default deﬁnitions until you re-enter the Macro mode.

Method B:

Under the default key deﬁnition, you can also quickly call the customized content of speciﬁc keys through

“Fn+right Alt+the key that has been deﬁned through Macro”. Note that you must ﬁrst press Fn and then press

Alt to call the Macro.
