AES global Praetorian Guard Instructions de montage

1 | P a g e

Installation & User Instructions

Praetorian Guard IP Intercom

(with 4G access Point)

PROFESSIONAL INSTALL ONLY

Manual Version 1.1

Tip: Site Survey BEFORE you begin.

See page 4

2 | P a g e

Index

Section

Pages

PHASE 1 –SITE SURVEY

3-4

Site Survey (4G Router)

PHASE 2 –PRODUCT OVERVIEW

5-23

Overview of Call Points

6-9

Overview of Optional Extra Devices

More Detail….

11-17

PCB Module Overview

18-19

Technical Specifications

20-23

PHASE 3 –SETUP 4G

24-45

PHASE 3a –SETUP 4G (Router Separate)

25-29

PHASE 3b –SETUP 4G (Router Integrated)

30-35

PHASE 3 –SETUP 4G (Continued)

36-45

4G Setup Intercom on App

37-41

Time Sync & Testing

42-43

Answering on Android

Answering on iOS (Apple)

PHASE 4 - INSTALLATION

46-55

How to Achieve & Maintain IP55 Rating

Power & Antenna

Solar Power

Wiring Example

Connecting Slave Devices

Adding Additional APP Users

Sound, Volumes and Speech / Intercom & Device Sound Options

Using Keypad Codes

PHASE 5 –ADVANCED SETUP

55-71

Feature Shortcuts & Settings Overview

Standard Features

Edit Intercom Details / Add a New Device ID

Ringtones of In-app Call / Check APP version

Check Intercom Firmware / Add, Edit or Delete Users & Logins

Adjust Relay Trigger Times / Adjust Intercom Time

Wi-Fi Settings / Adjust Maximum Monitoring Time

Adjust Maximum Talking Time / Adjust Maximum Calling Time

Reboot Intercom / Simplex / Duplex Audio Selection

Advanced Feature Overview / Notifications

Auto Relay Times / Camera Stream Resolution

Activity Log

Keypad Codes

PROX Cards/Tag IDs

Voicemail Option for missed Callers / Motion Detection Option

Troubleshooting

71-72

App Updates / Firmware Updates / Extra Resources

Intercom Maintenance / Environmental Information / Ingress

Warranty

Regulatory Compliance / Declaration of Conformity

3 | P a g e

PHASE 1

Site Survey

4 | P a g e

Mbs

Slow Fast

Site Survey (4G Router)

YES!

I have 4G signal at the gate with my phone! If

not, STOP. You will need some! Try a different

network provider.

Upload Speed

I have at least 1.5 Mb UPLOAD speed. If not

STOP! This system may operate intermittently

remotely or have delayed PUSH notifications.

The Praetorian Guard is specially designed to transmit the video and audio stream using on

average 400 KBit/sec (peaking to 1Mbps). This loosely translates to requiring a minimum of

1.5mbps UPLOAD speed on the network that the intercom is connected to. The higher the

upload speed the better quality of image up to approx. 4mbps.

If you have a good GSM signal for the network being used you can expect to have an upload

speed of up to 10mbps.

Note: When using our 4G access point the upload speed will be influenced by the GSM signal

being received. With a high signal level the access point can pull approx. 10mbps upload.

5 | P a g e

PHASE 2

Product Overview

6 | P a g e

Overview of Call Points(Modular Design)

Separate 4G Router

Overview of Call Points(Modular Design)

Integrated 4G Router

PRAE-4GXX-MOD

PRAE-4GXX-MOD-KP

PRAE-4GXX-MOD-PX

PRAE-4GXX-MOD-PX-KP

PRAE-4GXX-MOD-ROUTER

PRAE-4GXX-MOD-KP-ROUTER

PRAE-4GXX-MOD-PX-ROUTER

PRAE-4GXX-MOD-PX-KP-ROUTER

7 | P a g e

Overview of Call Points(Architecture Design)

Separate 4G Router

PRAE-4GXX-AB

PRAE-4GXX-AS

PRAE-4GXX-ABK

PRAE-4GXX-ASK

PRAE-4GXX-PX-ABK

PRAE-4GXX-PX-ASK

8 | P a g e

Overview of Call Points(Portrait Flush Design)

Separate 4G Router

PRAE-4GXX-FB

PRAE-4GXX/FS

PRAE-4GXX/FBK

PRAE-4GXX/FSK

PRAE-4GXX-F-PX-ABK

PRAE-4GXX-F-PX-ASK

9 | P a g e

Overview of Call Points (Pedestal Design)

Integrated 4G Router & Antenna

Overview of Call Points (Pedestal Flush Design)

Integrated 4G Router

PRAE-4GXX-PED

PRAE-4GXX-KP-PED

PRAE-4GXX-PX-PED

PRAE-4GXX-PX-KP-PED

PRAE-4GXX-PED-F

PRAE-4GXX-PED-F-KP

10 | P a g e

Overview of Optional Extra Devices

MON-11

POWER CONDITIONING MODULE

TBC (future addition late 2021)
