AIPTEK Pocket DV2 Manuel utilisateur

Installation GuideInstallation GuideInstallation GuideInstallation Guide

Contents

Specifications

Notice

Bundled Accessories

Your Camera

Using your Camera

Recording and Taking Pictures

A/V out Mode

TV Playback

Bundled Software

Software Installation

Hardware Installation

Troubleshooting

AIPTEK Service

Video Conference

Downloading Files from Camera to

Your PC

Battery Installation

Strap

Tripod (Optional)

External Memory/ CF Card (Optional)

Camera Parts

How to Enter MENU on LCD Display

Mode Selecting

Focus

How to Hold your Camera

Voice Recording

Playback Movies, Still Pictures and Recorded

Audio Files

Image Resolution & Quality

AVI Movies, Still Pictures and Voice

Recording Storage Capacity

Other Functions

Power

For Best Results

Specifications

Sensor Type 1.3M CMOS

Effective Pixels 1.3M (1280x1024 pixels)

Internal Memory 16MB built-in SDRAM

( 6MB are available for capture,

2M is Hardware Interpolated)

External Memory Built-in CF Card Slot

Maximum 512 MB

1.4" 4,096 color STN LCD Display

Main Functions

- Digital Video Camcorder :

QVGA (320 x 240 pixels) / 10fps

- Digital Still Camera : 2Mega (1600x1200 pixels) /

SXGA (1280 x 1024 pixels) /

VGA (640 x 480 pixels)

- Video Conference :

VGA 640 x 480 pixels / 10 fps

QVGA 320 x 240 pixels / 24 fps

QSIF 160 x 120 pixels / 30 fps

- Digital Voice Recorder :

Supports AV output

Focus Macro 40cm

Auto Exposure & Auto White-Balance

Self Timer 10 - second Self Timer

Power Saving Auto power off if idle over 60

seconds

Built-in Microphone & Speaker

Battery: AA x 2 ( Alkaline)

USB port

Dimension : 3.3" x 2.7" x 1.6"

about 20 min. ( When not

using CF Card)

System Requirements

Microsoft Windows 98SE / 2000 / ME / XP

Pentium II 266 MHz ( or equivalent )

64MB RAM (128MB recommended)

Video Card with 4 MB of RAM for minimum 16bit

high color display.

4 X speed CD-ROM

An available

Direct X8.0 or above

RAM

USB port

Notice

2Notice

1. Do not drop, puncture or disassemble the camera.

2. Remove batteries during long periods between use.

3. Avoid all contact with water and dry hands before

using.

4. Do not expose the camera to high temperature or

leave it in direct sunlight.

5. Avoid pressing hard on the camera body.

Camera USB cable

AV-out cable Strap

2 x AA Alkaline batteries

CD driver User guide

Bundled Accessories

Tripod (Optional)

Your Camera

Camera Parts

(1) Shutter

(2) Lens

(5) Microphone

LCD display

(8) LED light

USB port

(12) CF Card slot

(13) AV-out port

(14) Eject ( CF Card)

(15) Strap-holder

(16) Speaker

(17) Battery cover

(18) Tripod port

(19) LCD Backlight control

(3) Focus

(4) Mirror

(6) View finder

(7)

(9) Record button

(10) MENU control

(11)

(1)

(2)

(3)

(4)

(5)

(6)

(7)

(8)

(9)

(10)

(11)

(12)

(13)

(14)

(15)

(16)

(17)

4Your Camera

(18)

(19)

Battery Installation

Your camera runs on two AA alkaline batteries.

High performance batteries are recommended for

this camera for maximum battery life.

Strap

Attach the carrying strap for convenience and

safety.

Your Camera

External Memory/ CF Card (Optional)

In addition to 128 Mbits built-in SDRAM memory,

your camera can store data on Compact Flash

Cards ( 8MB-512MB). Insert you CF Card as

shown. Files will be automatically stored on the

CF Card after you've inserted the CF Card. EJECT

CF CARD

Your Camera

Tripod (Optional)

Use a tripod to minimize camera movement and

ensure optimal image quality, especially while

shooting longer movies, self-portraits or video

conferencing.

Tight

Loose

Your Camera

Using Your Camera

Opening LCD panel

Turning on your camera/off

Press and hold the MENU control for 3

seconds to turn on your camera.

Manual shut-off: press the MENU control for 3

seconds. If you can't turn off your camera,

please make sure you exit the MENU.

Auto shut-off: your camera will automatically

shut off after 60 seconds of inactivity.

Swing the LCD panel 90 away from the camera

body. Be careful not to over extend the panel.

90 °

Using Your Camera 7

Backlight
