Aether Biomedical Zeus Manuel utilisateur
Instruction
for Use
Version 1.0
For Qualied Personnel
THE POWER IN YOUR HAND
Aether BiomedicalZeus Brochure
1
INTRODUCTION............................................................................................4
Aether Biomedical......................................................................................4
Zeus.........................................................................................................................4
INTENDED USE.............................................................................................5
SCHEME OF ZEUS WITH DIMENSIONS.............................................7
BOX CHECKLIST............................................................................................9
ZEUS GRIPS....................................................................................................9
Opposed Grips..............................................................................................10
Non-opposed Grips..................................................................................13
Moving the thumb....................................................................................16
Changing grips.............................................................................................17
THE FIRST USE OF THE HAND.............................................................19
Power Switch Button.............................................................................19
Charging the battery..............................................................................20
Checking battery status.......................................................................22
INTERFACE SOFTWARE.........................................................................23
CONTROL METHODS...............................................................................24
TAKING CARE OF YOUR PROSTHESIS.............................................25
Warranty and customizability.........................................................25
Cleaning............................................................................................................26
Table of Contents
Aether Biomedical Zeus Brochure
21
Maintenance................................................................................................26
SAFETYANDWARNINGS.....................................................................27
Hand...................................................................................................................27
Battery...............................................................................................................28
TECHNICALINFORMATIONS..............................................................30
Electrodes......................................................................................................30
Batteries...........................................................................................................31
Power Button.............................................................................................32
ADDITIONALINFORMATIONS...........................................................32
Warranty..........................................................................................................32
Other information...................................................................................33
Troubleshooting........................................................................................34
Regulatory Compliance.....................................................................35
SYMBOLS.....................................................................................................36
EMCLABELLINGINFORMATION.......................................................38
Date of the last update of this
Instruction for user: 01-06-2020
»We highly recommend reading this document carefully before
using the prosthesis.
»This document contains information about the proper and
safe use of the prosthesis.
»We highly recommend keeping this document for the whole
period of using prosthesis.
»If you have any questions about the product please contact us
on info@aetherbiomedical.com
2
Aether BiomedicalZeus Brochure
3
Introduction
Aether Biomedical
Zeus
Aether Biomedical is a medical robotics company focused on biosi-
gnal processing and bionic limbs for upper limb amputees. Since
our founding, our team has expanded to represent diverse specialties
such as engineering, medicine, design and strategy. We want to shake
up the world of medical technology.
Our products are engineered with precision, designed to exceed
global standards and are fundamentally driven by human need. Our
solutions are conceived and developed in house and scaled externally
with the help of manufacturers and distributors.
Zeus is a multi action bionic limb combining ease of control with an
elegant, robust design. The ngers and thumb provide a rm grasp
to perform everyday tasks with ease. The ngers stall individually,
allowing them to conform to the shape of the object, regardless of
shape or size.
This document will give you important information for the correct use
of and how to look after your prosthesis. Read this document carefully
before tting Zeus.
Zeus is designed for mild to moderate activities. Please avoid use in
situations with heavy loads, vibrations or impacts.
Aether Biomedical Zeus Brochure
43
Intended Use
Zeus is recommended for:
»Adults only,
»Both genders,
»Age 18-65 while starting to use the prosthesis - older people
already using bionic limb are in the target group,
»People with circulation or respiratory problems after consulting
their physician.
Zeus is not recommended for:
»Children,
»women during pregnancy, unless they were already wearing a
similar device.
»People with serious mental disorders.
Zeus is an external prosthetic hand intended to be used with other
appropriate upper limb components to form a complete arm
prosthesis, to be tted only by qualied and certied clinicians. It
should be used only by upper limb amputees and by people with
congenital absence of an upper limb (forearm). Zeus is suitable for 3
amputation levels: below-elbow, above-elbow and shoulder disarti-
culation, but the nal decision whether Zeus should be used belongs
to qualied medical personnel. Its functionality covers most hand
movements.
Zeus including the socket (made by CPO) is designed for only one
person during the whole lifetime of the prosthesis.
Fitting of the product to the patient’s upper limb may be exclusively
done by a qualied and certied CPO.
Aether BiomedicalZeus Brochure
5
Zeus is developed for everyday use and must not be used for unusual
activities. These unusual activities include, for example, sports with
excessive strain and/or shocks to the wrist unit (pushups, downhill.
mountain biking) or extreme sports (free climbing, paragliding, etc.).
Furthermore, the Zeus should not be used for the operation of motor
vehicles, heavy equipment (e.g. construction machines), industrial
machines or motor-driven equipment.
The prosthesis is intended exclusively for use on one patient. Use of
the product by another person is not approved by the manufacturer.
Fitting a patient with Zeus may only be carried out by a prosthetist
who has been authorized by Aether Biomedical after completion of a
corresponding training course.
Aether Biomedical Zeus Brochure
65
Technical
Specication
7.4V, 2200mAh
560g
1.5sec
152N
500N 350N
182.7mm
80.6mm
29.9mm
Flexible battery pack
with magnetic charging
Device weight
QWD
Max. closing
time
Grip force
Force on chassis (static,
supporting the hand)
Force with closed hand
(static, carrying a bag)
Height (nger tip to wrist base)
Palm Width
Thickness
Aether BiomedicalZeus Brochure
7
7
Operating Range Storage range
Product Features
7
-5°C to +45°C
-25°C to +70°C
(at home – between uses)
15% to 93% RH (non-condensing)
Up to 93%
700 hPa to 1060 hPa
Temperature:
Temperature:
Humidity:
Humidity:
Pressure:
Closed loop motor control
sensing nger position and
applied force for
proportional
control
Compliant ngers to prevent
breaking of nger units
5 Individually motorized articulating digits
allowing for dexterity in movement
Opposable thumb
design with inbuilt
sensor for position
detection
100% customizability
for perfect aesthetic
appearance
Innovative
palm design
using hard & soft
material for reduced weight
and lateral shock absorption
12 Selectable + 2 User
congurable grip patterns
The strongest bionic
hand (152N grip force)
Aether Biomedical Zeus Brochure
87
Box Checklist
Zeus Grips
You can choose from 12 grip modes with an added option of 2 custom
grips. The hand has two selectable thumb positions: opposed and
non-opposed.
»Opposed thumb in opposition to the ngers on the hand allows
choosing grips like Tripod and Power.
»Non-Opposed thumb parallel with the ngers of the hand al-
lows grips like Key and Finger Point
The Zeus V1 is available in both left hand and right hand
congurations.
The system consists of the following:
1. Zeus Hand - Available in Left (A-01-L) and Right (A-01-R)
2. Flex Cell (1027204 OB)
3. Element electrode system (80101-1)
4. Quick Disconnect wrist lamination package (QDAWA-50)
5. Battery Charger (VEP24US09)
6. Accessories kit (AC-01)
7. Instructions for use
8. Zeus hand software
7
Model No.
Zeus V1 - L
Zeus V1 - R
Description
Zeus Prosthetic hand - Left
Zeus Prosthetic hand - Right
7
-25°C to +70°C
Up to 93%
Aether BiomedicalZeus Brochure
9
Opposed Grips
Power Grip
Active Index Grip
This grip is useful for operat-
ing appliances which
requiretrigger mechanisms
like power tools, sprays and
hairdryers. The hand grasps
the object and conforms to
the shape of the object. The
index nger is controlled
proportionately to operate
the trigger mechanism. The
speed and force applied
by the index nger can be
modulated on the basis of
EMG signal.
In this grip, the thumb is opposed,
while all of the other four ngers close
until they meet the object or receive
a closing signal. The strong grip
provides 152N of force spread over
all four ngers and thumb. This grip
is useful for lifting large objects,
shaking hands or crushing empty
cans. Individual nger stalling means
the grip conforms to the shape of the
object so that you can lift things such
as a wine glass. Thanks to advanced
sensors, the hand optimizes the force
applied to the object.
