Addonics Technologies HDUSI325AES Manuel utilisateur

Technical Support

If you need any assistance to get your unit functioning properly, please have your

product information ready and contact Addonics Technical Support at:

Hours: 8:30 am - 6:00 pm PST

Phone: 408-453-6212

Email: http://www.addonics.com/support/query/

v3.1.11

User Guide

1:1 HDD Duplicator PRO-S

(HDUSI325AES)

T E C H N O L O G I E S

www.addonics.com

Duplicator Panel

Source Drive Bay

Target Drive Bay

Power Switch

Table Of Contents

Basic Instructions

Functions

Copy HDD

Compare HDD

PreScan Source

ReScan Bus

Source Size

Overwrite

Setup

USB Mode

Advanced Setup

Basic Troubleshooting

Error Messages List

Firmware Update Procedure

............. Page 3

............. Page 5

............. Page 6

............. Page 7

............. Page 8

............. Page 11

............. Page 15

............. Page 16

............. Page 17

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

I. Installing drive into the HDD Duplicator

Note: Make sure that the capacity of the target hard disk is equal

or larger than the source hard disk.

For installing a hard drive on the various enclosures that

come with the HDD duplicator, refer to the bundled

enclosure installation guides.

When using the Diamond Cipher enclosure, it is important

that the cipher key needs to be inserted on the cipher key

slot on the enclosure before powering on the HDD

Duplicator.

Step 1

Once the hard drive is installed on the drive enclosure, slide in

the Source drive into the drive bay. Push down the handle and

using the key provided, turn the key lock to the Lock position.

This will secure the drive and turn on the power to the hard drive.

Step 2

Slide in the Target drive into the drive bay. Push down the

handle and using the key provided, turn the key lock to the Lock

position. This will secure the drive and turn on the power to the

hard drive.

II. Connecting the power cable and powering on

a. Connect the power cord provided from the wall outlet to the

back of the tower.

b. A main power switch is located at the back of the tower. Turn

the switch on. Another auxiliary switch is located on the front

of the tower.

c. Push the auxiliary switch button to turn on the HDD

duplicator.

III. The Duplicator Panel

There are four buttons and an LCD on the panelof HDD

Duplicator.

1 –LCD shows a function or a message.

2 –it is used to scroll up function menus.

3 –it is used to scroll down function menus.

4 –it is used to execute a function.

5 –it is used to cancel a function.

Basic Instructions

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

IV. Duplicating a drive

When the duplicator powers on, it initializes and goes through the

steps below

Copy HDD copies data directly from the source hard disk to the

target hard disk.

Press ENT button to begin copy. The system will auto-detect the

hard disks and show the following info on the LCD.

The LCD will show the following info during the copying process:

remaining time, completed percentage. The copy speed, capacity

and time will vary depending on the source hard disk. Once the

copying process is complete the LCD will display the following

results.

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

Functions

The copy controller has 8 functions in total, with the th (Adv Setup) beinga hidden system

function that onlyappears when the ESC key is pressed for 2 seconds until there is a beep. These

are shown below.

8-01. Language

8-03. Startup Menu

8-04.Auto Compare

8-05. Copy With Size

8-06. Button Sound

8-07. Device Info

8-08. System Info

8. Setup

8-02. Copy Size

10.AdvSetup

10-01. Detect HDD Delay

10-02. Read Error Skip

10-03. Update Firmware

10-04. Compare Firmware

10-05. Quick Erase HDD

10-06.H/W Diagnostic

10-07.Load Default

10-08.Link Option

10-09.USBAuto-Link

10-10.Copy HPA

Duplicator Controller

1. Copy HDD

2. Compare HDD

3. PreScan Source

4. ReScan BUS

5. Source Size

6. Secure Erase

7. Overwrite

8. Setup

9. USB Mode

10.AdvSetup

8-09. Fast Copy

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

CopyHDD

Copy HDD copies data directly from the source hard disk to the target hard disk. Please make

sure that the capacity of the target hard disk is equal or larger than the source hard disk.

Choose option 1 from the menu:

Press ENT to begin copy. The system will auto-detect the hard disks and show the following

copyinginfo on the LCD.

The LCD will show the following info during the copying process: elapsed time, completed

percentage. The copyspeed, capacity and time will vary depending on the source hard disk. Once

the copyingprocessis complete the LCDwill displaythe following results.

Copy-36MB/s 0%

232.9GB 00:00:00

Copy HDD

OK: 1 Fail: 0

1. Copy HDD

HDD:1 232.9GB

Compare

Compare HDDis used to see if the data on a source hard disk is identical to the target hard disk

after the Copy HDoperation.

Choose option 2 from the menu:

2. Compare HDD

HDD: 1 232.9GB

Press ENT to begin the comparison. The LCD will display the following info.

Comp-23MB/s 0%

232.9GB 00:00:00

Once the comparison is complete the LCD will display the following info as well asthe amount of

data on the source harddisk.

Compare OK:1

Fail: 0 Di: 0

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

PreScan Source

PreScan HDD is used to check if the source hard disk can be accessed properly.

It also tests the read speed.

Choose option 3 from the menu:

3. PreScan Source

HDD : 1 232.9GB

Press ENTto begin scan. The LCD will display the following info

Scan-90MB/s 1%

230.6GB 00:00:27

Once the scan is complete, the LCD will display the correspondingresults

PreScan OK!

4. ReScan BUS

ReScanBus

Chooseoption 4 from the menu:

Press ENT to re-scan hardware. The LCD will display the followinginfo.

Re-Scan BUS NOW?

Yes

When the scan is complete the LCD will display the following info.

Bus re- scan OK!

ReScan Bus allows swapping the source or target in and out without having to

reboot the system.

8.Setup

Setup

Setup allows various system settings to be changed. There are 12 sub-options:

Language, Copy Size, Startup Menu, Auto Compare, Button Sound, Device Info,

System Info, Fast Copy, Auto Start Drive, Auto Start Timer, Tolerance Size and

Boot Time Delay.

Choose option 8 from the menu:

InProcess

Elapsed 01:00

7. Overwrite

Overwrite

Overwrite is used to overwrite the data of the hard disk, it will erase all HDDs connected to the duplicator

(including Source HDD). There are 3 sub-options: One pass,3 pass and 7 pass.

Choose option 7 from the menu:

Press ENT to accessoption. By default it isOne pass Use the Up and Down arrow keys to choose

otheroptions.

7-01. Overwrite

One pass

Press ENT to accessoption. By default it isset to No. Use the Up and Down arrowkeys to choose

Yes.

Wipe all data.

Continue? No

Press ENT and the LCD will show the following info.

In Process

Elapsed 01:00

Language

This option is used to select the system's language support. By default this is set to English. Press

ENT to change the Language settings.

Language

English

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

8-02.Setup

CopySize

Press ENT and the LCD willdisplay a detailed list of options as shownbelow

Use the Up and Down arrow keys to choose dierent copy sizes. The system will oer their

corresponding percentages so the user can specify the amount to copy from the source hard disk.

Press ENT to conrm and save the changes.

Copy Size

100%~1% (*MB)

Startup Menu

This option allows you to set an option other than "Se tup" to be displayed as the rst available

option on the menu every time you start the system.

Startup Menu

1. Copy HDD

Press ENT then use the Up and Down arrow keys to choose other options. By default the rst

menu option is Copy HDD.

8-03.Setup

Startup Menu

Auto Compare

This option automaticallycompares the source hard diskwith the target hard disk after a copy

operation is completed.

Press ENT to accessoption. By default it is set to O. Use the Up and Down arrowkeys to choose

On.

Auto Compare

O

8-04.Setup

Auto Compare

CopySize

This option is used to specify the size of the source hard disk for simplifyingfurthercopying

operations.

CopyWithSize

This option is used to set the source harddisk with the target hard diskthe same capacity after a

copyoperation.

8-05.Setup

Copy With Size

Press ENT to enter the following gure. The default is O. Use the Up and Down arrow keys to

choose On.

Copy with Size

O

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

Device Info

This option is used to display the detailsof all hard disks connected to the copy controller.

8-07.Setup

Device Info

Press ENT and the LCD will display each hard disk' information in order as shown below.

0 Source CH: 0

Hitachi 232.9GB

System Info

This optiondisplayssystem information.

8-08.Setup

System Info

Fast Copy

This option displays Fast Copy. Fast Copy only copies data on the source drive

to the target drives. Currently only supports FAT, FAT32, NTFS, HFS, Ext2 and

Ext3 partitions. 8-09. Setup

Fast Copy

Press ENT and the LCD will display the following info. Use the Up and Down arrowkeys to choose

whether fast copy is on or o. (This function currently only eective in FAT, FAT32, NTFS, HFS,

Ext2 and Ext3 partitions.)

FastCopy

USB Mode

Not Available

Button Sound

This option isused to control the sound of a button when you press it.

8-06.Setup

Button Sound

Press ENT and the LCD will display the following info. Use the Up and Down arrow keys to choose

whether button sound is on or o.

ButtonSound

www.addonics.com Technical Support (M-F 8:30am - 6:00pm PST) Phone: 408-453-6212 Email: www.addonics.com/support/query/

Table des matières

Autres manuels Addonics Technologies duplicateur de disques

Addonics Technologies

Addonics Technologies Jasper II 1S JD2-325SN Manuel utilisateur

Addonics Technologies

Addonics Technologies HDUS11325DX Manuel utilisateur

Addonics Technologies

Addonics Technologies HDUSI325 Manuel utilisateur

Addonics Technologies

Addonics Technologies DDU7SAS Manuel utilisateur

Addonics Technologies

Addonics Technologies UDFHNVM15 Manuel utilisateur

Addonics Technologies

Addonics Technologies DDU3SAS Manuel utilisateur

Addonics Technologies

Addonics Technologies DGBRC3 Manuel utilisateur

Addonics Technologies

Addonics Technologies HD9SITDRHS Manuel utilisateur

Addonics Technologies

Addonics Technologies HDUS11SNDX Manuel utilisateur

Addonics Technologies

Addonics Technologies DigiCopier III DGC3 Manuel utilisateur

Addonics Technologies

Addonics Technologies HDUS11NB Manuel utilisateur

Addonics Technologies

Addonics Technologies HDU11SAS Manuel utilisateur

Addonics Technologies

Addonics Technologies Jasper II 3M Manuel utilisateur

Addonics Technologies

Addonics Technologies ST55HPMXA Manuel utilisateur

Addonics Technologies

Addonics Technologies DGC3 Manuel utilisateur

Addonics Technologies

Addonics Technologies DGBRC1 Manuel utilisateur

Addonics Technologies

Addonics Technologies JD2-3SN25 Manuel utilisateur

Addonics Technologies

Addonics Technologies Jasper II SID Manuel utilisateur

Addonics Technologies

Addonics Technologies HDUS4SNDX-A Manuel utilisateur

Addonics Technologies

Addonics Technologies AEDVDCOPPM4U Manuel utilisateur

Addonics Technologies

Addonics Technologies MSDU5 Manuel utilisateur

Addonics Technologies

Addonics Technologies UDFH15-C Manuel utilisateur

Addonics Technologies

Addonics Technologies ST5DVRE Manuel utilisateur

Addonics Technologies

Addonics Technologies HDMU3 Manuel utilisateur

Manuels duplicateur de disques populaires d'autres marques

Riso

Riso CV Series Manuel

MicroBoards Technology

MicroBoards Technology GX-2 Manuel utilisateur

Carry

Carry Pro118 Manuel utilisateur

CopyPro

CopyPro PowerPro II Manuel utilisateur

Primera

Primera Max Manuel utilisateur

Logicube

Logicube EchoPlus-NG Manuel utilisateur

Silca

Silca Delta 2000 SA Manuel utilisateur

Reflex7

Reflex7 Daisy Chain Series Manuel utilisateur

Vinpower Digital

Vinpower Digital SharkCopier DC Manuel utilisateur

Codonics

Codonics Virtua E Manuel utilisateur

Octave

Octave Copy Master II Manuel utilisateur

Kanguru

Kanguru U2-DVDDUPE-S Manuel utilisateur

StarTech.com

StarTech.com 8STSATDUP11 Manuel utilisateur

DUPLO SEIKO CORPORATION

DUPLO SEIKO CORPORATION Duprinter DP-460 Manuel utilisateur

Vinpower Digital

Vinpower Digital MiniLoader VDX-1 Manuel utilisateur

MicroBoards Technology

MicroBoards Technology Quic Disc QD-2 Manuel utilisateur

Telex

Telex SpinWise Manuel utilisateur

Aleratec

Aleratec 260206 Manuel utilisateur
