Akko 3068B Manuel utilisateur
用户手册
User Manual
Multi-modes
B三模
11
3068B Technical Specifications
Dimensions
Approximately
316*107*39mm
Weight Country of Origin Type
Approximately
0.64kg China Mechanical Keyboard
Key/Lighting Effects Customization
The keyboard can only be customized
with driver in wired mode
Multimedia Keys N-Key Rollover
YES YES
PBT Material
Keycap Connection
Bluetooth/USB/2.4Ghz
Interface
Type-C To USB
Battery Capacity
1800mAh
CtrlFn
Fn
12
3068B HotKeys
F1 - F10
F11
F12
Home
End
Fn+
1 - 0
-
=
PgUp
PgDn
=
Insert
Prtsc
Calculator
Mute
Decrease Volume
Fn+
I
P
C
M
<
=
Increase Volume
Fn+
>
=Swap W A S D
with ↑↓ ←→
w
13
3068B System Commands(Windows)
Fn
～
Fn
Fn
QO
Ctrl
~
Win
Press Fn and left Win key
Hold down Fn and press ～ key for 3S
Hold down Fn and press right Ctrl for 3S
Hold down Fn and press Q key for 3S
Hold down Fn and press O key for 3S
Lock Windows Key
Restore Factory Settings
Revert Ctrl into Menu (APP) key
Enter Windows system
Enter Mac system
14
3068B System Commands(Mac)
1
2
3
4
Decrease display brightness
Increases display brightness
Open mission control
Activate Siri
5
6
7
8
F5
F6
Skip back (Audio)
Pause/Play (Audio)
9
10
_
+
Skip forward (audio)
Mute
Volume down
Volume up
Note: The following features are realized by the combination of “Fn + corresponding key”
Right Alt
Left Win
Left Alt
Command
Option
Command
1 2 34567890
FnWin Alt Alt
_+
15
3068B Backlight Settings
Caps Lock
Battery Level Indicator
Lock Win
Fn
\[ ]
L
Del
Slower Animation
Faster Animation
Bright
Dim
Set animation direction to left
Set animation direction to Right
“↑”
“↓”
“←”
“→”
[
]
Fn+ =
In all lighting effects with RGB color mode,
set the backlight color to 7 single color with
RGB loop effect.
Fn+ =
\
Constant \ Breath \ Neon \ Wave \ Ripple \ Star \
Effect A \ Effect B \ Effect C \ Effect D \ Effect E \
Effect F \ Effect G \ Effect H \ Effect I \ Effect J \
Effect K \ Effect L\ Effect M \ Effect N
(20 Lighting Effects)
Del
LLight On / Off
16
3068B Bluetooth Feature Overview
Bluetooth device 1
Bluetooth device 2
Bluetooth device 3
2.4G wireless device
Wired mode
Fn+
E
R
T
Y
U
=
Short press to connect with slow
flashing green LED;
The lighting effect will be restored
when pairing succeeds.
Short press to connect with slow
flashing blue LED;
Press and hold to pair device with
fast flashing blue LED.
Fn
2.4G321
17
3068B Bluetooth Setup Instruction 1
1.Switch to Bluetooth mode
2.Set the Bluetooth profile
To help user recognize individual Bluetooth device, the keyboard is equipped with both Bluetooth 5.0 and 3.0 frameworks. The device
name under the Bluetooth 5.0 framework is Akko 3068BT-1 / Akko 3068BT-2 / Akko 3068BT-3 while the device name under Bluetooth 3.0
is AKK0 3068 BT3.0. Once the devices are paired through Fn + E/R/T, the system will by default memorize the last connected device before
you turn off the Bluetooth mode.
① When the keyboard remains unplugged, turn the back switch to ON. Then long press and hold Fn + E / R / T to start pairing with
Bluetooth devices. The keyboard will enter Bluetooth pairing mode when the blue LEDs under E / R / T keys flash quickly.
②When the Keyboard is plugged into the computer through USB interface, it will enter Bluetooth mode automatically without having to
push the switch on the back. Users can directly long press and hold Fn + E / R / T to enable Bluetooth pairing. The keyboard will enter
Bluetooth pairing mode when the blue LEDs under E / R / T keys flash quickly.
18
3068B Bluetooth Setup Instruction 2
4.Switch the Bluetooth device
After 4 Bluetooth devices have been paired with the keyboard, press Fn+E / Fn+R / Fn+T / Fn+Y for at least 3 seconds to quickly switch
between them.
5.Shut off the keyboard
Turn the power off on the keyboard back panel while unused for power saving;
If the keyboard remains unused for over 10 mins, it would go to sleep mode and you can activate it by pressing any key.
Note: The battery saver mode for Windows system would affect/delay the sleep activation time of the keyboard.
6.Reset the keyboard
If you forgot the specific paired front-end device or if there remains disorder in Bluetooth connection and communication, you'll need to
clear the computer’s Bluetooth cache by removing the 3068 keyboard from the list of connected device.
3.Bluetooth Pairing
The keyboard can be paired with PC, Pad, smartphone and other devices with Bluetooth turned on. When you first try to search Bluetooth
devices, two groups of device names shall appear with Akko 3098 BT3.0 (Bluetooth 3.0) and Akko 3098-1 (Bluetooth 5.0). Select a
Bluetooth group based on your preferences (Note: some devices can only search for the Bluetooth 5.0 group).
1.The key/lighting effects customization must be completed in wired mode with Akko driver.
2. In wired mode, the lighting effects can also achieve music rhythm effects with Akko driver.
3. Please download the Akko Cloud driver on our website.
4. Users can download the driver via en.akkogear.com
19
Key/Lighting Effects Customization Instruction
