Please mount the two halves cylinder on the cable between the Display of the
air condition to the VAV SYSTEM controller.
The two halves cylinder should close on the round cable with the snaps on
the sides.
Air condition with Round type - 8 DIN connector.•
This original cable is used to connect between the Air condition display and
the air condition controller.
When using the Zone Control system VAV SYSTEM , this cable should be
connected between the Air condition Display to the VAV SYSTEM controller.
Please connect to the plug marked “Display”.
At the box of the VAV SYSTEM controller
you will nd two halves of a cylinder.
(Black color) these are parts of cable lter.
Please mount the two halves cylinder
on the original cable between the Display
of the air condition to the VAV SYSTEM
controller.
The two halves cylinder should close on the
round cable with the snaps on the sides.
Enter the plug with the arrow mark pointing
up to the socket at the VAV SYSTEM
Controller.
AIR COND. IR RECEIVER
MEGA
TOOL
(See connection schematic at page 5).
Connection Cable between the controller and air
condition controller.
It is possible to receive two different types of
connectors on this cable.
Square Type - ePAD connector.Round type - 8 DIN connector.
AIR COND. IR RECEIVER
MEGA
TOOL
Square Type - ePAD connector.•
When using the Square Type ePAD connector, use the original cable of the air
condition to connect between the VAV SYSTEM and the air condition controller.
At the VAV SYSTEM side plug it to the connector marked “Air Condition “.
