Agilent Technologies E5900B Manuel utilisateur

User’s Guide

Publication number E3454-97006

February 2002

ll Rights Reserved

For Safety information, Warranties, and Regulatory information,

see the pages behind the index.

Emulation for the

PowerPC 400/600/700

2 Agilent Technologies Emulation for the PowerPC 400/600/700

Agilent Technologies E 900B Option 060/070

Emulation Probe—At a Glance

This manual describes how to set up:

• an emulation probe

• an emulation module

• an emulation migration

The emulation probe provides a low-cost way to debug embedded software for

PowerPC 400/600/700 family microprocessors. The emulation probe lets you

use the target processor’s built-in debugging features, including: run control,

emulation probe to debug code running on the target system.

The emulation probe can be controlled by a debugger on a host computer or

by the Emulation Control Interface on an gilent 16700-series logic analysis

system. The emulation probe communicates with a host computer or logic

analysis system via L N.

E5900B Emulation Probe

Host

Computer

E5900B

Emulation Probe

LAN Cable

Target System

Power Supply

Agilent Technologies Emulation for the PowerPC 400/600/700 3

E5901B Emulation Module Kit

The gilent E5901B emulation module kit includes the E5900B emulation

probe, the E5901B emulation module, and other items listed on page 22. The

gilent E5901B emulation module plugs into your gilent 16700-series logic

analysis system frame. It provides power, cross triggering, and limited

communication for the E5900B emulation probe through the module/probe

interconnect cable. The logic analysis system communicates with the target

system through the L N connection to the E5900B emulation probe.

E5902B Emulation Migration Kit

The emulation migration includes the parts needed to use an emulation probe

for a new processor family.

Emulation Solution

If you have an E9xxxB emulation solution, refer to the appropriate Logic

Analysis Support User’s Guide (or Solutions User’s Guide) for information

on how to connect the analysis probe, then return to this book for information

on connecting the emulation probe.

Logic Analysis

System

Target System

E5901B Emulation Module

E5900B Emulation Probe

Module/Probe Interconnect Cable

LAN Cable

4 Agilent Technologies Emulation for the PowerPC 400/600/700

In This Book

Emulation Probe

Processor supported Product ordered Includes

PPC401 (all), PPC403 (all),

PPC405 (all), NPe405H,

NPe405L, PPC440A4,

PPC440GP.

PPC603e rev. 1, 3, 4, 5;

MPC603e; PPC603ev rev. 2,

12; PPC603e2; MPC603P;

MPC603ec; MPE603R;

MPC603ei.

PPC740/50, MPC740/50,

PPC750M, MPC740P/50P,

MPC745/55, PPC750CX,

PPC750CXe.

E5900B Option #060

E5900B Option #070

E5900B #060 emulation probe, cables,

software, and manual.

E5900B #060 emulation probe, cables,

software, and manual.

E5900B #070 emulation probe, cables,

software, and manual.

Emulation Module Kit

Processor supported Product ordered Includes

PPC400-series

(Versions listed above.)

PPC600-series

(Versions listed above.)

PPC700-series

(Versions listed above.)

E5901B Option #060

E5901B Option #070

E5901B emulation module, E5900B #060

emulation probe, cables, software, and

manual.

Emulation Migration Kit

Processor supported Product ordered Includes

PPC400-series

(Versions listed above.)

PPC600-series

(Versions listed above.)

PPC700-series

(Versions listed above.)

E5902B Option #060

E5902B Option #070

Target board adapter, front panel, tool kit,

cables, software, and manual.

Agilent Technologies Emulation for the PowerPC 400/600/700 5

The E5900B emulation probe has been programmed with firmware at the

factory.

The firmware is a driver that lets the emulation probe communicate with a

certain family of processors. Consult the chart on page 136 to determine

whether the factory-loaded firmware is compatible with your target processor.

If not, you will need to update the firmware as described in Chapter 10,

“Updating Firmware,” beginning on page 135.

In this manual "PowerPC" is used to refer to both the IBM PPC family of

PowerPC processors and the Motorola MPC family of PowerPC processors.

Emulation Solution

Processor supported Product ordered Includes

PPC603e rev. 1, 3, 4, 5;

MPC603e; PPC603ev rev. 2,

12; MPC603ei.

E9487B Option #001 E5901B emulation module, E5900B #060 or

E5900B #070 emulation probe, cables,

software, and manual, plus analysis

software as described in the Logic Analysis

Support User’s Guide.

PPC603e rev. 1, 3, 4, 5;

MPC603e; PPC603ev rev. 2,

12.

E9487B Option #002 Everything in the E9487B Option #001 and

the 240-pin PQFP analysis probe.

PPC740/50, MPC740/50,

PPC750M, MPC740P/50P,

MPC745/55, PPC750CX,

PPC750CXe.

E9486B Option #001 E5901B emulation module, E5900B #070

emulation probe, cables, software, and

manual, plus analysis software as

described in the Logic Analysis Support

User’s Guide.

Contents

gilent Technologies E5900B Option 060/070 Emulation Probe—

t a Glance 2

In This Book 4

1Overview 17

Setup Flowchart 19

gilent E5900B Emulation Probe 20

Equipment supplied 20

Minimum equipment required 20

gilent E5901B Emulation Module Kit 22

Equipment supplied 22

Minimum equipment required 22

gilent E5902B Emulation Migration Kit 24

Equipment supplied 24

Minimum equipment required 24

To connect the emulation probe to a power source 26

Connection Sequence 27

To power on the system 27

To power off the system 27

dditional Information Sources 28

Contents

2Designing a arget System for an Emulation

Probe 29

Target System Requirements 30

PowerPC JT G interface connections and resistors 34

3Connecting the Emulation Probe

to a LAN 37

To choose a point-to-point or site L N connection 38

Connecting the Emulation Probe to a Site L N 40

To obtain an IP address 41

To configure L N parameters using a serial connection 42

To configure L N parameters using DHCP 45

What is DHCP? 46

How does the emulation probe use DHCP? 46

How does DHCP interact with other methods of setting L N parameters? 46

To configure L N parameters using a logic analysis system without an emula-

tion module 47

To configure L N parameters using a logic analysis system with an emulation

module 48

Setting up a Point-to-Point Connection 49

To set up a point-to-point connection with an emulation module 49

To set up a point-to-point connection without an emulation module 50

Verifying L N Communications 51

To verify L N communications using ping 51

To verify L N communications using telnet 52

Contents

4Installing the Emulation Module 53

To install the emulation module in an gilent 16700-series logic analysis sys-

tem or expansion frame 55

To connect the E5901B emulation module to the E5900B emulation

probe 57

5Installing Software on a 16700-Series Logic

Analysis System 59

Installing and loading 60

What needs to be installed 61

To install the software from CD-ROM 62

To list software packages which are installed (16700) 63

6Connecting the Emulation Probe to Your arget

System 65

To connect the emulation probe to the target system 67

7Configuring the Emulation Probe 69

What can be configured 71

Using the cf Commands 72

Contents

Configuration items 74

Default configuration 74

To configure the processor type 74

To configure the processor version using the procs command (PowerPC 740P

and 750P) 75

To configure the JT G test clock (TCK) speed (communication speed) 76

Configuring the Emulation Probe for Maximum Performance 77

To configure restriction to real-time runs

( ll processors) 78

To configure reset operation 79

To configure reset vector address

(PowerPC 603ei, 745, 755) 81

To configure power on reset operation

(PowerPC 745, 755) 81

To set the freeze timers option

(PowerPC 400) 82

To enable branch folding

(PowerPC 400) 83

To enable or disable address validation

(PowerPC 400) 84

To enable fast memory loads

(PowerPC 400) 85

To configure the memory model

(PowerPC 603ei, 745, 755) 86

To configure the memory read operation

(PowerPC 400, 603e, 603ev, 603e2, 603P, 603ec, 603R, 740, 750, 750M, 740P,

750P) 87

To configure data memory write operations

(PowerPC 400, 603e, 603ev, 603e2, 603P, 603ec, 603R, 740, 750, 750M, 740P,

750P) 88

To configure instruction memory write operations

(PowerPC 400, 603e, 603ev, 603e2, 603P, 603ec, 603R, 740, 750, 750M, 740P,

750P) 89

To set the memory read delay clock cycles

(PowerPC 603ei, 745, 755) 91
