Airlink101 AKVM-S32 Manuel utilisateur

Ver. 1A

Quick Installation Guide

Model#AKVM-S32

Section 1

The AKVM-S32 is a 2-port PS/2 type KVM switch that

comes with two sets of 3-in-1 combo KVM cables. It

enables users to access, control, boot, and reboot two

computersusingonlyonekeyboard,video monitor,and

mouse.Its slim-sized design offersmoreportabilityand

convenienceto users thanconventionalKVM switches.

Introduction

Section 2

Beforeconnecting any cable, please makesure all of your

computers and their peripherals have been powered off.

Otherwise, the KVM switch may not be set up properly.

Installation

Step 1 Make sure all the computers that are to be

connected to the KVM switch and their peripherals

arepowered-off. Ifnot, power them off beforeyou

proceedwiththefollowing steps.

Step 2 Connectthe shared keyboard,monitor,and

mouse to the main KVM unit. See Fig. 1.1

Fig 1.1

Step 3 Connect each of your computers to the KVM

switchusingtheprovided3-in-1comboKVMcables.

SeeFig.1.2

Step 4 Power up the connected computers one by

one.After the computers are powered up, the

keyboardandmousewillbe recognized and you can

begin operating the KVM switch.

Operations

There are two methods to select a specific computer:

Usingthepush button or the hotkey sequence.

Hotkey sequence = ScrLk + ScrLk + Command key

ThetwoconsecutiveScrLk keyshouldbepressed

within2secondsandthefollowingcommandkey(s)

should also be pressed within 2 seconds. Otherwise,

thehotkeysequencewillnotbevalidated.

FordetailedHotkey sequences and their correspond-

ingfunctions,pleasereferto the Quick Reference

Chart on back.

Push Button

The push button lets you directly switch between the

computers. Simply press the button on the KVM unit

to select the computer.

Technical Support

Email:[email protected]

TollFree:1-888-746-3238

Website:www.airlink101.com

ContinueonBack

Hotkey Sequence

The hotkey sequence consists of three specific

keystrokes pressd on the keyboard.

Section 3

Section 4

Fig 1.2

KVM Side PC Side

You can use individual standard keyboard, mouse

and video cables to extend the cable distance, but

depending on the type of cables you use, the

maximum cable distance is limited to 5 ~ 7 meters

(15.5~ 23 feet).

Command

Quick Reference Chart

Select PC

Hotkeys Front-Panel Button Description

ScrLk + ScrLk + (channel #) Selecttheactivechannel

Next lower channel ScrLk + ScrLk + (up arrow) Selectthelowerchannel

Next higher channel ScrLk + ScrLk + (down arrow) Press the push button to

rotatethroughthe channel Select the higher channel

Reset KVM

Autoscan

StopAutoscan

ScrLk + ScrLk + End

ScrLk + ScrLk + S

Any key on keyboard

Reset the KVM Switch

Autoscanthrough every connected channel

TerminateAutoscan activity

1: Press 1 or 2 for the for the channel #

Copyright©2006 AirLink101™All rightsreserved. AirLink101,the stylizedAirLink101logo,specificproduct designations,and allother wordsand logosthat areidentified astrademarks and/orservicemarksare,unlessnotedotherwise, thetrademarks andservice marksof AirLink101.All

otherproduct orservice namesare theproperty oftheir respectiveholders. AirLink101products areprotected undernumerousU.S. andforeign patentsand pendingapplications, maskwork rights,and copyrights.

Previous PC channel ScrLk + ScrLk + (Backspace)

Autoscan with

programmable delay

time ScrLk + ScrLk + (x) 2Autoscan with a user-defined delay time

within a range of 5 ~ 99 seconds

2: x = 0 ~ 9

1 .. 10” ; 2 .. 20” ; 3 .. 30” ; 4 .. 40” ; 5 .. 50”

6 .. 60” ; 7 .. 70” ; 8 .. 80” ; 9 .. 90” ; 0 .. 99”
