Lightmeter

Model 1110

Quick Start Guide

ENGLISH

LIGHTMETER DATA LOGGER

WITH AEMC

INSTRUMENTS

No part of this documentation may be reproduced in any form or by any means (including electronic

storage and retrieval or translation into any other language) without prior agreement and written consent

from Chauvin Arnoux®, Inc., as governed by United States and International copyright laws.

Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

15 Faraday Drive • Dover, NH 03820 USA

Tel: (800) 945-2362 or (603) 749-6434 • Fax: (603) 742-2346

This documentation is provided “as is,” without warranty of any kind, express, implied, or otherwise.

Chauvin Arnoux®, Inc. has made every reasonable e󰀨ort to ensure that this documentation is accurate;

but does not warrant the accuracy or completeness of the text, graphics, or other information contained

in this documentation. Chauvin Arnoux®, Inc. shall not be liable for any damages, special, indirect,

incidental, or inconsequential; including (but not limited to) physical, emotional or monetary damages

due to lost revenues or lost prots that may result from the use of this documentation, whether or not the

user of the documentation has been advised of the possibility of such damages.

Statement of Compliance

Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments

certies that this instrument has been calibrated

using standards and instruments traceable to

international standards.

We guarantee that at the time of shipping your

instrument has met its published specications.

An NIST traceable certicate may be requested

at the time of purchase, or obtained by returning

the instrument to our repair and calibration

facility, for a nominal charge.

The recommended calibration interval for this

instrument is 12 months and begins on the date of

receipt by the customer. For recalibration, please

use our calibration services. Refer to our repair and

calibration section at www.aemc.com.

Serial #:

Catalog #: 2121.71

Model #: 1110

Please ll in the appropriate date as indicated:

Date Received:

Date Calibration Due:

Chauvin Arnoux®, Inc.

d.b.a AEMC®Instruments

www.aemc.com

Lightmeter Model 1110 Quick Start Guide

Thank you for purchasing an AEMC®Instruments Lightmeter Data Logger Model

1110.

For the best results from your instrument and for your safety, you must read the

enclosed operating instructions carefully and comply with the precautions for

use. Only qualied and trained operators should use this product.

Symbols and Denitions

CAUTION - Risk of Danger! Indicates a WARNING. Whenever this symbol

is present, the operator must refer to the user manual before operation.

Indicates important information to acknowledge.

Battery

Magnet

The product has been declared recyclable.

AEMC has adopted an Eco-Design approach in order to design this

appliance. Analysis of the complete lifecycle has enabled us to control and

optimize the e󰀨ects of the product on the environment. In particular this

appliance exceeds regulation requirements with respect to recycling and

reuse.

This product complies with the Low Voltage & Electromagnetic Compatibility

European directives (73/23/CEE & 89/336/CEE).

In the European Union, this product is subject to a separate collection

system for recycling electrical and electronic components in accordance with

directive WEEE 2002/96/EC.

Denition of Measurement Categories (CAT)

CAT IV corresponds to measurements performed at the primary electrical

supply (< 1000 V).

Example: primary overcurrent protection devices, ripple control units, and

meters.

CAT III corresponds to measurements performed in the building installation at

the distribution level.

Example: hardwired equipment in xed installation and circuit breakers.

CAT II corresponds to measurements performed on circuits directly connected

to the electrical distribution system.

Example: measurements on household appliances and portable tools.

Lightmeter Model 1110 Quick Start Guide

PRECAUTIONS FOR USE

These safety warnings are provided to ensure the safety of personnel and

proper operation of the instrument.

Read this instruction manual completely and follow all the safety information

before attempting to use or service this instrument.

Safety is the responsibility of the operator!

Tests are to be carried out only on dead circuits! Check for live circuits

before making resistance measurements (safety check).

Always make connections from the instrument to the circuit under test.

These megohmmeters are sources of high voltage, as is the sample

connected to them. All persons performing or assisting in the tests must

follow all safety precautions to prevent electrical shock to themselves and to

others.

AEMC considers the use of rubber gloves to be an excellent safety practice

even if the equipment is properly operated and correctly grounded.

When testing capacitance samples, make sure that they have been properly

discharged and that they are safe to touch. Dielectric insulation samples

should be short-circuited for at least ve times the amount of time they were

energized.

Never open the back of the instrument while connected to any circuit or

input.

INITIAL SETUP

Installing Batteries

1. Press the tab of the battery compartment cover and lift it clear.

2. Remove the battery compartment cover.

3. Insert the new batteries, ensuring correct polarity.

4. Close the battery compartment cover, ensuring it is completely and

correctly closed.

Lightmeter Model 1110 Quick Start Guide

Connecting to a Computer

Some Model 1110 features (such as measurement units and min/max/average

settings) can be congured through the instrument keypad. Others require

the instrument to be connected to DataView® for conguration. (For detailed

setup instructions, see the User Manual in the USB drive that comes with the

instrument).

To connect the Model 1110 to your computer:

1. Install the DataView®software, making sure to select the Data Logger

Control Panel as an option (it is selected by default). De-select any Control

Panels you do not need.

2. If prompted, restart the computer after installation is complete.

3. Connect the instrument to the computer using a USB cable or pair with

Bluetooth.

4. Wait for the drivers to install. The drivers are installed the rst time the

instrument is connected to the computer. The Windows operating system

will display messages indicating when the installation is complete.

5. Start the Data Logger Control Panel by double-clicking the Data Logger

shortcut icon in the DataView®folder placed on the desktop during the

installation.

6. Click Instrument in the menu bar, and select Add an Instrument.

7. The Add an Instrument Wizard dialog box opens. This is the rst of a

series of screens that lead you through the instrument connection process.

The rst screen prompts you to select the connection type (USB or

Bluetooth). Choose the connection type and click Next.

8. If the instrument is identied, click Finish. The instrument is now

communicating with the Control Panel.

9. When you are nished, the instrument will appear in the Data Logger

Network branch in the Navigation frame, with a green check mark

indicating a successful connection.

Setting the Instrument’s Clock

To ensure an accurate time stamp of measurements recorded in the instrument,

set the instrument’s clock as follows:

1. Select the instrument in the Data Logger Network.

2. In the menu bar, select Instrument. In the drop-down menu that appears,

click Set Clock.

3. The Date/Time dialog box appears. Complete the elds in this dialog box. If

you need assistance, press F1.

4. When you are nished setting the date and time, click OK to save your

changes to the instrument.

Lightmeter Model 1110 Quick Start Guide

INSTRUMENT CONFIGURATION

In addition to setting the instrument’s clock, other basic setup tasks include:

• Enabling Bluetooth (can be done on the instrument or via DataView®)

• Setting measurement units (can be done on the instrument or via DataView®)

• Changing the Auto OFF interval (requires DataView®)

Detailed information for conguring the instrument via the DataView®Data

Logger Control Panel is available by pressing the Help button.

ENABLING BLUETOOTH

Long press (> 2 seconds) the button to enable/disable Bluetooth.

SELECTING TEMPERATURE UNITS

Press to toggle between lx (lux) and fc (foot-candles).

OPERATION

Making Measurements

1. Remove the cap protecting the sensor.

2. Place the sensor in the location to be measured, ensuring you do not

position yourself between the sensor and light source(s).

3. If the instrument is OFF, press and hold down the button until it

turns ON. The instrument displays the current time, followed by the

measurement.

4. To change the units of measure, long-press the button. The instrument

will continue to use this unit when next turned ON.

5. To save the measurement to the instrument’s memory, press the

button.

Recording Measurements

You can start and stop a recording session on the instrument. Recorded data

is stored in the instrument’s memory, and can be downloaded and viewed on a

computer running the DataView®Data Logger Control Panel.

You can record data by pressing the button:

• A short press (MEM) records the current measurement(s) and date.

• A long press (REC) starts the recording session. While the recording is in

progress, the symbol REC appears at the top of the display. A second long

press of stops the recording session. Note that while the instrument is

recording, a short press of has no e󰀨ect.

To schedule recording sessions, and download and view recorded data, see the

DataView®Data Logger Control Panel Help.

Lightmeter Model 1110 Quick Start Guide

REPAIR AND CALIBRATION

To ensure that your instrument meets factory specications, we recommend

that it be sent back to our factory Service Center at one-year intervals for

recalibration or as required by other standards or internal procedures.

For instrument repair and calibration:

You must contact our Service Center for a Customer Service Authorization

Number (CSA#). Send an email to [email protected] requesting a CSA#,

you will be provided a CSA Form and other required paperwork along with the

next steps to complete the request. Then return the instrument along with the

signed CSA Form. This will ensure that when your instrument arrives, it will be

tracked and processed promptly. Please write the CSA# on the outside of the

shipping container. If the instrument is returned for calibration, we need to know

if you want a standard calibration or a calibration traceable to N.I.S.T. (includes

calibration certicate plus recorded calibration data).

Ship To: Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

15 Faraday Drive ▪ Dover, NH 03820 USA

Phone: (800) 945-2362 (Ext. 360) / (603) 749-6434 (Ext. 360)

Fax: (603) 742-2346

E-mail: [email protected]

(Or contact your authorized distributor.)

traceable to N.I.S.T.

NOTE: You must obtain a CSA# before returning any instrument.

TECHNICAL ASSISTANCE

If you are experiencing any technical problems or require any assistance with

the proper operation or application of your instrument, please call, e-mail or fax

our technical support team:

Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

Phone: (800) 343-1391 (Ext. 351)

Fax: (603) 742-2346

E-mail: [email protected]

www.aemc.com

Lightmeter Model 1110 Quick Start Guide

LIMITED WARRANTY

The instrument is warrantied to the owner for a period of two years from the date

of original purchase against defects in manufacture. date of original purchase

against defects in manufacture. This limited warranty is given by AEMC®

Instruments, not by the distributor from whom it was purchased. This warranty

is void if the unit has been tampered with, abused, or if the defect is related to

service not performed by AEMC®Instruments.

Full warranty coverage and product registration is available on our

website at www.aemc.com/warranty.html.

Please print the online Warranty Coverage Information for your records.

What AEMC® Instruments will do:

If a malfunction occurs within the warranty period, you may return the instrument

to us for repair, provided we have your warranty registration information on

le or a proof of purchase. AEMC®Instruments will repair or replace the faulty

material at our discretion.

WARRANTY REPAIRS

What you must do to return an Instrument for Warranty

Repair:

First, send an email to [email protected]m requesting a Customer Service

Authorization Number (CSA#) from our Service Department. You will be

provided a CSA Form and other required paperwork along with the next steps

to complete the request. Then return the instrument along with the signed CSA

Form. Please write the CSA# on the outside of the shipping container. Return

the instrument, postage or shipment pre-paid to:

Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

15 Faraday Drive, Dover, NH 03820 USA

Phone: (800) 945-2362 (Ext. 360) / (603) 749-6434 (Ext. 360)

Fax: (603) 742-2346

E-mail: [email protected]

Caution: To protect yourself against in-transit loss, we recommend that

you insure your returned material.

NOTE: You must obtain a CSA# before returning any instrument.

Lightmeter Model 1110 Quick Start Guide

NOTES:

Autres manuels pour 1110

Table des matières

Autres manuels AEMC Instrument de mesure

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
