Advantech PCI-1736UP Manuel utilisateur

PCI-1736UP

32-channel Isolated Digital

Input/Output Card

User Manual

PCI-1736UP User Manual ii

The documentation and the software included with this product are copy-

righted 2005 by Advantech Co., Ltd. All rights are reserved. Advantech

Co., Ltd. reserves the right to make improvements in the products

described in this manual at any time without notice. No part of this man-

ual may be reproduced, copied, translated or transmitted in any form or

by any means without the prior written permission of Advantech Co., Ltd.

Information provided in this manual is intended to be accurate and reli-

able. However, Advantech Co., Ltd. assumes no responsibility for its use,

nor for any infringements of the rights of third parties, which may result

from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of

Microsoft Corp.

All other product names or trademarks are properties of their respective

owners.

Part No. 2003173600 1st Edition

Printed in Taiwan January 2005

iii

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its prod-

ucts will be free from defects in materials and workmanship for two years

from the date of purchase.

This warranty does not apply to any products which have been repaired or

altered by persons other than repair personnel authorized by Advantech,

or which have been subject to misuse, abuse, accident or improper instal-

lation. Advantech assumes no liability under the terms of this warranty as

a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous test-

ing, most of our customers never need to use our repair service. If an

Advantech product is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will

be billed according to the cost of replacement materials, service time and

freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For

example, CPU speed, Advantech products used, other hardware

and software used, etc.) Note anything abnormal and list any

onscreen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your man-

ual, product, and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return

merchandize authorization) number from your dealer. This allows

us to process your return more quickly.

4. Carefully pack the defective product, a fully-completed Repair and

Replacement Order Card and a photocopy proof of purchase date

(such as your sales receipt) in a shippable container. A product

returned without proof of the purchase date is not eligible for war-

ranty service.

5. Write the RMA number visibly on the outside of the package and

ship it prepaid to your dealer.

PCI-1736UP User Manual iv

This product has passed the CE test for environmental specifications

when shielded cables are used for external wiring. We recommend the use

of shielded cables. This kind of cable is available from Advantech. Please

contact your local supplier for ordering information.

Technical Support and Assistance

Step 1. Visit the Advantech web site at www.advantech.com/support

where you can find the latest information about the product.

Step 2. Contact your distributor, sales representative, or Advantech's cus-

tomer service center for technical support if you need additional

assistance. Please have the following information ready before

you call:

- Product name and serial number

- Description of your peripheral attachments

- Description of your software (operating system, version, appli-

cation software, etc.)

- A complete description of the problem

- The exact wording of any error messages

Packing List

Before setting up the system, check that the items listed below are

included and in good condition. If any item does not accord with the

table, please contact your dealer immediately.

1. PCI-1736UP card

2. Companion CD-ROM (Device Drivers included)

3. User Manual

Safety Precaution - Static Electricity

Follow these simple precautions to protect yourself from harm and the

products from damage.

1. To avoid electrical shock, always disconnect the power from your

PC chassis before you work on it. Don't touch any components on

the CPU card or other cards while the PC is on.

2. Disconnect power before making any configuration changes. The

sudden rush of power as you connect a jumper or install a card may

damage sensitive electronic components.

Contents

Chapter 1 Introduction ..................................................... 2

1.1 Features ............................................................................. 2

1.1.1 Robust Protection ........................................................... 2

1.1.2 Wide Input Range .......................................................... 3

1.1.3 Reset Protection for Industrial Applications .................. 3

1.1.4 Plug & Play Function ..................................................... 3

1.1.5 BoardID Switch ............................................................. 3

1.2 Applications ...................................................................... 4

1.3 Installation Guide .............................................................. 4

1.4 Software Overview............................................................ 5

1.4.1 Programming Choices for DA&C Cards ....................... 5

1.4.2 Device Drivers ............................................................... 5

1.4.3 Register-level Programming .......................................... 5

1.5 Device Drivers Programming Roadmap ........................... 6

1.5.1 Programming Tools ....................................................... 6

1.5.2 Programming with Device Drivers Function Library .... 7

1.5.3 Troubleshooting Device Driver Error ............................ 7

1.6 Accessories........................................................................ 8

1.6.1 Wiring Cables ................................................................ 8

1.6.2 Wiring Boards ................................................................ 8

Chapter 2 Installation ..................................................... 10

2.1 Unpacking ....................................................................... 10

2.2 Driver Installation ........................................................... 11

Figure 2.1:The Setup Screen of Automation Software 12

Figure 2.2:Different Options for Driver Installation ... 13

2.3 Hardware Installation ...................................................... 14

Figure 2.3:The Device Name Listed on Device Mng. . 15

2.4 Device Setup & Configuration........................................ 16

2.4.1 Setting Up the Device .................................................. 16

Figure 2.4:The Device Manager Dialog Box ............... 17

Figure 2.5:The “Device(s) Found” Dialog Box ........... 17

2.4.2 Configuring the Device ................................................ 18

Figure 2.6:The Device Setting Dialog Box ................. 18

Figure 2.7:The Device Name Appearing on the List of

Devices Box ..................................................... 18

Figure 2.8:The Test Diagram Box for Digital Input .... 19

Figure 2.9:The Test Diagram Box for Digital Output 20

Chapter 3 Signal Connections ........................................ 22

3.1 Overview ......................................................................... 22

3.2 Switch and Jumper Locations ......................................... 22

Figure 3.1:Card Conn., Jumper and Switch Locations 22

3.2.1 Setting the time to Reset the Digital Outputs .............. 23

PCI-1736UP User Manual vi

Table 3.1:Jumper Settings ............................................ 23

3.2.2 BoardID Switch Setting ............................................... 24

3.2.3 Wet/Dry Contact Setting. ............................................. 24

3.3 Signal Connections.......................................................... 25

Table 3.2:Description of CN1 Pin Use ........................ 25

Figure 3.2:I/O Connector Pin Assignments for CN1 ... 25

3.3.1 Isolated Digital Inputs .................................................. 26

Figure 3.3:Isolated Digital Input Connection .............. 26

Figure 3.4:Bi-directional Isolated Digital Input Conn. 26

3.3.2 Isolated Digital Outputs ............................................... 27

Figure 3.5:Isolated Digital Output Connection ............ 27

Appendix A Specifications ................................................. 30

A.1 Isolated Digital Inputs ..................................................... 30

A.2 Isolated Digital Outputs...................................................... 30

A.3 General ................................................................................. 31

Appendix B Block Diagram............................................... 34

Figure B.1:PCI-1736UP Block Diagram ..................... 34

Appendix C Register Structure & Format....................... 36

C.1 Overview ......................................................................... 36

C.2 I/O Port Address Map .................................................... 36

Table C.1:PCI-1736UP Register Format ..................... 37

C.3 Isolated Digital Input Reg. -- BASE+0H/1H (/2H/3H) .. 38

Table C.2:Register for Isolated Digital Input .............. 38

C.4 Isolated Digital Output Reg.- BASE+0H/1H (/2H/3H) .. 38

Table C.3:Register for Isolated Digital Output ............ 38

C.5 Board ID — BASE+4H ................................................. 39

Table C.4:Register for BoardID ................................... 39

C.6 Interrupt Status Register — BASE+8H/CH/10H............ 40

Table C.5:Register for Interrupt Status ........................ 40

C.7 Interrupt Control Register — BASE+8H/CH/10H ......... 41

Table C.6:Register for Interrupt Control ..................... 41

CHAPTER

Introduction

The following sections of this chapter

will provide further information about

features, installation guide, together

with some brief information on soft-

ware and accessories for the PCI-

1736UP card.

Sections include:

• Features

• Applications

• Installation Guide

• Software Overview

• Device Drivers Programming Road-

map

• Accessories

PCI-1736UP User Manual 2

Chapter 1 Introduction

Thank you for buying the Advantech PCI-1736UP. The

Advantech PCI-1736UP is a 32-channel isolated digital

input/output card for the PCI bus.

1.1 Features

The Advantech PCI-1736UP offers the following main features:

• 32 isolated DIO channels (16 inputs and 16 outputs)

• High output driving capacity

• High-voltage isolation on isolated I/O channels (2,500 V DC)

• Interrupt handling capability

• D-type connector for isolated input and output channels

• Output status read-back

• Keep digital output values when hot system reset

• Wide input range (5 ~ 30 V DC)

• BoardID switch

• Low profile

• Universal PCI card, accepts both 3.3 and 5 V

1.1.1 Robust Protection

The PCI-1736UP digital input channels feature a robust isolation protec-

tion for industrial, lab and machinery automation applications. It durably

withstands voltage up to 2,500 VDC, preventing your host system from

any incidental harms. If connected to an external input source with surge-

protection, the PCI-1736UP can offer up to a maximum of 2,000 VDC

ESD (Electrostatic Discharge) protection. Even with an input voltage ris-

ing up to 70 VDC, the PCI-1736UP can still manage to work properly

albeit only for short period of time.

3 Chapter1

1.1.2 Wide Input Range

PCI-1736UP has a wide range of input voltage from 5 to 30 V DC, and it

is suitable for most industrial applications with 12 to 24 V DC input volt-

age.

1.1.3 Reset Protection for Industrial Applications

When the system has undergone a hot reset (i.e. without turning off the

system power), PCI-1736UP can either retain outputs values of each

channel, or return to its default configuration as open status, depending

on its onboard jumper setting. This function protects the system from

wrong operations during unexpected system resets.

1.1.4 Plug & Play Function

PCI-1736UP is a Plug & Play device, which fully complies with PCI

Specifications Revision 2.2. During card installation, there is no need to

set jumpers or DIP switches. Instead, all bus-related configurations such

as base I/O address and interrupt are automatically done by the Plug &

Play function.

1.1.5 BoardID Switch

PCI-1736UP has a built-in DIP Switch that helps define each card’s ID

when multiple PCI-1736UP cards have been installed on the same PC

chassis. The BoardID switch setting function is very useful when users

build their system with multiple PCI-1736UP cards. With correct Boar-

dID settings, you can easily identify and access each card during hard-

ware configuration and software programming.

Note For detailed specifications of the PCI-1736UP,

please refer to Appendix A, Specifications.

PCI-1736UP User Manual 4

1.2 Applications

• Industrial ON/OFF control

• Switch status sensing

• BCD interfacing

• Digital I/O control

• Industrial and lab automation

• Laboratories & Education

1.3 Installation Guide

Before you install your PCI-1736UP card, please make sure you have the

following necessary components:

• PCI-1736UP card

• PCI-1736UP User Manual

• Driver software Advantech DLL drivers

(included in the companion CD-ROM)

• Wiring cable PCL-10144 (optional)

• Wiring board ADAM-3944 (optional)

• Computer Personal computer or workstation with a PCI-bus slot (run-

ning Windows 98/2000/XP)

Some other optional components are also available for enhanced

operation:

• Application software ActiveDAQ, ADAQ-View or other third-party

software packages

After you get the necessary components and maybe some of the accesso-

ries for enhanced operation of your Multifunction card, you can begin the

installation procedures.

Table des matières

Autres manuels Advantech Carte PCI

Advantech

Advantech AIMB-228 Manuel utilisateur

Advantech

Advantech PCM-3614I Manuel d'installation et d'exploitation

Advantech

Advantech PCI-1671UP Manuel d'installation et d'exploitation

Advantech

Advantech DVP-7020BE Manuel utilisateur

Advantech

Advantech MIC-3756 Manuel utilisateur

Advantech

Advantech PCI-1751 Manuel utilisateur

Advantech

Advantech PCI-1710U-DE Manuel utilisateur

Advantech

Advantech ARK-5261 Manuel d'installation et d'exploitation

Advantech

Advantech VEGA-340 Manuel d'installation et d'exploitation

Advantech

Advantech PCI-1730 Manuel utilisateur

Advantech

Advantech PCA-6005-B Manuel utilisateur

Advantech

Advantech PCI-1718 Series Manuel utilisateur

Advantech

Advantech PCIE-1752 Manuel utilisateur

Advantech

Advantech MIC-3302 Manuel utilisateur

Advantech

Advantech PCI-1730U Manuel d'installation et d'exploitation

Advantech

Advantech PCI-1752USO Manuel d'installation et d'exploitation

Advantech

Advantech EKI-6340 Series Manuel utilisateur

Advantech

Advantech PCI-1742U Manuel d'installation et d'exploitation

Advantech

Advantech PCM-2604C-AE Manuel d'installation et d'exploitation

Advantech

Advantech PCI-1751 Manuel utilisateur

Advantech

Advantech PCI-1752U Manuel utilisateur

Advantech

Advantech PCI-1734 Manuel d'installation et d'exploitation

Advantech

Advantech PCIE-1760 Manuel utilisateur

Advantech

Advantech PCI-1710 Manuel utilisateur

Manuels Carte PCI populaires d'autres marques

ERMA

ERMA SSI 1417 Manuel utilisateur

SIIG

SIIG CyberSerial Dual PCI Instructions de montage

Moxa Technologies

Moxa Technologies CP-102E Manuel utilisateur

I-Bus

I-Bus IBC2602 Manuel utilisateur

Exsys

Exsys EX-60102 Manuel utilisateur

Chelsio Communications

Chelsio Communications T5 Series Manuel utilisateur

Conrad Electronic

Conrad Electronic 97 46 71 Manuel utilisateur

Micro Innovations

Micro Innovations USB650A Manuel utilisateur

KTI Networks

KTI Networks KF-310 Manuel utilisateur

Asus

Asus SpaceLink WL230 Manuel utilisateur

SIIG

SIIG SC2475 Manuel utilisateur

TRENDnet

TRENDnet TEW-703PI Manuel utilisateur

Belkin

Belkin F5D7000F Manuel utilisateur

Pericom

Pericom PI7C7100 Manuel utilisateur

ADLINK Technology

ADLINK Technology cPCI-3548 Manuel utilisateur

Digium

Digium TE200 Series Manuel utilisateur

Allo.com

Allo.com 2nd Gen E1/T1/J1 Manuel utilisateur

Western Digital

Western Digital FireWire PCI Adapter Manuel utilisateur
