Advantech AIMB-281 Manuel utilisateur

User Manual

AIMB-281

Intel® Core™ i7/i5/i3/Celeron

LGA1155 Mini-ITX with CRT/DVI/

LVDS, 6 COM, Dual LAN, PCIe x4

AIMB-281 User Manual ii

The documentation and software included with this product are copyrighted 2015 by

Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to

improve the products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or transmitted in any

form or by any means without the prior written permission of Advantech Co., Ltd. All

information provided in this manual is intended to be accurate and reliable. However,

Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements

of the rights of third parties that may result from its use.

Acknowledgements

IBM and PC are trademarks of International Business Machines Corporation.

Intel® Core™ i7/i5/i3, Pentium®, Celeron® are trademarks of Intel Corporation.

WinBond is a trademark of Winbond Corporation.

All other product names or trademarks are properties of their respective owners.

Part No. 2006028100 Edition 1

Printed in China June 2015

iii AIMB-281 User Manual

A Message to the Customer

Advantech Customer Services

Every Advantech product is built with exact specifications to ensure reliable perfor-

mance in the harsh and demanding conditions typical of industrial environments.

Whether this Advantech equipment is destined for the laboratory or factory floor, be

assured that your product will provide the reliability and ease of operation for which

Advantech has become renowned.

Because your satisfaction is our primary concern, we have produced this guide to

Advantech’s customer services. To ensure you receive the full benefit of our services,

please follow the instructions provided below.

Technical Support

We want customers to experience the maximum performance from our products.

Should you encounter technical difficulties, we are available to provide assistance.

For the most frequently asked questions, we have provided answers in the product

documentation. Generally, these answers are substantially more detailed than those

provided over the phone.

Please consult this manual first when you encounter a problem. If you still cannot find

the answer, gather all the information or questions that apply to your problem, and

with the product on hand, call your dealer. Our dealers are well trained and ready to

offer the support required to get the most from Advantech products. The majority of

problems reported are minor and can be easily resolved over the phone.

In addition, free technical support from Advantech engineers is available every busi-

ness day. We are always ready and willing to give advice on application requirements

or specific information regarding the installation and operation of any of our products.

AIMB-281 User Manual iv

Declaration of Conformity

FCC Class B

This device complies with the requirements specified in Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

This device must not cause harmful interference.

This device must accept any interference received, including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits of a Class B dig-

ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro-

vide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Opera-

tion of this device in a residential area is likely to cause harmful interference. In such

cases, users are required to correct the interference at their own expense. Users are

advised that any equipment changes or modifications not expressly approved by the

party responsible for compliance will void the compliance with FCC Rules, and there-

fore, the user's authority to operate the equipment.

CPU Compatibility

Caution! Batteries may explode if incorrectly installed. Do not attempt to

recharge, force open, or heat the battery. Replace the battery only with

the same or equivalent type recommended by the manufacturer. Dis-

card used batteries according to the manufacturer's instructions.

Test Item Description

CPU Family Base Freq Power L3 Cache Mfg Tech Result

Intel i5-3550 3.3GHz 77W 6MB 22nm PASS

Intel i5-3570T 2.3GHz 45W 6MB 22nm PASS

Intel i5-3550S 3.0GHz 65W 6MB 22nm PASS

Intel i5-3450 3.1GHz 77W 6MB 22nm PASS

Intel i5-3570K 3.4GHz 77W 6MB 22nm PASS

Intel i5-2500T 2.3GHz 45W 6MB 32nm PASS

Intel i7-3770T 2.5GHz 45W 8MB 22nm PASS

Intel i7-3770S 3.1GHz 65W 8MB 22nm PASS

Intel i7-3770 3.4GHz 77W 8MB 22nm PASS

Intel i7-3770K 3.5GHz 77W 8MB 22nm PASS

Intel i7-2600K 3.4GHz 95W 8MB 32nm PASS

Intel i3-2125 3.3GHz 65W 3MB 32nm PASS

Intel i3-3220 3.3GHz 55W 3MB 22nm PASS

Intel Xeon E3-1275 3.4GHz 84W 8MB 22nm PASS

Intel Xeon E3-1225 3.1GHz 95W 6MB 32nm PASS

Intel Pentium G620 2.6GHz 65W 3MB 32nm PASS

Intel Celeron G460 1.8GHz 35W 1.5MB 32nm PASS

v AIMB-281 User Manual

Memory Compatibility

Memory Module Information

Item MEM-01 MEM-02 MEM-03

Module Vendor Transcend Transcend Transcend

Module P/N TS1GSK64V3H TS256MSK64V3N TS256MSK64V6N

Chip Vendor Micron Hynix Micron

Chip P/N 2AD27 D9PBC H5TQ2G83CFR IVM77 D9PFJ

Capacity 8 GB 2 GB 2 GB

Unbuffered/Regis- Unbuffered Unbuffered Unbuffered

Type SO DIMM SO DIMM SO DIMM

Speed 1333 1333 1600

ECC/Non-ECC Non-ECC Non-ECC Non-ECC

Wide Temp Support NIL NIL NIL

Device ID

Memory Module Information

Item MEM-04 MEM-05MEM-06

Module Vendor ATP DSL DSL

Module P/N AW24M64F8BLK0S DDR3 1600 2GB CL11 DDR3 1333 4GB CL9

Chip Vendor SEC SEC Elpida

Chip P/N 216 HYKO 113 HCK0 J4208BASE-DJ-F

Capacity 8 GB 2 GB 4 GB

Unbuffered/Regis- Unbuffered Unbuffered Unbuffered

Type SO DIMM SO DIMM SO DIMM

Speed 160016001066

ECC/Non-ECC Non-ECC Non-ECC Non-ECC

Wide Temp Support NIL NIL NIL

Device ID

Memory Module Information

Item MEM-07MEM-08MEM-09

Module Vendor Transcend Kingston ADATA

Module P/N TS128MSK64V1U KVR1333D3S8S9/2G HY7YG1B16

Chip Vendor Elpida Elpida Hynix

Chip P/N J1108BDBG-DJ-F J2108BCSE H5TQ1G83BFR

Capacity 1 GB 2 GB 2 GB

Unbuffered/Regis- Unbuffered Unbuffered Unbuffered

Type SO DIMM SO DIMM SO DIMM

Speed 1066 1333 1066

AIMB-281 User Manual vi

ECC/Non-ECC Non-ECC Non-ECC Non-ECC

Wide Temp Support NIL NIL NIL

Device ID SD3-039/040SD3-126/127 SD3-087/088

Memory Module Information

Item MEM-10 MEM-11 MEM-12

Module Vendor Innodisk Innodisk Transcend

Module P/N M3SP-2GMJCL0C-M M3SP-4GMJDL0C-M JM1333KSN-2G

Chip Vendor Micron Micron SpecTek

Chip P/N IQM22 D9PFJ IIM22 D9PFJ PE901

Capacity 2 GB 4 GB 2 GB

Unbuffered/Regis- Unbuffered Unbuffered Unbuffered

Type SO DIMM SO DIMM SO DIMM

Speed 160016001333

ECC/Non-ECC Non-ECC Non-ECC Non-ECC

Wide Temp Support NIL NIL NIL

Device ID SD3-142/143 SD3-145/146 SD3-116/117

Memory Module Information

Item MEM-13 MEM-14 MEM-15

Module Vendor DSL Panram ADATA

Module P/N DDR3 1333 2GB CL9 200D38G328,NB,

K2BASESF EL73I1B0873ZV

Chip Vendor Elpida Elpida

Chip P/N J1108BDSE-DJ-F F140X8A09481 J2108BCSE-DJ-F

Capacity 2 GB 8 GB 2 GB

Unbuffered/Regis- Unbuffered Unbuffered Unbuffered

Type SO DIMM SO DIMM SO DIMM

Speed 1333 1333 1333

ECC/Non-ECC Non-ECC Non-ECC Non-ECC

Wide Temp Support NIL NIL NIL

Device ID SD3-019/020SD3-140/141 SD3-132/133

Memory Module Information

Item MEM-16 MEM-17 MEM-18

Module Vendor Kingston PQI Apacer

Module P/N KVR1066D3S7/1G MFCBR502SA0101 78.A2GC3.421

Chip Vendor Kingston Hynix Elpida

Chip P/N D1288JPNDPLD9U H5TQ2G83AFR J1108BDBG-DJ-F

Capacity 1 GB 4 GB 2 GB

Unbuffered/Regis- Unbuffered Unbuffered Unbuffered

vii AIMB-281 User Manual

Type SO DIMM SO DIMM SO DIMM

Speed 1066 1066 1066

ECC/Non-ECC Non-ECC Non-ECC Non-ECC

Wide Temp Support NIL NIL NIL

Device ID SD3-064/065 SD3-075/076 SD3-027/028

Memory Module Information

Item MEM-19 MEM-20 MEM-21

Module Vendor Kingston hynix Transcend

Module P/N KVR1333D3S9/1G HMT112S6TFR8C-H9 TS512MSK64V1N

Chip Vendor Kingston Hynix Hynix

Chip P/N D1288JPNDPLD9U H5TQ1G83TFR H5TQ2G83BFR

Capacity 1 GB 1 GB 4 GB

Unbuffered/Regis- Unbuffered Unbuffered Unbuffered

Type SO DIMM SO DIMM SO DIMM

Speed 1333 1333 1066

ECC/Non-ECC Non-ECC Non-ECC Non-ECC

Wide Temp Support NIL NIL NIL

Device ID SD3-066/067 SD3-128/129 SD3-055/056

Memory Module Information

Item MEM-22 MEM-23 MEM-24

Module Vendor Transcend PQI ADATA

Module P/N TS256MSK64V6N MFCBR402PA0105 AD73I1A0873EG

Chip Vendor Micron Hynix ADATA

Chip P/N IVM77 D9PFJ H5TQ1G83BFR AD3BC8A-13339H

Capacity 2 GB 2 GB 1 GB

Unbuffered/Regis- Unbuffered Unbuffered Unbuffered

Type SO DIMM SO DIMM SO DIMM

Speed 16001066 1333

ECC/Non-ECC Non-ECC Non-ECC Non-ECC

Wide Temp Support NIL NIL NIL

Device ID SD3-151/152 SD3-077/078 SD3-123/124

AIMB-281 User Manual viii

*Use external VGA card to perform this test, DO NOT use on-board internal VGA.

Ordering Information

*() not populated on MP version.

Product Warranty (2 years)

Advantech warrants the original purchaser that all its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products that have been repaired or altered by

persons other than the repair personnel authorized by Advantech, or that have been

subject to misuse, abuse, accident, or improper installation. Advantech assumes no

liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most

customers never need to use our repair service. If an Advantech product is defective,

it will be repaired or replaced at no charge during the warranty period. For out-of-war-

ranty repairs, customers are billed according to the cost of replacement materials,

service time, and freight. Please consult your dealer for more details.

If you believe your product to be defective, please follow the steps outlined below.

1. Collect all information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and record any onscreen messages displayed when the

problem occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any relevant information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandise

authorization) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a completed Repair and Replacement

Order card, and proof of purchase date (such as a photocopy of your sales

receipt) in a shippable container. Products returned without a proof of purchase

date are not eligible for warranty service.

5. Write the RMA number clearly on the outside of the package, then ship the

package prepaid to your dealer.

Memory No. Test Procedure Result

MEM-01

System can boot up Pass

Check if BIOS can detect correct capacity and speed Pass

System can power on/off x 10 Pass

Run Memtest86 for 3 loops Pass

Run Prime95 for 1 hour Pass

Part Number Chipset CRT DVI LVDS GbE LAN COM

AIMB-281G2-00A1E H61 Yes Yes Yes 2 6

ix AIMB-281 User Manual

Initial Inspection

Before installing the motherboard, please check to ensure that the following materials

have been shipped:

1 x AIMB-281 mini-ITX motherboard

1 x driver CD

2 x COM cable (2 x 10 pin)

2 x SATA cable (2 in 1,7-pins)

1 x I/O shield

1 x startup manual

1 x warranty card

If any of the above items are missing or damaged, please contact your distributor or

sales representative immediately. We have carefully inspected the AIMB-281

mechanically and electrically before shipment. The product should be free of marks

and scratches and in perfect working order upon receipt. While unpacking, check the

AIMB-281 device for signs of shipping damage (for example, damaged box,

scratches, or dents). If the product is damaged or fails to meet the specifications,

notify our service department or your local sales representative immediately. Also

remember to notify the carrier. Retain the shipping carton and packing material for

inspection by the carrier. After inspection, we will make arrangements to repair or

replace the unit.

AIMB-281 User Manual x

Autres manuels pour AIMB-281

Table des matières

Autres manuels Advantech Carte mère

Advantech

Advantech POD-6552 Manuel d'installation et d'exploitation

Advantech

Advantech AIMB-214 Manuel utilisateur

Advantech

Advantech PCM-9365 Manuel d'installation et d'exploitation

Advantech

Advantech GMB-910 Manuel utilisateur

Advantech

Advantech AIMB-233 Manuel utilisateur

Advantech

Advantech AIMB-212 Manuel utilisateur

Advantech

Advantech PCA-6166 Manuel utilisateur

Advantech

Advantech CPC-2245/N Manuel d'installation et d'exploitation

Advantech

Advantech AIMB-740-6CB1 Manuel utilisateur

Advantech

Advantech i915GV-INA Series Manuel utilisateur

Advantech

Advantech PCA-6752 Manuel d'installation et d'exploitation

Advantech

Advantech PCM-3362Z Manuel d'installation et d'exploitation

Advantech

Advantech AIMB-706 Manuel utilisateur

Advantech

Advantech PCM-9587 A2 Manuel d'installation et d'exploitation

Advantech

Advantech AIMB-567 Manuel utilisateur

Advantech

Advantech AIMB-341 Manuel utilisateur

Advantech

Advantech PPC-MB-610 Manuel d'installation et d'exploitation

Advantech

Advantech PCE-7128 Manuel d'installation et d'exploitation

Advantech

Advantech AIMB-270 Manuel utilisateur

Advantech

Advantech PCM-3353 Manuel utilisateur

Advantech

Advantech AIMB-308 Manuel d'installation et d'exploitation

Advantech

Advantech ACP-2000MB Manuel utilisateur

Advantech

Advantech AIMB-275 A2 Manuel utilisateur

Advantech

Advantech PCM-4862 Manuel d'installation et d'exploitation

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
