STARTUP MANUAL

MIC-3327 Startup Manual 1

MIC-3327DC01-A43E

3U CompactPCI® Intel® Atom™ N2600 Controller

Packing List

Before you begin installing your module, please make

sure that the following materials have been shipped:

MIC-3327 Series CPU Board

Driver CD

Startup Manual

If any of these items are missing/damaged, contact

your distributor or sales representative immediately.

Overview

The MIC-3327 is a 3U CompactPCI®system

control board, with an Intel® Atom™ N2600

1.6GHz processor and highly integrated Intel®

NM10 Express chipset. It supports on board DDR3

SDRAM up to 2 GMB and dual Gigabit Ethernet.

The MIC-3327 is a powerful 3U CompactPCI

controller which can fulll your need in any mission

critical applicaitons, such as transportaiton, trafc

control, and military defense applicaitons.

User Manualtion

For detailed information on this product, refer to:

CD:MIC-3327\Manual\MIC-3327_User_Manual.pdf

Notes

For more information on this and other Advantech

products, please visit our websites at:

http://www.advantech.com

http://www.advantech.com/eAutomation

For technical support and service:

http://www.advantech.com.tw/eservice

This manual is for MIC-3327.

Part No: 2003332700 1st Edition

February 2014

Declaration of Conformity

FCC Class A

This equipment has been tested and found to comply

with the limits for a Class A digital device, pursuant

to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference when the equipment is operated

in a commercial environment. This equipment

generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance

with the instruction manual, may cause harmful

interference to radio communications. Operation

of this equipment in a residential area is likely to

cause interference in which case the user is required

to correct interference at his own expense.

This product has passed the CE test for environmental

specifications when shielded cables are used

for external wiring. We recommend the use of

shielded cables. This kind of cable is available from

Advantech. Please contact your local representative.

2 MIC-3327 Startup Manual

Speciﬁcations

Certication: CE, FCC, Class A

CPU: Intel®Atom N2600 1.6 GHZ

BIOS: AMI UEFI 16Mbit SPI BIOS

System Chipset: Intel NM10

Memory:

–SDRAM: DDR3 800 MHz Support 2G

Graphics:

–Chipset: Intel Gfx integrated in Atom Processor

–Resolution: 1600 x 1200

Ethernet:

–Interface: 1000/100/10M Base-T Giga Ethernet

–Controller: Intel @ 82574L Ethernet Controller

–Connector: RJ-45*2 (Pins reserved on PCB

next to LAN2 for customer lead wire)

Bus:

–PCI Bus: 7 x 32 bit / 33 MHz Compact PCI

Bus Master Interface( PCIe-PCI Bridge

PERICOM

–PI7C9X110)

Serial:

–Interface: RS-232/422/485 Selectable

(COM1~COM4)

–UART: 954 compatible

–Data bits: 5, 6, 7, 8

–Stop Bits: 1, 1.5, 2

–Parity: None, Even, Odd

–Speed: 50 ~ 115.2 Kbps

–Connector: COM1 (9 PIN, DB9 Front Panel)

COM2~COM4 (5 PIN, J2)

Audio:

–Line-in (DB9: 7, 8 PIN)

–Line-out (DB9: 2, 3 PIN) (Pins reserved on

PCB next to DB9 for customer lead wire)

–MIC-in: 3.5’’ Audio Connector

SATA: 1 x SATA interface, data transfer rate up

to 300 MB/S

USB: 3 x USB 2.0 channels up to 480Mbps, 2 as

front I/O

P-IDE: 1 x CompactFlash Slot Type II

Watchdog Timer: 256 levels timer interval, from

1 to 255 sec or min setup by software

Front Panel Function(8HP):

–COM1: 1 x DB9, RS-232/422/485

–Audio: 1 x DB9, 1 x 3.5’’ Audio Connector

–Ethernet: 2 x RJ-45 Connector with LED

–VGA: 1 x 15pin D-SUB Connector

–USB: 2 x USB2.0, 4pin Connector

–Button: Reset Button

–LED: Power, HDD

Environment:

–Humidity: 5~95%(non-condensing)

–Operation Temp: -20 ~ 60°C

–Storage Temp: -40 ~ 80°C

Physical:

–Dimensions (L x H): 160 x 100 mm (3U)

–Weight: 0.8 Kg

MIC-3327 Startup Manual 3

Jumpers and Connections

Connector Description

Figure 1 -MIC-3327CB Board Connector Locations (1F)

Figure 2 -MIC-3327DAU Board Connector Locations (2F)

MIC-3327 Startup Manual 4

Connector Function Description

1F-SW1 Reset Reset Button

1F-CN1 SOM SOM Connector

1F-CN2 VGA D-Sub 15-pin (Female) on Front side panel

1F-CN4 LAN1 10/100/1000Base-T Ethernet on Front side panel

1F-CN6 USB1 USB1 Type-A Female on Front side panel.

1F-CN8 B to B Connector B to B Connector

1F-CN9 CF CF Connector

1F-CN10 USB2 USB2 Type-A Female on Front side panel

1F-J1 CPCI Connector CPCI Connector

1F-J2 CPCI Connector CPCI Connector

2F-CN2 SATA connector Serial ATA 22P connector

2F-CN3 Audio(Line in/ Line out) Audio connector

2F-CN4 MIC MIC connector

2F-CN5 COM1 DB9 connector

2F-CN6 COM1 Type Select RS-232/422/485 Selection

2F-CN8 Audio Jumper Audio(Line in/ Line out/ MIC)

2F-CN9 LAN2 Jumper 10/100/1000Base-T Ethernet

2F-CN10 LAN2 10/100/1000Base-T Ethernet on Front side panel.

2F-XYM1 B to B Connector B to B Connector

2F-SW1 COM2~COM4 COM2/COM3/COM4 Type Selection

2F-SW2 COM1~COM4 RS-422 Master/ Slave

Select

COM1/COM2/COM3/COM4 RS-422 Master/ Slave

Selection

Table 1 -MIC-3327 Connector Description

MIC-3327 Startup Manual 5

Card Installation

The CompactPCI connectors are rm and rigid, but require careful handling while plugging and unplugging.

Improper installation of a card can easily damage the backplane of the chassis.

The inject/eject handle of MIC-3327 helps you install and remove the card easily and safely. Follow the

procedure below to install the MIC-3327 into a chassis:

To install a card:

1. Hold the card vertically. Be sure that the card is pointing in the correct direction. The components of the

card should be pointing to the right.

2. Holding the lower handle, pull out the red portion in the middle of the handle to unlock it.

Caution! Keep your ngers away from the hinge to prevent them from getting pinched.

3. Insert the card into the chassis by sliding the upper and lower edges of the card into the card guide.

4. Push the card into the slot gently by sliding the card along the card guide until the handles meet the

rectangular holes of the cross rails.

Note: If the card is correctly positioned and has been slid all the way into the chassis, the handle should

match the rectangular holes. If not, remove the card from the card guide and repeat step 3 again. Do not try to

install a card by forcing it into the chassis.

5. Lift the lower handle up to push the card into place.

To remove a card:

1. Unscrew the four screws on the front panel.

2. Press the lower handle down to release the card from the backplane.

3. Slide the card out.

Figure 3 -Chassis Installation/ Removal

6 MIC-3327 Startup Manual

J1 & J2 Connectors

Pin A B C D E F

1 5V -12V TRST# +12V 5V GND

2 TCK 5V TMS TDO TDI GND

3 INTA# INTB# INTC# 5V INTD# GND

4 RSV1 GND V(I/O) INTP INTS(SERIRQ) GND

5 RSV2 RSV3 RST# GND GNT0# GND

6 REQ0# GND 3.3V CLK0 AD[31] GND

7 AD[30] AD[29] AD[28] GND AD[27] GND

8 AD[26] GND V(I/O) AD[25] AD[24] GND

9 C/BE[3] IDSEL AD[23] GND AD[22] GND

10 AD[21] GND 3.3V AD[20] AD[19] GND

11 AD[18] AD[17] AD[16] GND C/BE[2]# GND

15 3.3V FRAME# IRDY# GND TRDY# GND

16 DEVSEL# GND V(I/O) STOP# LOCK# GND

17 3.3V REQA# GNTA# GND PERR# GND

18 SERR# GND 3.3V PAR C/BE[1]# GND

19 3.3V AD[15] AD[14] GND AD[13] GND

20 AD[12] GND V(I/O) AD[11] AD[10] GND

21 3.3V AD[9] AD[8] M66EN C/BE[0]# GND

22 AD[7] GND 3.3V AD[6] AD[5] GND

23 3.3V AD[4] AD[3] 5V AD[2] GND

24 AD[1] 5V V(I/O) AD[0] ACK64# GND

25 5V REQ64# ENUM# 3.3V 5V GND

Table 2 -MIC-3327 J1 Connectors

MIC-3327 Startup Manual 7

Pin A B C D E F

1/26 CLK1 GND REQ1# GNT1# REQ2# GND

2/27 CLK2 CLK3 GNT2# REQ3# GND

3/28 CLK4 GND GNT3# REQ4# GNT4# GND

4/29 V(I/O) GND GND

5/30 COM2_TX+ V(I/O) GND

6/31 COM2_TX- COM2_TX COM2_RX GND COM2_CTS GND

7/32 COM2_RX+ GND V(I/O) COM2_RTS GND

8/33 COM2_RX- COM3_TX COM3_RX GND COM3_CTS GND

9/34 COM3_TX+ GND V(I/O) COM3_RTS GND

10/35 COM3_TX- COM3_RX+ COM3_RX- GND GND

11/36 COM4_TX+ GND V(I/O) GND

12/37 COM4_TX- COM4_TX COM4_RX GND COM4_CTS GND

13/38 COM4_RX+ GND V(I/O) COM4_RTS GND

14/39 COM4_RX- USB+ USB- GND GND

15/40 GND REQ5# GNT5# GND

16/41 GND GND

17/42 GND REQ6# GNT6# GND

18/43 GND GND

19/44 GND GND

20/45 CLK5 GND GND

21/46 CLK6 GND GND

22/47 GND

Table 3 -MIC-3327 J2 Connectors
