AEG DEK431010M Manuel utilisateur

USER

MANUAL

EN User Manual

Built-In Double Oven

DEK431010M

Welcome to AEG! Thank you for choosing our appliance.

In our drive to be sustainable, we are reducing paper assets and provide full user

manuals online. Access your full user manual at aeg.com/manuals

Get usage advice, brochures, trouble shooter, service and repair information at

aeg.com/support

1. PRODUCT DESCRIPTION

1.1 General overview

1 3 4 5 762

1Knob for the top oven functions

2Temperature indicator / symbol for the

top oven

3Knob for the top oven temperature

4Display

5Knob for the main oven functions

6Temperature indicator / symbol for the

main oven

7Knob for the main oven temperature

8Heating element

9Lamp

10 Fan

11 Shelf support, removable

12 Shelf positions

2. CONTROL PANEL

2.1 Sensor fields / Buttons

To set the time.

To set a clock function.

To set the time.

2.2 Display

The display works only with the

main oven.

A B

2 ENGLISH

A. Clock functions B. Timer

3. BEFORE FIRST USE

3.1 Before first use

The oven can emit an odour and smoke during preheating. Make sure that the room is

ventilated.

Preheat both ovens. Heat up one oven at a time.

Step 1 Step 2 Step 3

Set the clock Clean the oven Preheat the empty oven

1. , - press to set the time.

After approximately 5 sec., the

flashing stops and the display

shows the time.

1. Remove all accessories and re‐

movable shelf supports from

the oven.

2. Clean the oven and the acces‐

sories with a soft cloth, warm

water and a mild detergent.

1. Set the maximum temperature

for the function: .

Time: 1 h.

2. Set the maximum temperature

for the function: .

Time: 15 min.

3. Set the maximum temperature

for the function: .

Time: 15 min.

Turn off the oven and wait until it is cold. Place the accessories and the removable shelf supports in the oven.

4. DAILY USE

4.1 How to set: Heating function

Step 1 Turn the knob for the heating functions

to select a heating function.

Step 2 Turn the control knob to select the tem‐

perature.

Step 3 When the cooking ends, turn the knobs

to the off position to turn off the oven.

4.2 Top oven functions

Heating function Application

Light

Oven lamp

Conventional Cooking

Traditional baking, crispiness, crust gloss

Top Heat

Browning cooked dishes

ENGLISH 3

Heating function Application

Bottom Heat

Preserving food

Grill

Toasting, grilling

Fast Grilling

Toasting, grilling

4.3 Main oven functions

Heating function Application

Light

Oven lamp

True Fan Cooking

Even baking, tenderness, drying

Defrost

Defrosting

5. CARE AND CLEANING

5.1 Notes on cleaning

Cleaning Agents

Clean the front of the oven with a soft cloth with warm water and a mild detergent.

Use a cleaning solution to clean metal surfaces.

Clean stains with a mild detergent.

Everyday Use

Clean the cavity after each use. Fat accumulation or other residue may cause fire.

Do not store the food in the oven for longer than 20 minutes. Dry the cavity with a soft cloth

after each use.

Accessories

Clean all accessories after each use and let them dry. Use a soft cloth with warm water and

a mild detergent. Do not clean the accessories in a dishwasher.

Do not clean the non-stick accessories using abrasive cleaner or sharp-edged objects.

4 ENGLISH

6. TROUBLESHOOTING

6.1 What to do if...

In any cases not included in this table please

contact with an Authorised Service Centre.

Problem Check if...

The oven does not heat

up.

The fuse is blown.

Problem Check if...

The display shows

"12.00".

There was a power cut.

Set the time of day.

The lamp does not work. The lamp is burnt out.

6.2 Service data

If you cannot find a solution to the problem yourself, contact your dealer or an Authorised

Service Centre.

The necessary data for the service centre is on the rating plate. The rating plate is on the front

frame of the oven cavity. Do not remove the rating plate from the oven cavity.

We recommend that you write the data here:

Model (MOD.) .........................................

Product number (PNC) .........................................

Serial number (S.N.) .........................................

7. ENERGY EFFICIENCY

7.1 Product Information Sheet according to UK Ecodesign and Energy

Labelling Regulations

Supplier's name AEG

Model identification DEK431010M 944171699

Energy Efficiency Index Top oven: 106.8

Main oven: 95.2

Energy efficiency class Top oven: A

Main oven: A

Energy consumption with a standard load, conventional mode Top oven: 0.78 kWh/cycle

Main oven: -

Energy consumption with a standard load, fan-forced mode Top oven: -

Main oven: 0.79 kWh/cycle

Number of cavities 2

Heat source Electricity

Volume Top oven: 42 l

Main oven: 66 l

Type of oven Built-In Oven

ENGLISH 5

Mass 47.7 kg

BS EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Meth‐

ods for measuring performance.

7.2 Energy saving

The oven has features which

help you save energy during

everyday cooking.

Make sure that the oven door is closed when

the oven operates. Do not open the oven

door too often during cooking. Keep the door

gasket clean and make sure it is well fixed in

its position.

Use metal cookware to improve energy

saving.

When possible, do not preheat the oven

before cooking.

Keep breaks between baking as short as

possible when you prepare a few dishes at

one time.

Cooking with fan

When possible, use the cooking functions

with fan to save energy.

Residual heat

When the cooking duration is longer than 30

min, reduce the oven temperature to

minimum 3 - 10 min before the end of

cooking. The residual heat inside the oven

will continue to cook.

Use the residual heat to warm up other

dishes.

Keep food warm

Choose the lowest possible temperature

setting to use residual heat and keep a meal

warm.

8. ENVIRONMENTAL CONCERNS

Recycle materials with the symbol . Put

the packaging in relevant containers to

recycle it. Help protect the environment and

human health by recycling waste of electrical

and electronic appliances. Do not dispose of

appliances marked with the symbol with

the household waste. Return the product to

your local recycling facility or contact your

municipal office.

6 ENGLISH

www.aeg.com/shop

867370755-A-502021
