6304W ONU Gateway

Configuration Guide

Version 1.01

ubiQuoss Inc.

www.ubiQuoss.com

Specifications and product availability are subject to change without notice.

© 2017 ubiQuoss. All rights reserved.

6304W Configuration Guide

Contents

CHAPTER 1 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

CHAPTER 2 Logging into the Web GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

CHAPTER 3 Viewing Device Information . . . . . . . . . . . . . . . . . . . . . . . . .7

CHAPTER 4 Viewing WAN Interface Information. . . . . . . . . . . . . . . . . . .9

CHAPTER 5 Configuring WAN Interfaces . . . . . . . . . . . . . . . . . . . . . . . .11

CHAPTER 6 Configuring Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

CHAPTER 7 Viewing Wi-Fi Information . . . . . . . . . . . . . . . . . . . . . . . . .19

CHAPTER 8 Configuring Voice Service . . . . . . . . . . . . . . . . . . . . . . . . . .21

CHAPTER 9 Configuring NTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

CHAPTER 10 Configuring Static Routing. . . . . . . . . . . . . . . . . . . . . . . . . .27

CHAPTER 11 Restarting the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

CHAPTER 12 Reverting to the Default Setting . . . . . . . . . . . . . . . . . . . . . .33

CHAPTER 13 Upgrading Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

CHAPTER 14 Configuring Backups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Contents

ii 6304W Configuration Guide

CHAPTER 15 Restoring Configuration Files . . . . . . . . . . . . . . . . . . . . . . . 39

CHAPTER 16 Performing Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

6304W Configuration Guide 1

CHAPTER 1 Getting Started

Default Settings

The following table lists the default settings for the four WAN interfaces to provide

triple play services.

TABLE 1-1. Default Settings

Interface Type VLAN Binding LAN Ports Service

1_TR069_R_VID_400 IPoE 400 TR-069

2_VOICE_R_VID_200 IPoE 200 PHONE1, PHONE2 Voice

3_INTERNET_R_VID_100 IPoE 100 LAN1, Wireless(2.4G/

5G)

Internet

4_OTHER_B_VID_300 Bridge 300 LAN2, LAN3, LAN4 IPTV

Getting Started

26304W Configuration Guide

FIGURE 1-1. Rear View

6304W Configuration Guide 3

CHAPTER 2 Logging into the Web GUI

Logging into the Web GUI

Follow these steps to log into the web GUI.

1Connect your device to LAN 1 or Wireless.

2Launch a web browser.

3Connect to 192.168.1.1. A login screen displays.

4Enter the user name and password. User names and passwords are case-sensi-

tive.

TABLE 2-1. User Names and Default Passwords

Administrator User

User Name admin useradmin

Default Password admin useradmin

Logging into the Web GUI

46304W Configuration Guide

FIGURE 2-1. Login Screen

Changing Passwords

Follow these steps to change a password.

1Connect your device to LAN 1 or Wireless.

2Launch a web browser.

3Connect to 192.168.1.1. A login screen displays.

4Enter the user name and password. The home screen displays.

5Select Management > User Info > User Info.

6304W Configuration Guide 5

Changing Passwords

FIGURE 2-2. User Info

6Select whether to change the user or admin password.

7Enter the user name, the new password, and then confirm the password.

8Click Save/Apply.

6304W Configuration Guide 7

CHAPTER 3 Viewing Device Information

Viewing Device Information

Follow these steps to view device information.

1Connect your device to LAN 1 or Wireless.

2Launch a web browser.

3Connect to 192.168.1.1. A login screen displays.

4Enter the user name and password. The home screen displays.

5Select Status > Device Info > Device Basic Info. You can view the device type,

device ID, hardware version, and software version.

Viewing Device Information

86304W Configuration Guide

FIGURE 3-1. Device Basic Info
