Advantech MIOe-DB2000 Manuel utilisateur

User Manual

MIOe-DB2000

Evaluation Board for MIO-2262

MIOe-DB2000 User Manual ii

The documentation and the software included with this product are copyrighted 2013

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. Information provided in this manual is intended to be accurate and reliable. How-

ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-

ments of the rights of third parties, which may result from its use.

Acknowledgements

Intel® is a trademark of Intel® Technologies, Inc.

IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Cor-

poration.

Microsoft Windows® is a registered trademark of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

For more information on this and other Advantech products, please visit our websites

at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our support website at:

http://support.advantech.com/

Part No. 2006DB2000 Edition 1

Printed in China May 2013

iii MIOe-DB2000 User Manual

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its products will be

free from defects in materials and workmanship for two years from the date of pur-

chase.

This warranty does not apply to any products which have been repaired or altered by

persons other than repair personnel authorized by Advantech, or which have been

subject to misuse, abuse, accident or improper installation. Advantech assumes no

liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of

our customers never need to use our repair service. If an Advantech product is defec-

tive, it will be repaired or replaced at no charge during the warranty period. For out-

of-warranty repairs, you will be billed according to the cost of replacement materials,

service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages you get when the problem

occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt)

in a shippable container. A product returned without proof of the purchase date

is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid

to your dealer.

MIOe-DB2000 User Manual iv

Declaration of Conformity

This product has passed the CE test for environmental specifications. Test conditions

for passing included the equipment being operated within an industrial enclosure. In

order to protect the product from being damaged by ESD (Electrostatic Discharge)

and EMI leakage, we strongly recommend the use of CE-compliant industrial enclo-

sure products.

FCC Class A

This equipment has been tested and found to comply with the limits for a Class A dig-

ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro-

vide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Opera-

tion of this device in a residential area is likely to cause harmful interference in which

case the user will be required to correct the interference at his/her own expense. The

user is advised that any equipment changes or modifications not expressly approved

by the party responsible for compliance would void the compliance to FCC regula-

tions and therefore, the user's authority to operate the equipment.

Caution! There is a danger of a new battery exploding if it is incorrectly installed.

Do not attempt to recharge, force open, or heat the battery. Replace the

battery only with the same or equivalent type recommended by the man-

ufacturer. Discard used batteries according to the manufacturer’s

instructions.

v MIOe-DB2000 User Manual

Technical Support and Assistance

1. Visit the Advantech website at http://support.advantech.com where you can find

the latest information about the product.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the

following information ready before you call:

–Product name and serial number

–Description of your peripheral attachments

–Description of your software (operating system, version, application software,

etc.)

–A complete description of the problem

–The exact wording of any and all error messages

Packing List

Before you begin installing your card, please make sure that the following materials

have been shipped:

1 MIOe-DB2000 development board

If any of these items is missing or damaged, contact your distributor or sales repre-

sentative immediately.

Ordering Information

* HDMI and DC jack supported by request.

Optional Accessories

Part No. DP/

HDMI

VGA GbE PCIe

RS-

232

Full-size

Mini PCIe

SIM

holder

SATA

LPC SMBus I2C USB

2.0

Audio MIOe Power

Conn.

MIOe-DB2000-

00A1E

1* 1 1121 1 1 11 16Yes Yes 2x2

pin*

Part Number Description

M I O - 2 2 6 2 N - S 6 A 1 E M I O - 2 2 6 2 N 2 6 0 0 S B C

MIO-2262N-S8A1E MIO-2262 N2800 SBC

MIOe-DB2000 User Manual vi

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp

cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the equip-

ment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting

it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything

over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source

to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service

personnel:

The power cord or plug is damaged.

Liquid has penetrated into the equipment.

The equipment has been exposed to moisture.

The equipment does not work well, or you cannot get it to work according to

the user's manual.

The equipment has been dropped and damaged.

The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE

STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C

(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT

SHOULD BE IN A CONTROLLED ENVIRONMENT.

16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE

RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES

ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.

The sound pressure level at the operator's position according to IEC 704-1:1982 is

no more than 70 dB (A).

DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech

disclaims all responsibility for the accuracy of any statements contained herein.

vii MIOe-DB2000 User Manual

Contents

Chapter 1 General Information ............................1

1.1 Introduction ............................................................................................... 2

1.2 Specifications ............................................................................................ 2

Table 1.1: Specifications ............................................................. 2

1.3 Block Diagram........................................................................................... 3

Figure 1.1 Block Diagram ............................................................ 3

1.4 Board Layout: Dimensions ........................................................................ 3

Figure 1.2 MIOe-DB2000 Mechanical Drawing (Top Side) ......... 3

Figure 1.3 MIOe-DB2000 Mechanical Drawing (Top Side, with op-

tional DC Jack) ........................................................... 4

Figure 1.4 MIOe-DB2000 Mechanical Drawing (Bottom Side) .... 4

Figure 1.5 MIOe-DB2000 Mechanical Drawing (Bottom Side, with

optional DC Jack) ....................................................... 5

Figure 1.6 MIOe-DB2000 Mechanical Drawing (Front I/O).......... 5

Figure 1.7 MIOe-DB2000 Mechanical Drawing (Front I/O, with op-

tional DC Jack) ........................................................... 5

Figure 1.8 MIOe-DB2000 Mechanical Drawing (Rear I/O) .......... 6

Figure 1.9 MIO-2262 + MIOe-DB2000 Height Dimension (With

standard heatsink) ...................................................... 6

Figure 1.10MIO-2262 + MIOe-DB2000 Height Dimension (With op-

tional heatspreader).................................................... 6

Chapter 2 Installation............................................7

2.1 Jumpers .................................................................................................... 8

2.1.1 Jumper Description ....................................................................... 8

2.1.2 Jumper Table................................................................................ 8

Table 2.1: Jumper Table.............................................................. 8

2.2 Connector Table........................................................................................ 9

Table 2.2: Connector Table......................................................... 9

2.3 Jumper and Connector Locations ........................................................... 10

Figure 2.1 Jumper and Connector layout (Top side) ................. 10

Figure 2.2 Jumper and Connector layout (Bottom side)............ 10

2.4 Jumper and Connector Pin Definition ..................................................... 11

2.5 Quick Installation Guide .......................................................................... 30

MIOe-DB2000 User Manual viii

Chapter 1

1General Information

This chapter gives background

information on the MIOe-DB2000.

Sections include:

Introduction

Specifications

Block diagram

Board layout and dimensions

MIOe-DB2000 User Manual 2

1.1 Introduction

MIOe-DB2000 is MIOe evaluation board for MIO-2262 SBC with standard EPIC form

factor. It’s compatible with MIOe; all circuit designs follow MI/O Extension design

guide. MIOe-DB2000 units have complete and flexible interfaces for verification and

various applications, including PCIe x1, DP or HDMI, mini PCIe with SIM, LPC,

SMBus, I2C, 8-bit GPIO, inverter, 12 VDC in, 6 USB2.0, HD audio line in/line out,

SATA with power, power/HDD LED, power/reset button. MIOe-DB2000 expedites

carrier board development, and saves customer design time and costs.

1.2 Specifications

Table 1.1: Specifications

Form Factor EPIC

Compatible Models MIO-2262

Display VGA 1

DP/HDMI 1 DP or HDMI (HDMI supported by request)

Storage SATA with Power 1 (connect to 2.5" HDD)

Rear I/O

Ethernet 1 x RJ45

VGA 1

DP/HDMI 1 (HDMI supported by request)

USB 6 x USB2.0

LED Power, HDD

Power Button 1

Reset Button 1

HD Audio Line in, Line out

Serial 2 x RS-232 (ESD protection for RS-232: Air

gap ±15 kV, Contact ± 8kV)

Power Input 1 (default 2x2pin power connector, DC jack

supported by request)

Internal I/O

I2C1

SMBus 1

Inverter 1

GPIO 8-bit general purpose input/output

LPC 1

Expansion

PCIe x1 slot 1

Mini PCI Express 1 (Full-size)

SIM card Holder 1

MIOe connector 1

64pin Connector 2

Power Independent Power

voltage Single +12 V DC in

Environment Operation 0 ~ 60° C (32 ~ 140° F) (Operational humid-

ity: 40° C @ 95% RH Non-Condensing)

Non-Operational -40 ~ 85° C and 40° C @ 95% RH Non-Con-

densing

Mechanical Dimensions (L x W) 115 x 165 mm (4.5" x 6.5")

Weight 0.25 kg (0.55 lb), weight of total package

Table des matières

Autres manuels Advantech Carte mère

Advantech

Advantech mATX i915GV2-IGM Series Manuel utilisateur

Advantech

Advantech PCM-9570 Manuel d'installation et d'exploitation

Advantech

Advantech AIMB-256 Manuel utilisateur

Advantech

Advantech MIC-3392 Manuel utilisateur

Advantech

Advantech POD-6552 Manuel d'installation et d'exploitation

Advantech

Advantech AIMB-766 Manuel utilisateur

Advantech

Advantech SOM-7567 Manuel utilisateur

Advantech

Advantech PCI-7020F PCI-7020VG PCI-7020LV PCI-7020 Manuel utilisateur

Advantech

Advantech WISE-DB1500 Manuel utilisateur

Advantech

Advantech AIMB-252 Manuel utilisateur

Advantech

Advantech PCM-9588 Manuel utilisateur

Advantech

Advantech PCA-6166 Manuel utilisateur

Advantech

Advantech AIMB-785 Manuel d'installation et d'exploitation

Advantech

Advantech ASMB-786 Manuel utilisateur

Advantech

Advantech MIC-3329 Series Manuel utilisateur

Advantech

Advantech AIMB-223 Manuel d'installation et d'exploitation

Advantech

Advantech PCM-9387 Manuel d'installation et d'exploitation

Advantech

Advantech AIMB-340F series Manuel utilisateur

Advantech

Advantech AIMB-562 KIOSK Manuel utilisateur

Advantech

Advantech PCM-4372 Manuel d'installation et d'exploitation

Advantech

Advantech PCM-3375 Manuel utilisateur

Advantech

Advantech RSB-4210 Evaluation Kit Manuel utilisateur

Advantech

Advantech AIMB-506 Manuel utilisateur

Advantech

Advantech MIO-2263 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
