ADTRAN NetVanta 1531 Series Manuel

NetVanta 1531/1534/1544 Series

Hardware Installation Guide

1700570F1 NetVanta 1531

1700571F1 NetVanta 1531P

1702590G1 NetVanta 1534

1702591G1/G2 NetVanta 1534P

1702544G1 NetVanta 1544

1702545G1/G2 NetVanta 1544P

1700546G1#120 NetVanta 1544F with 120 VAC Power Supply

1700546G1#240 NetVanta 1544F with 240 VAC Power Supply

1200884G1 Wall Mounting Bracket (NetVanta 1531/1534/1544 Series)

1700512F1 Dual Wall Mounting Bracket

1700511F1 Rack Mounting Bracket (NetVanta 1531 Series)

1700508F1 19-inch Dual Mounting Tray

1700530F1 NetVanta 1131 RPS/EPS

1700532F1 NetVanta 1131 RPS Cable

1700533F1 NetVanta 1131 EPS Cable

1700534F1 NetVanta 1131 Dual Mounting Tray

61702590G1-34H

August 2019

Trademarks NetVanta 1531/1534/1544 Series

Trademarks

Any brand names and product names included in this manual are trademarks, registered trademarks, or

trade names of their respective holders.

To the Holder of the Manual

The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change

the contents without prior notice.

In no event will ADTRAN be liable for any special, incidental, or consequential damages or for

commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.

Software Licensing Agreement

Each ADTRAN product contains a single license for ADTRAN-supplied software. Pursuant to the

Licensing Agreement, you may: (a) use the software on the purchased ADTRAN device only and (b) keep

a copy of the software for backup purposes. This Agreement covers all software installed on the system, as

well as any software available on the ADTRAN website. In addition, certain ADTRAN systems may

contain additional conditions for obtaining software upgrades.

Changes or modifications to this unit not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

901 Explorer Boulevard

P.O. Box 140000

Huntsville, AL 35814-4000

Phone: (256) 963-8000

Printed in U.S.A.

NetVanta 1531/1534/1544 Series Conventions

Conventions

Warnings provide information that could prevent injury or endangerment to human

life.

Cautions signify information that could prevent service interruption or damage to the

equipment.

Notes provide additional useful information.

Safety Instructions NetVanta 1531/1534/1544 Series

Safety Instructions

When using your telephone equipment, please follow these basic safety precautions to reduce the risk of

fire, electrical shock, or personal injury:

1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a

wet basement, or near a swimming pool.

2. Avoid using a telephone (other than a cordless type) during an electrical storm. There is a remote

risk of shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord, power supply, and batteries indicated in the manual. Do not dispose of

batteries in a fire. They may explode. Check with local codes for special disposal instructions.

5. The socket-outlet shall be installed near the equipment and shall be easily accessible.

If any of the following conditions occur, unplug the product from the electrical outlet and replace the part

or contact your qualified service personnel:

Additional safety guidelines, such as Waste Electrical and Electronic Equipment (WEEE),

are given in the document NetVanta Safety and Regulatory Information available at



https://supportforums.adtran.com.

These units contain no user-serviceable parts. They should only be serviced by qualified

service personnel.

This equipment incorporates double pole/neutral fusing. If the neutral fuse opens and the

line fuse does not open, voltage could still be present in the unit.

1. The power cable, extension cable, or plug is damaged.

2. An object has fallen into the product.

3. The product has been exposed to water.

4. The product has been dropped or damaged.

5. The product does not operate correctly when you follow the operating instructions.

Save These Important Safety Instructions

NetVanta 1531/1534/1544 Series FCC Radio Frequency Interference Statement

FCC Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio frequencies. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

Canadian Emissions Requirements

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus

as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the

Department of Communications.

Cet appareil numérique respecte les limites de bruits radioelectriques applicables aux appareils numériques

de Class A prescrites dans la norme sur le materiel brouilleur: “Appareils Numériques,” NMB-003 edictee

par le ministre des Communications.

Toll Fraud Liability

Be advised that certain security risks are inherent in the use of any telecommunications or networking

equipment, including but not limited to, toll fraud, Denial of Service (DoS) attacks, loss or theft of data, and the

unauthorized or illegal use of said equipment. ADTRAN OFFERS NO WARRANTIES, EITHER

EXPRESSED OR IMPLIED, REGARDING THE PREVENTION, DETECTION, OR DETERRENCE OF

TOLL FRAUD, NETWORKING ATTACKS, OR UNAUTHORIZED, ILLEGAL, OR IMPROPER USE OF

ADTRAN EQUIPMENT OR SOFTWARE. THEREFORE, ADTRAN IS NOT LIABLE FOR ANY LOSSES

OR DAMAGES RESULTING FROM SUCH FRAUD, ATTACK, OR IMPROPER USE, INCLUDING, BUT

NOT LIMITED TO, HUMAN AND DATA PRIVACY, INTELLECTUAL PROPERTY, MATERIAL

ASSETS, FINANCIAL RESOURCES, LABOR AND LEGAL COSTS. Ultimately, the responsibility for

securing your telecommunication and networking equipment rests with you, and you are encouraged to review

documentation regarding available security measures, their configuration and implementation, and to test such

features as is necessary for your network.

Service and Warranty

For information on the service and warranty of ADTRAN products, visit the Support section of the

ADTRAN website at http://www.adtran.com.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Physical Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

NetVanta 1531 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

NetVanta 1534 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

NetVanta 1544 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Mounting Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Supplying Power to the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Installing a CompactFlash Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

NetVanta 1131 RPS/EPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

NetVanta 1131 Series Shipping Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

NetVanta 1131 Front Panel Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

NetVanta 1131 Rear Panel Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

LED Behaviors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Installing the NetVanta 1131 RPS/EPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Rack Mounting the NetVanta 1131 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Wall Mounting the NetVanta 1131 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Connecting the NetVanta 1131 and the NetVanta Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Powering the NetVanta 1131 and the NetVanta Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Appendix A. Connector Pin Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

List of Figures

Figure 1. NetVanta 1531 Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Figure 2. NetVanta 1531 Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Figure 3. NetVanta 1531P Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Figure 4. NetVanta 1531P Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Figure 5. NetVanta 1534 Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Figure 6. NetVanta 1534 Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Figure 7. NetVanta 1534P Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Figure 8. NetVanta 1534P Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 9. NetVanta 1544 Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Figure 10. NetVanta 1544 Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Figure 11. NetVanta 1544P Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Figure 12. NetVanta 1544P Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Figure 13. NetVanta 1544F Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Figure 14. NetVanta 1544F Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Figure 15. NetVanta Rack Mounting Brackets and Kensington Lock Slot . . . . . . . . . . . . . . . . . . . . . . . . 31

Figure 16. Dual Mounting Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Figure 17. NetVanta 1531/1531P/1534/1544 Wallmount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Figure 18. NetVanta 1531/1531P/1534/1544 Dual Wallmount Installation . . . . . . . . . . . . . . . . . . . . . . . 35

Figure 19. NetVanta 1534P/1544P/1544F Wallmount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Figure 20. CompactFlash Card Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Figure 21. NetVanta 1131 Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Figure 22. NetVanta 1131 Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Figure 23. Rack Mounting the NetVanta 1131 Using the Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Figure 24. Rack Mounting the NetVanta 1131 Using the Dual Mounting Tray . . . . . . . . . . . . . . . . . . . . 43

Figure 25. Wall Mounting the NetVanta 1131 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

List of Tables

Table 1. Front Panel LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Table 2. Front Panel LED Behaviors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Table A-1. CONSOLE Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Table A-2. 1000Base-T Gigabit Ethernet Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Table A-3. SFP Slot Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

1. INTRODUCTION

The NetVanta 1531/1534/1544 Series Gigabit Switches include the NetVanta 1531, NetVanta 1531P

(Power over Ethernet (PoE)), NetVanta 1534, NetVanta 1534P (PoE), NetVanta 1544, NetVanta 1544P

(PoE), and NetVanta 1544F.

In this document, the term NetVanta 1531/1534/1544 Series means all of the units

collectively. If a statement only applies to one particular switch, the text refers to that

switch individually.

This hardware installation guide lists the NetVanta 1531/1534/1544 Series units’ physical characteristics

and product specifications, introduces basic functionality, and provides installation instructions.

•Physical Descriptions on page 10

•Product Specifications on page 26

•Unit Installation on page 29

•NetVanta 1131 RPS/EPS on page 38

For additional information on mounting options, suppling power, upgrading memory, installing a CompactFlash

card, and installing the NetVanta 1131 RPS/EPS refer to the following sections:

•Mounting Options on page 30

•Supplying Power to the Unit on page 37

•Installing a CompactFlash Card on page 37

•Installing the NetVanta 1131 RPS/EPS on page 41

For information on switch configuration for a specific application, refer to the configuration guides provided on

the ADTRAN Support Community. For details on the command line interface (CLI), refer to the AOS

Command Reference Guide. All other related documents are also available online at

http://supportforums.adtran.com.

Physical Descriptions NetVanta 1531/1534/1544 Series

2. PHYSICAL DESCRIPTIONS

NetVanta 1531 Series

The NetVanta 1531 Series is a Layer 3 Lite managed switch. The entire series runs ADTRAN Operating

System (AOS), is managed through an EIA-232 CONSOLE port (DB-9), Telnet session, or web-based

graphical user interface (GUI), and is RoHS compliant (telecommunications exemption). The

NetVanta 1531 Series units are described in the following sections.

The NetVanta 1531 Series is housed in a 1U-high, rack-mountable metal enclosure that is half the width of a

standard 19-inch rack, allowing two units to be mounted side by side using an optional dual mounting tray. It

includes a universal AC power supply and the front panel contains 10 10/100/1000Base-T Ethernet interfaces

that are accessed via standard RJ-45 connectors. Two 1000Base-X small form-factor pluggable (SFP) slots

(supporting industry standard small SFP modules) are available on the front panel for high-speed uplink via

fiber. The NetVanta 1531 EIA-232 CONSOLE port (DB-9) is located on the front panel.

SFP Module Slots

The NetVanta 1531 Series units support two 1000Base-X SFP slots on the front panel that accept a number of

industry standard SFP modules. The SFP modules provide Gigabit Ethernet fiber connectivity for high-speed

uplinks or switch stacking. For a list of supported SFP modules, visit the ADTRAN website at

http://www.adtran.com.

Power over Ethernet

The NetVanta 1531P unit provides the same basic functionality as the NetVanta 1531 product. PoE provides the

ability to detect attached powered devices (PDs), and deliver 48 VDC to the PD via Ethernet cabling. The

NetVanta 1531P is fully compliant with the IEEE 802.3af PoE and IEEE 802.3at PoE+ standards. By default,

the PoE switch discovers and provides power to IEEE-compliant PDs. The NetVanta 1531P also supports legacy

PDs.

NetVanta 1531 Series Shipping Contents

Each NetVanta 1531 Series unit is shipped in its own cardboard shipping carton. Open each carton carefully, and

avoid deep penetration into the carton with sharp objects.

After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit,

immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on

the ADTRAN website at http://www.adtran.com/support).

Domestic shipments of the NetVanta 1531 Series includes the following items:

• NetVanta 1531 base unit

• A detachable power cable with a grounded, three-prong plug

• Quick start guide

International shipments of the NetVanta 1531 Series includes the following items:

• NetVanta 1531 base unit

• All necessary power cords

• Quick start guide

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ADTRAN Matériel réseau

ADTRAN

ADTRAN 1200864L1 Manuel utilisateur

ADTRAN

ADTRAN HDSL 3192 HTU-C Mode d’emploi

ADTRAN

ADTRAN Total Access 5006 Manuel utilisateur

ADTRAN

ADTRAN NetVanta Series Manuel utilisateur

ADTRAN

ADTRAN Express 3000 Manuel utilisateur

ADTRAN

ADTRAN Total Access 300 Series Manuel du produit

ADTRAN

ADTRAN ATLAS 800 Series Module QUAD E1 Guide de l'utilisateur

ADTRAN

ADTRAN 4202023L1 Manuel utilisateur

ADTRAN

ADTRAN Total Reach DDS-DP 5 Series Mode d’emploi

ADTRAN

ADTRAN Octal IDSL DSLAM Octal IDSL Manuel utilisateur

ADTRAN

ADTRAN eSBC Manuel utilisateur

ADTRAN

ADTRAN DSU 56/64 Manuel utilisateur

ADTRAN

ADTRAN 1200630L1 Manuel utilisateur

ADTRAN

ADTRAN TR OCU DP Mode d’emploi

ADTRAN

ADTRAN Express 3000 Manuel utilisateur

ADTRAN

ADTRAN NetVanta 2000 Series Guide de l'utilisateur

ADTRAN

ADTRAN DSU IV ESP Manuel utilisateur

ADTRAN

ADTRAN 6540 Manuel du produit

ADTRAN

ADTRAN Total Access 300 Series Manuel du produit

ADTRAN

ADTRAN OSU 300 Manuel utilisateur

ADTRAN

ADTRAN NetVanta 4660 Manuel utilisateur

ADTRAN

ADTRAN 1442823F1 Manuel utilisateur

ADTRAN

ADTRAN Total Access 1500 Total Reach DDS-DP Manuel utilisateur

ADTRAN

ADTRAN SHDSL V.35 LTU Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur
