Agilent Technologies

Agilent 3200P

pH Meter

pH 计

User Guide

用户手册

⋠

⋠࡬







⋠

⋠࡬







3200P pH Meter User Guide

Notices

No part of this manual may be reproduced in

any form or by any means (including elec-

tronic storage and retrieval or translation

into a foreign language) without prior agree-

ment and written consent from Agilent

Technologies, Inc. as governed by United

States and international copyright laws.

Manual Part Number

5973-1775

Edition

First edition, March 2012

Printed in China

Agilent Technologies, Inc.

412 Ying Lun Road

Shanghai 200131 P.R. China

Warranty

The material contained in this docu-

ment is provided “as is,” and is sub-

ject to being changed, without notice,

in future editions. Further, to the max-

imum extent permitted by applicable

law, Agilent disclaims all warranties,

either express or implied, with regard

to this manual and any information

contained herein, including but not

limited to the implied warranties of

merchantability and fitness for a par-

ticular purpose. Agilent shall not be

liable for errors or for incidental or

consequential damages in connec-

tion with the furnishing, use, or per-

formance of this document or of any

information contained herein. Should

Agilent and the user have a separate

written agreement with warranty

terms covering the material in this

document that conflict with these

terms, the warranty terms in the sep-

arate agreement shall control.

Technology Licenses

The hardware and/or software described in

this document are furnished under a license

and may be used or copied only in accor-

dance with the terms of such license.

Restricted Rights Legend

U.S. Government Restricted Rights. Soft-

ware and technical data rights granted to

the federal government include only those

rights customarily provided to end user cus-

tomers. Agilent provides this customary

commercial license in Software and

technical data pursuant to FAR 12.211

(Technical Data) and 12.212 (Computer Soft-

ware) and, for the Department of Defense,

DFARS 252.227-7015 (Technical Data -Com-

mercial Items) and DFARS 227.7202-3

(Rights in Commercial Computer Software

or Computer Software Documentation).

Safety Notices

CAUTION

A CAUTION notice denotes a

hazard. It calls attention to an oper-

ating procedure, practice, or the

like that, if not correctly performed

or adhered to, could result in

damage to the product or loss of

important data. Do not proceed

beyond a CAUTION notice until the

indicated conditions are fully

understood and met.

WARNING

A WARNING notice denotes a

hazard. It calls attention to an

operating procedure, practice, or

the like that, if not correctly per-

formed or adhered to, could result

in personal injury or death. Do not

proceed beyond a WARNING

notice until the indicated condi-

tions are fully understood and

met.

安捷伦科技（上海）有限公司

上海市浦东新区外高桥保税区

英伦路 412 号

系电话：（800）820 3278

3200P pH Meter User Guide 3

Contents

1 Installation 5

Tools and Components Needed for Installation 6

Installing the 3200P pH Meter 7

Installing the Power Adaptor 9

Installing the Ground Line 10

Installing the Electrochemical Data Collecting Software 10

More Information 10

2 Operation 11

Introduction 12

Safety Information 14

Agilent Customer Portal 15

Term Definitions 16

Features 17

Specifications 18

The Operating Panel 19

Display 19

Keypad 19

Instrument control 21

Setting Up the pH Meter 22

To start up the 3200P pH Meter 22

Accessing setup parameters 23

To manually set the solution temperature 27

To set up the system (System Setup) 29

To select the display language 31

To set the meter to turn off automatically (Auto Power Off) 31

43200P pH Meter User Guide

Using the pH Meter 32

To prepare an electrode for use 32

To adjust mV zero 33

To calibrate pH electrode (Calib pH EC) 36

To measure pH value 39

To measure mV value 40

To measure temperature 40

To turn off the 3200P pH Meter 40

Storing Data 41

To delete saved data 41

To output data 41

Viewing Parameters During Measurement 42

To view saved data 43

To view last calibrated data 45

Software Operation 47

To install the software 47

To run software 47

3 Troubleshooting and Maintenance 49

Troubleshooting Common Problems 50

General Troubleshooting Procedure 52

Check the temperature measurement 52

Check the potential (mV) value 53

Check the pH value 53

Restore factory default settings 54

Meter Self-Diagnostics and Messages 56

Severe errors 56

Error warning 57

Maintenance 59

Electrode cleaning 59

Electrode storage 59

Agilent Technologies

Agilent 3200P pH Meter

User Guide

Installation

Tools and Components Needed for Installation 6

Installing the 3200P pH Meter 7

Installing the Power Adaptor 9

Installing the Ground Line 10

Installing the Electrochemical Data Collecting Software 10

More Information 10

Use the tools and accessories shipped with 3200P pH Meter

during installation.

63200P pH Meter User Guide

1 Installation

Tools and Components Needed for Installation

Agilent provides the special tools needed for installation. You

can find the following parts in the shipping case of the pH

Meter (Meter Kit).

•Electrode holder (G4389A)

•Electrode, for example P3211 pH combination electrode

(5190- 3988)

•Power adapter (5185- 8389)

Installation 1

3200P pH Meter User Guide 7

Installing the 3200P pH Meter

Open the meter kit package case. Remove the pH Meter,

multifunction electrode holder, and other parts.

The sockets for the pH electrode and ATC probe are on the

back panel of the meter. Insert the connectors of the pH

electrode and ATC probe (5190- 3998) into their respective

sockets. See Figure 6 on page 13. Run the electrode cables

along the electrode holder as shown in Figure 2 on page 8.

Figure 1 Installing the Electrode holder

Large nut

Small nut

Flexible arm

Small nut

Electrode holder

Large nut

Electrode holder base

Setscrew

83200P pH Meter User Guide

1 Installation

Figure 2 Installing the electrodes

Installation 1

3200P pH Meter User Guide 9

Installing the Power Adaptor

The universal power adapter that is included with the meter

is the only power adapter recommended for use with this

unit.

The external electrical power adapter is rated at 100 to

240 VAC, 1 A, 50/60 Hz.

This power adaptor provides a plug converter which

supports several kinds of plugs. Choose the appropriate

power plug. Connect the output plug of the power adapter to

the power input on the meter. A click will be heard when

the plug is properly engaged.

Figure 3 Installing the Power Adaptor

10 3200P pH Meter User Guide

1 Installation

Installing the Ground Line

The meter ships with an optional ground line. During use, if

another device (such as a constant temperature bath) causes

electrical interference and an unstable reading, install the

ground line. Connect one terminal of the ground line to the

meter ground socket ( ) and the other terminal to the

interference source.

Installing the Electrochemical Data Collecting Software

The optional G4390A software provides communications

between the meter and a computer. To input data to a

computer, install the Electrochemical Data Collecting

Software on a computer. Connect the computer to the meter

with a USB cable. See the G4390A software documentation

for more information.

If not using the G4390A software, Agilent provides

downloadable data printing software on the Agilent

Customer Portal (see “Agilent Customer Portal ” on

page 15). To use this software, download it from the portal

and install it. Then connect the meter to the PC using the

USB cable. Refer to the data printing software

documentation for more information

More Information

For more information, visit the Agilent website at

http://www.agilent.com/chem. See also the instructions

provided with each electrode.
