Addonics Technologies HDUS11325DX Manuel utilisateur

Technical Support

If you need any assistance to get your unit functioning properly, please have your

product information ready and contact Addonics Technical Support at:

Hours: 8:30 am - 6:00 pm PST

Phone: 408-453-6212

Email: http://www.addonics.com/support/query/

v3.1.11

www.addonics.com

User Guide

1:11 HDD Duplicator Deluxe

(HDUS11325DX)

T E C H N O L O G I E S

ENT

ESC

Duplicator Panel

Source Drive Bay

Target Drive Bay 6 - 11

Target Drive Bay 1 - 5

Power Switch

Table Of Contents

Basic Instructions

Functions

Copy HDD

Compare HDD

PreScan Source

ReScan Bus

Source Size

Overwrite

Setup

Advanced Setup

Basic Troubleshooting

Error Messages List

Firmware Update Procedure

............. Page 3

............. Page 5

............. Page 6

............. Page 7

............. Page 8

............. Page 9

............. Page 13

............. Page 16

............. Page 17

............. Page 18

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

I. Installing Drive into the HDD Duplicator

For installing a hard drive on the various enclosures that come with the HDD duplicator, refer to the

bundled enclosure installation guides.

Step 1

Open the source drive door and slide in the 3.5” SATA hard disk Source drive into the drive bay. Close the

front panel and using the key provided, turn the key lock to the Lock position. This will secure the drive and

turn on the power tothe hard drive.

Step 2

Open the target drive door(s) and slide in the 3.5” SATA hard disk Target drive(s) into the drive bay. Close

the front panel and using the key provided, turn the key lock to the Lock position. This will secure the drive

and turn on the power tothe hard drive.

Note: Refer to the Snap-In 25 user guide for 2.5” SATA hard drive installation.

II. Connecting the Power Cable and Powering On

a. Connect the power cord provided from the wall outlet tothe back of the tower.

b. Amain power switch is located at the back of the tower. Turn the switch on.Another auxiliary

switch is located on the front of the tower.

c. Push the auxiliary switch button toturn on the HDD duplicator.

III. The Duplicator Panel

There are four buttons and an LCD on the panel of HDD Duplicator.

1 – LCD shows a function or a message.

2 – it is used to scroll up function menus.

3 – it is used to scroll down function menus.

4 – it is used to execute a function.

5 – it is used to cancel a function.

ENT

ESC

Duplicator Panel

Basic Instructions

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

IV. Duplicating adrive

When the duplicator powers on, it initializes and goes through the steps below

Shows the firmware version Initialize SDRAM's status..

Detect Drives' status. Shows the first function:

Copy HDD copies data directly from the source hard disk tothe target hard disk.

Press ENT button to begin copy. The system will auto-detect the hard disks and show the following info on

the LCD.

The LCD will show the following info during the copying process: remaining time, completed percentage.

The copy speed, capacity and time will vary depending on the source hard disk. Once the copying process

is complete the LCD will display the following results.

HD Duplicator

1-1 Ver:Initialize SDRAM

Detect Drives

Copy-36MBs 0%

235.7GB 1:48

Copy HD

OK:

1.Copy HD

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

Functions

The copy controllerhas 11 functions in total, with the 11th (AdvSetup) beinga hidden system

function that only appears when the ESC key is pressed for 2 seconds until there is a beep. These

are shown below.

10-01. Language

10-02. CopySize

10-03. Startup Menu

10-04.Auto Compare

10-05. Button Sound

10-06. Device Info

10-07. System Info

10-08. Fast Copy

10. Setup

10-09.Auto Start Drive

10-10.Auto StartTimer

10-11.Tolerance Size

Duplicator Controller

1. CopyHDD

2.Async CopyHDD

3. Compare HDD

4.Async Compare

5. PreScan Source

6. ReScan BUS

7. Source Size

11.AdvSetup

11-01. Read ErrorSkip

11-02. Update Firmware

11-03. Compare Firmware

11-04. Quick Erase HDD

11-05. Full Erase HDD

11-06. H/W Diagnostic

11-07. Load Default

8. Secure Erase

9. Overwrite

10-12. BootTime Delay

10-13. Quick Compare

11-08. CopyHPA

11-09. Burn In

10. Setup

11.AdvSetup

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

CopyHDD

CopyHDD copies data directlyfrom the source hard disk to

the target hard disk. Please make

sure that the capacity of the target hard disk is equal o

rlarger than the source hard disk.

Choose option 1 from the menu:

Press ENT to begin copy. The system will auto-detect the hard di

sks and showthe following

copying info on the LCD.

The LCD will show the following info duringthe copyin

g process: elapsed time, completed

percentage. Thecopy speed, capacity and time willvary

depending on the source hard disk. Once

the copying process is complete the LCD will display t

he followingresults.

Copy-36MB/s 0%

232.9GB 00:00:00

CopyHDD

OK: 11 Fail: 0

1. CopyHDD

HDD:11 232.9GB

Async Copy HDD

This option is used to specify the size of the source for simplifying further copying operations.

Choose option 2 from the menu:

2.Async Copy HDD

HDD:10 232.9GB

Press ENT . Before the start of the reproduction, if theconsole detects that a hard drive

capacity is less than source, then the LCD will show the cor

responding channel number.

Space Not Enough

Andthen automatically copies. The LCD will displayt

he following info.

Acpy-36MB/s 0%

232.9GB 00:00:00

If the replication process to continue to add additi

onal hard disk device, LCD will only show the last

completed percentage.

Once the copying process is complete theLCD will disp

laythe following results.

Async CopyHDD

OK: 11 Fail: 0

Compare

Compare HDD isused to see if the data on asourceha

rd disk is identical to the target harddisk

after the Copy HDoperation.

Choose option 3 from the menu:

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

3. Compare HDD

HDD: 11 232.9GB

Press ENT to begin the comparison.The LCD will display the following info.

Comp-23MB/s 0%

232.9GB 00:00:00

Once the comparison is complete the LCD will display the following info as well as the amount of

data on the source hard disk.

Compare OK:11

Fail: 0 Di: 0

PreScan Source

PreScan HDD is used to check if the source hard disk can be accessed properly.

It also tests the read speed.

Choose option 5 from the menu:

5. PreScan Source

HDD : 11 232.9GB

Async Compare

Compare HDD is used to see if the data on a source hard disk is identical to the

target hard disk after the Copy HDD operation. While compare process is

on-going, allows you to plug-in additional target drives and comparison will

automatically start for the added target drive.

Choose option 4 from the menu:

4.Async Compare

HDD: 11 232.9GB

Press ENT

to begin the async comparison.The LCD will display the following info.

ACmp-23MB/s 0%

232.9GB 00:00:00

Compare OK:11

Fail: 0 Di: 0

If the comparison process continues to addadditional hard disk device, LCD will onlyshow the

last completed percentage.

Once the copying process is complete theLCD will displaythe following results.

Press ENT

to begin scan. The LCD will displaythe following info

Scan-90MB/s 1%

230.6GB 00:00:27

Once the scan is complete, the LCD will displaythe corresponding results

PreScan OK!

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

6. ReScan BUS

ReScan Bus

Chooseoption 6 from themenu:

Press ENT to re-scan hardware. The LCD will displaythe followinginfo.

Re-Scan BUS NOW?

Yes

When the scan is completetheLCD will display the fol lowing info.

Bus re- scan OK!

7. Source Size

Source Size

Source Size is used to show the capacity of the source.

Choose option 7 from the menu:

Press ENT andthe LCD will show the following info.

HDD:Hitachi

Size:232.9GB

Then press ENT and the LCD will show the data's size info.

HDD:Hitachi

Data:200.9GB

8. Secure Erase

Secure Erase

Secure Erase is used to wipe the data of the hard disk, it will erase all of HDD of duplicator

(included Source HDD).

Choose option 8 from the menu:

Press ENT to access option. By default it is set to No. Use the Up and Down arrow keys to choose

Yes.

Wipe all data.

Continue? No

Press ENT andthe LCD will show the following info.

ReScan Bus allows swapping the source or target in and out without having to

reboot the system.

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

10. Setup

Setup

Setup allows various system settings to be changed. There are 12 sub-options:

Language, Copy Size, Startup Menu, Auto Compare, Button Sound, Device Info,

System Info, Fast Copy, Auto Start Drive, Auto Start Timer, Tolerance Size and

Boot Time Delay.

Choose option 8 from the menu:

In Process

Elapsed 01:00

9. Overwrite

Overwrite

Overwrite is used to overwrite the data of the hard disk, it will erase all HDDs connected tothe duplicator

(including Source HDD). Thereare 3 sub-options: One pass,3 pass and 7 pass.

Choose option 9 from the menu:

Press ENT to access option. By default it is One pass Use the Up and Down arrow keys to choose

other options.

9-01. Overwrite

One pass

Press ENT to access option. By default it is set toNo. Use the Up and Down arrow keys to choose

Yes.

Wipe all data.

Continue? No

Press ENT and theLCD will show thefollowing info.

In Process

Elapsed 01:00

Language

This optionis used toselectthe system's language sup port. By default this is set to English. Press

ENT to change the Language settings.

Language

English

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

10-02. Setup

CopySize

Press ENT and theLCD will display a detailed list of options as shown below

Use the Up and Down arrow keys to choose dierent copy sizes. The system will oer their

corresponding percentages so the user can specify the amount to copy from the source hard disk.

Press ENT to conrm and save the changes.

CopySize

100%~1% (*MB)

Startup Menu

This option allows you to set an option other than "Setup" to be displayed as the rst available

option on the menu every time you start the system.

Startup Menu

1. CopyHDD

Press ENT then use the Up and Down arrowkeys to choose other options. By default the rst

menu option is Copy HDD.

10-03. Setup

Startup Menu

Auto Compare

This option automaticallycompares the source hard disk with the target hard disk after a copy

operation is completed.

Press ENT to access option. By default it is set to O. Use the Up and Down arrowkeys to choose

On.

Auto Compare

O

10-04. Setup

Auto Compare

CopySize

This optionis used tospecify the size of thesource hard disk for simplifying furthercopying

operations.

Button Sound

This option is used to control the sound of a button when you press it.

10-05. Setup

Button Sound

Press ENT andthe LCD will display the following info. Use the Up and Down arrow keys to choose

whetherbutton sound is on or o.

ButtonSound

Table des matières

Autres manuels Addonics Technologies duplicateur de disques

Addonics Technologies

Addonics Technologies HDUS4SNDX-A Manuel utilisateur

Addonics Technologies

Addonics Technologies HD9SITDRHS Manuel utilisateur

Addonics Technologies

Addonics Technologies Jasper II SID Manuel utilisateur

Addonics Technologies

Addonics Technologies DGBRC7 Manuel utilisateur

Addonics Technologies

Addonics Technologies HDUSAS Manuel utilisateur

Addonics Technologies

Addonics Technologies ST5BDVES Manuel utilisateur

Addonics Technologies

Addonics Technologies DDU7SAS Manuel utilisateur

Addonics Technologies

Addonics Technologies Jasper II JD2P3 Manuel utilisateur

Addonics Technologies

Addonics Technologies HDU11SAS Manuel utilisateur

Addonics Technologies

Addonics Technologies DDU3SAS Manuel utilisateur

Addonics Technologies

Addonics Technologies HDU11SITDR Manuel utilisateur

Addonics Technologies

Addonics Technologies HDUSI325-A Manuel utilisateur

Addonics Technologies

Addonics Technologies DGBRC1 Manuel utilisateur

Addonics Technologies

Addonics Technologies HDUSI325AES Manuel utilisateur

Addonics Technologies

Addonics Technologies M2MSHD9H-2S Manuel utilisateur

Addonics Technologies

Addonics Technologies HD4SNH Manuel utilisateur

Addonics Technologies

Addonics Technologies UDFHNVM7 Manuel utilisateur

Addonics Technologies

Addonics Technologies UDFHNVM15 Manuel utilisateur

Addonics Technologies

Addonics Technologies UDFH15-C Manuel utilisateur

Addonics Technologies

Addonics Technologies HDUS11SNDX Manuel utilisateur

Addonics Technologies

Addonics Technologies Jasper II 1S JD2-325SN Manuel utilisateur

Addonics Technologies

Addonics Technologies DGC3 Manuel utilisateur

Addonics Technologies

Addonics Technologies MSHDU11T Manuel utilisateur

Addonics Technologies

Addonics Technologies HDUS325DX Manuel utilisateur

Manuels duplicateur de disques populaires d'autres marques

Riso

Riso CV Series Manuel

MicroBoards Technology

MicroBoards Technology GX-2 Manuel utilisateur

Carry

Carry Pro118 Manuel utilisateur

CopyPro

CopyPro PowerPro II Manuel utilisateur

Primera

Primera Max Manuel utilisateur

Logicube

Logicube EchoPlus-NG Manuel utilisateur

Silca

Silca Delta 2000 SA Manuel utilisateur

Reflex7

Reflex7 Daisy Chain Series Manuel utilisateur

Vinpower Digital

Vinpower Digital SharkCopier DC Manuel utilisateur

Codonics

Codonics Virtua E Manuel utilisateur

Octave

Octave Copy Master II Manuel utilisateur

Kanguru

Kanguru U2-DVDDUPE-S Manuel utilisateur

StarTech.com

StarTech.com 8STSATDUP11 Manuel utilisateur

DUPLO SEIKO CORPORATION

DUPLO SEIKO CORPORATION Duprinter DP-460 Manuel utilisateur

Vinpower Digital

Vinpower Digital MiniLoader VDX-1 Manuel utilisateur

MicroBoards Technology

MicroBoards Technology Quic Disc QD-2 Manuel utilisateur

Telex

Telex SpinWise Manuel utilisateur

Aleratec

Aleratec 260206 Manuel utilisateur
