AJAX FireProtect 2 Manuel utilisateur
FireProtect 2 (Heat/Smoke) Jeweller User
manual
Updated January 12, 2023
FireProtect 2 (Heat/Smoke) Jeweller is a wireless re detector with a built-in
siren. Intended for indoor installation. Detects smoke and temperature rise.
It is available in two modications: with sealed batteries (has SB in the name)
that run up to 10 years, and with replaceable ones (has RB in the name) that run
up to 7 years.
A list of compatible hubs and range extenders is .
The detector operates as part of the Ajax security system, communicating with
the hub via the secure radio protocol. The hub communication range is
up to 1,700 meters without obstacles.
available here
Jeweller
Buy FireProtect 2 (Heat/Smoke)
Versions of the detector with other sensor combinations are also available. All Ajax re
detectors are .
Functional elements
available here
1. The front panel of the detector with a . To activate the
button, press the central part of the panel.
Test/Mute button
2. SmartBracket mounting panel. To take off the panel, turn it
counterclockwise.
3. Device QR code and ID (serial number). Used for detector connection to the
Ajax security system.
4. . Triggers when trying to tear the detector off from the
surface or to take it off the mounting panel.
Tamper button
5. Detector certication information.
6. Power button.
Operating principle
FireProtect 2 (Heat/Smoke) is a wireless re detector designed for indoor
installation. Available in two modications:
7. First thermistor. Detects dangerous temperatures.
8. Green LED indicator.
9. Yellow LED indicator.
10. Red LED indicator.
11. Siren.
12. Second thermistor. Detects dangerous temperatu
13. Information about the detector’s end of life date.
14. Smoke chamber lid.
With sealed batteries. Such a detector has SB in its name. Sealed battery life
is 10 years. After the batteries are discharged, the detector should be
replaced with a new one.
With replaceable batteries. Such a detector has RB in its name. Pre-installed
battery life is 7 years. When the batteries are discharged, they can be
replaced with new ones.
How to replace FireProtect 2 RB batteries (Heat/Smoke)
00:00
00:12
The detector is equipped with a siren (piezoelectric buzzer) for sound
notication of alarms and events with a volume of up to 85 dB (at a distance of
3 m from the detector). The detector is always active and reacts to a re during
24/7, regardless of the system’s security mode.
FireProtect 2 is protected by two tampers. The rst tamper controls the removal
of the detector from the SmartBracket mounting panel: the detector reacts with
LED indication and sends notications to users in Ajax apps and the security
company monitoring station. The second tamper signals the removal of the
smoke chamber lid, which is located under the front panel of the detector.
Removing the smoke chamber lid is possible when the enclosure is fully disassembled.
The system detects this event as a malfunction. When the lid is removed, the detector
reacts with asound signal, and users and the security company receive a malfunction
notication.
The can respond to FireProtect 2 alarms and perform
user-dened actions using . For example, the
relay can turn on the ventilation system and emergency lighting when an alarm
occurs.
Operation without a hub
FireProtect 2 can be used without connecting to the Ajax hub. All you need is to
install the detector following this manual and turn it on.
In case of autonomous operation, the detector noties of re with a built-in siren
and LED indication only and does not send notications to the user’s
smartphone, Ajax Translator, or PRO Desktop. In this case, the
feature is not available.
Smoke sensor
FireProtect 2 detects smoke with a bispectral optical sensor. Inside the smoke
chamber, the sensor has blue and infrared LEDs which emit light at different
wavelengths. This technology allows the detector to determine the size of the
Ajax automation devices
automation scenarios WallSwitch
Interconnected
Fire Detectors Alarms
volatile particles inside the chamber and respond only to smoke, ignoring
vapour and steam.
The smoke chamber in FireProtect 2 is protected from dust, dirt, and insects.
Even if dust gets inside and settles, this does not threaten or impair re
detection. The optical system is designed to prevent non-volatile particles from
getting within the eld of both blue and infrared LEDs at the same time. So that
situation does not cause a false alarm.
The HazeFlow 2 software algorithm also protects against false alarms. When an
alarm is detected, the algorithm additionally processes the data received from
the detector and conrms the alarm.
Temperature sensor
Two built-in class A1 thermistors detect a rapid rise and exceeding the
temperature threshold in FireProtect 2. The thermistors of this class notify of
alarms when a rapid temperature rise or static temperature is detected in the
range of +54°C to +65°C.
The thermistors are mounted outside under the front panel of the detector. This
allows you to respond to threats faster than when the sensors are inside the
detector enclosure.
FireProtect 2 will reports that the temperature threshold has been exceeded as
soon as its value exceeds +64°C. The detector will reports a rapid temperature
rise if the indicator increases by 10°C within one minute. If the temperature
indicator rises sharply by 20°C or more, the detector signals immediately.
Test/Mute button
The Test/Mute button is located under the front panel of the detector. This is a
mechanical button. Тo activate it, press lightly on the central part of the front
panel with your hand or a suitable item if the detector is installed in a hard-to-
reach place. For example, you can do this with a mop handle.
The button performs several functions:
In normal mode, it starts the .detector self-test
Interconnected Fire Detectors Alarms
All re detectors of the FireProtect 2 product line support the Interconnected
Alarm feature. This feature activates the built-in sirens of all re detectors in the
system as soon as at least one of the re detectors has detected an alarm.
Sirens of FireProtect 2 detectors are activated within 20 seconds after an alarm
is detected. The sirens of and are activated during
the detector ping interval set in the Jeweller(or Jeweller/Fibra) settings, but no
later than 60 seconds after.
The detectors have different sound and LED indications of alarm
types to make it easier for users to distinguish between them. In case of
interconnected alarm, all FireProtect 2 detectors indicate exactly the alarm type
detected by the initiating detector. Instead, and
detectors noties all types of alarms with the same sound.
Sending events to the monitoring station
The Ajax security system can transmit events and alarms to the
monitoring app as well as the Central Monitoring Station (CMS) via SurGard
(Contact ID), SIA DC-09 (ADM-CID), ADEMCO 685, and other protocols. The list
of supported protocols is .
Addressability of Ajax devices allows you to send to the PRO Desktop and to the
CMS not only events but also the type of the device, the name given to it, virtual
room, and security group. The list of transmitted parameters may differ
depending on the CMS type and the selected communication protocol.
The ID and detector loop (zone) number are available in the detector .
In case of an alarm, it mutes the detector alarm or of
all re detectors in the system.
Interconnected Alarm
FireProtect FireProtect Plus
FireProtect 2
FireProtect FireProtect Plus
How to set Interconnected Fire Detectors Alarms
PRO Desktop
available here
Which CMSs Ajax connects to
States
Adding to the system
Before adding a device
A can connect the device to the hub.
To connect to the hub, the detector should be within the coverage area of the
hub radio network. To operate via a , rst connect
the detector to the hub and then to the range extender. You can do this in the
range extender settings in Ajax apps.
How to connect FireProtect 2 to a hub
1. Install the .Ajax app
2. if you don’t have one.Create an account
3. Add a to the app. Set the required settings
and create at least one .
hub compatible with the detector
virtual room
4. Make sure that the hub is on and has Internet access via Ethernet, Wi-Fi,
and/or mobile network. You can do this in the Ajax app or by looking at the
LED indicator of the hub: it should light up white or green.
5. Make sure that the hub does not start updates and that it is disarmed by
checking the status in the Ajax app.
PRO or a user with system setup rights
radio signal range extender
1. Open the .Ajax app
2. Select the hub if you have several of them or if you are using the
.
Ajax PRO
app
3. Go to the Devices tab. Press Add Device.
4. Enter the name of the device.
Once connected, FireProtect 2 will appear in the hub device list in the Ajax app.
Device status update depends on the ping interval set in the Jeweller or
Jeweller/Fibra settings. The default value is 36 seconds.
FireProtect 2 works with only one hub. When connected to a new hub, the
detector stops transmitting data to the old hub. Once added to a new hub,
FireProtect 2 is not removed from the list of devices of the old hub. This must be
done manually in Ajax apps.
Indication
5. Scan the QR code or enter the ID manually. QR code is located on the rear
part of the enclosure (under the mounting panel) and on the device
packaging. The device ID can be found below the QR code.
6. Select the and security group (if the is enabled).virtual room group mode
7. Click Add; the countdown will begin.
If the maximum number of devices is added to the hub, when adding the one, you
will get a notication of exceeding the device limit. The number of devices that you
can connect to the hub depends on the .central unit model
8. Turn on the detector by holding the power button for 3 seconds. The hub
connection request is sent only if the detector is enabled. If the detector
fails to connect to the hub, try again in 5 seconds.
The detector cannot connect to the hub if they operate on different radio
frequencies. The radio frequency range of the devices may vary by the region of
sale. Please contact for information on the operating frequency
range of your devices.
technical support
LEDs and the built-in siren of the detector can report alarms, as well as some
detector states.
LED indication Sound indication Event Notes
The red LED blinks
continuously.
The siren beeps in
time with the LED
indication.
Alarm by:
The detector stops
alarming as soon as
its sources are
eliminated.
Also, you can mute
the alarm by pressing
the
or in the Ajax
app.
The LED and sound
indications resume if
the source of the
alarm is still present
after the muting timer
(10 minutes) has
expired.
The red LED blinks
every 8 seconds. No. Muted alarm.
The detector stops
alarming as soon as
its source is
eliminated.
The red LED blinks 2
times in a row. No. Restore after alarm.
If the source of the
alarm is removed, the
detector is restored
automatically.
The yellow LED lights
up for 1 second. No.
Tamper alarm.
The detector is
removed from the
SmartBracket
mounting panel.
smoke;
rapid temperature
rise;
temperature
threshold
exceeded.
Test/Mute
button
00:00
00:06
The green LED lights
up for 1 second. No.
The detector is
installed on the
SmartBracket
mounting panel.
Turns on when the
tamper is triggered.
Green, yellow, and red
LEDs light up in turn,
then go out.
No. Turning the detector
on.
To turn off the
detector, hold the
power button for 1
second.
Green, yellow, and red
LEDs light up at the
same time, then go
out in reverse order.
No. Turning the detector
off.
To turn off the
detector, hold the
power button for 2
seconds.
The green LED is
permanently on. No. Connection to the hub
in progress.
The indication turns
off after the detector
connection to the hub.
The green LED blinks
6 times in a row.No. No.
The detector has been
removed from the
hub.
The indication turns
on when the detector
receives information
that it has been
removed from the
hub.
The green LED blinks
once per minute. No. Detector power
supply is OK.
The indication is
present when the
detector is on and the
tamper state is OK
(the detector is
installed on the
SmartBracket
mounting panel).
There is no indication
when the detector
switches to the
mode.
The yellow LED blinks
2 times in a row every
minute.
The siren beeps 2
times in time with the
LED indication every
minute.
Malfunction is
detected.
All malfunctions are
displayed in the
detector in
Ajax apps. Fields with
malfunctions are
highlighted in red.
If the detector needs
to be repaired, contact
Jeweller Signal
Strength Test
States
Autres manuels pour FireProtect 2
1
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels AJAX Capteur de sécurité
AJAX
AJAX MotionProtect Manuel utilisateur
AJAX
AJAX LeaksProtect Manuel utilisateur
AJAX
AJAX ReX Manuel utilisateur
AJAX
AJAX CombiProtect Fibra Manuel utilisateur
AJAX
AJAX FireProtect Manuel utilisateur
AJAX
AJAX GlassProtect Manuel utilisateur
AJAX
AJAX MotionCam Jeweller Manuel utilisateur
AJAX
AJAX DoorProtect Manuel utilisateur
AJAX
AJAX MotionProtect Manuel utilisateur
AJAX
AJAX MotionProtect Manuel utilisateur
AJAX
AJAX DoorProtect Plus Manuel utilisateur
AJAX
AJAX CombiProtect Manuel utilisateur
AJAX
AJAX MotionProtect Plus Manuel utilisateur
AJAX
AJAX GlassProtect Manuel utilisateur
AJAX
AJAX Fire Protect Manuel utilisateur
AJAX
AJAX GlassProtect Manuel utilisateur
AJAX
AJAX MotionProtect Manuel utilisateur
AJAX
AJAX LeaksProtect Manuel utilisateur
AJAX
AJAX FireProtect Manuel utilisateur
AJAX
AJAX GlassProtect Manuel utilisateur
