ADC HiGain HRU-402 Manuel utilisateur

HiGain

TECHNICAL PRACTICE

ALM

TELEPHONE Co. PROPERTY

LP2

ESF

LP1

B8ZS

AMI

LBK

RCV

LEV

0 -15

DIS EN

TLOS

XMT

BRG

RCV

RS-232

DCE

BARCODE

HiGain

HDSL2

HRU-402 List 4

Remote Unit

Part Number: 150-1592-04

CLEI Code: T1L3KLRD

1024.book Page i Thursday, January 4, 2001 10:30 AM

LTPH-TP-1024-02, Issue 2

ii January 3, 2001 HRU-402 List 4

Revision History of This Practice

To order copies of this document, use document catalog number LTPH-TP-1024-02.

January 3, 2001

Trademark Information

ADC and Soneplex are registered trademarks of ADC Telecommunications, Inc.

HiGain is a registered trademark of PairGain Technologies, Inc. No right, license, or

interest to such trademarks is granted hereunder, and you agree that no such right,

license, or interest shall be asserted by you with respect to such trademark.

Other product names mentioned in this practice are used for identification purposes

only and may be trademarks or registered trademarks of their respective companies.

Disclaimer of Liability

Information containedin this document iscompany private toADC DSL Systems, Inc.,

and shall not be modified, used, copied, reproduced or disclosed in whole or in part

without the written consent of ADC.

Contents herein are current as of the date of publication. ADC reserves the right to

change the contents without prior notice. In no event shall ADC be liable for any

damages resulting from loss of data, loss of use, or loss of profits, and ADC further

disclaims any and all liability for indirect, incidental, special, consequential or other

similar damages. This disclaimer of liability applies to all products, publications and

services during and after the warranty period.

Issue Release Date Revisions Made

01 September 3, 1999 Initial Release

02 January 3, 2001 Style and format changes

1024.book Page ii Thursday, January 4, 2001 10:30 AM

LTPH-TP-1024-02, Issue 2 Using This Technical Practice

HRU-402 List 4 January 3, 2001 iii

USING THIS TECHNICAL PRACTICE

Three types of messages, identified by icons, appear in the text:

For a list of abbreviations used in this document, refer to “Appendix C -

Abbreviations” on page 41.

UNPACK AND INSPECT YOUR SHIPMENT

Upon receipt of the equipment:

1Unpack the container and inspect the product for signs of damage. If the

equipment has been damaged in transit, immediately report the extent of

the damage to the transportation company and to your sales

representative. When storing the equipment for a prolonged period, use

the original container.

2Verify the contents using the packing list to ensure complete and

accurate shipment.

Notes contain information about special circumstances.

Caution symbols indicate the possibility of personal injury

or equipment damage.

The Electrostatic Discharge (ESD) susceptibility symbol

indicates that adevice or assemblyis susceptibleto damage

from electrostatic discharge.

1024.book Page iii Thursday, January 4, 2001 10:30 AM

Unpack and Inspect Your Shipment LTPH-TP-1024-02, Issue 2

iv January 3, 2001 HRU-402 List 4

1024.book Page iv Thursday, January 4, 2001 10:30 AM

LTPH-TP-1024-02, Issue 2 Table of Contents

HRU-402 List 4 January 3, 2001 v

TABLE OF CONTENTS

Overview _______________________________________________ 1

Features.................................................................................... 2

Product Description ................................................................. 3

Status LEDs ............................................................................. 5

Compatibility ........................................................................... 7

Installation _____________________________________________ 8

Setting Panel Circuit Board Options........................................8

Set the SCURR Option.............................................. 9

Set the LPWR Option.............................................. 10

Install the HRU-402............................................................... 11

Remote Login __________________________________________ 12

Connecting to a Maintenance Terminal.................................12

Logging On and Off............................................................... 13

Remote Terminal Main Menu................................................ 15

Performance Monitoring_________________________________ 16

PM Applications .................................................................... 16

Accessing the Performance Monitoring Menu...................... 18

Current Status Screen .............................................. 20

Blockage Indicator History Screen.......................... 22

Sectionalized Event History Screen ........................ 24

Performance 15-Minute History Screen.................. 26

Performance 1-Day History Screen......................... 27

Set Date and Time Screen .......................................28

Signal Generator Screen.......................................... 29

Set HiGain Configuration........................................ 31

1024.book Page v Thursday, January 4, 2001 10:30 AM

Table of Contents LTPH-TP-1024-02, Issue 2

vi January 3, 2001 HRU-402 List 4

Appendix A - Specifications _______________________________33

Card-Edge Connector.............................................................34

Craft Port................................................................................35

NIU Query Command............................................................36

Appendix B - Product Support_____________________________37

Technical Support...................................................................37

Returns....................................................................................38

Appendix C - Abbreviations _______________________________41

Certification and Warranty _________________Inside Back Cover

1024.book Page vi Thursday, January 4, 2001 10:30 AM

LTPH-TP-1024-02, Issue 2 List of Figures

HRU-402 List 4 January 3, 2001 vii

LIST OF FIGURES

1.Typical HiGain System .......................................................................... 1

2.HRU-402 Front Panel............................................................................. 3

3.Location of Switch S1 on HRU-402 Circuit Board ............................... 9

4.Installing the HRU-402 in a Remote Enclosure................................... 11

5.Connecting to a Maintenance Terminal ............................................... 12

6.Remote Terminal Login Screen ........................................................... 14

7.Sectionalized Analysis of T1 Transmission......................................... 16

8.Performance Monitoring Menu............................................................ 18

9.Current Status Screen........................................................................... 20

10.Blockage Indicator History Screen....................................................... 22

11.Sectionalized Event History Screen..................................................... 24

12.Performance 15-Minute History Screen............................................... 26

13.Performance 1-Day History Screen...................................................... 27

14.Set Clock Screen .................................................................................. 28

15.Signal Generator Screen....................................................................... 29

16.Set HiGain Configuration Screen......................................................... 31

17.Card-Edge Connector Pinouts.............................................................. 34

18.RS-232 Craft Port Pinout ..................................................................... 35

1024.book Page vii Thursday, January 4, 2001 10:30 AM

List of Tables LTPH-TP-1024-02, Issue 2

viii January 3, 2001 HRU-402 List 4

LIST OF TABLES

1.HRU-402 Front-Panel Features..............................................................4

2.Status LED Descriptions.........................................................................5

3.Switch S1 - SCURR Option Settings....................................................10

4.Switch S1 - LPWR Option Settings......................................................10

5.Remote Terminal Main Menu Items.....................................................15

6.Performance Monitoring Menu Items...................................................19

7.Status Screen Parameters......................................................................20

8.Sectionalized Event Descriptions .........................................................25

9.Signal Generator Test Options..............................................................30

10.User Options for the Set HiGain Configuration Screen .......................32

11.Model-specific NIU Query Commands................................................36

1024.book Page viii Thursday, January 4, 2001 10:30 AM

LTPH-TP-1024-02, Issue 2 Overview

HRU-402 List 4 January 3, 2001 1

OVERVIEW

The ADC®HiGain®Remote Unit, HRU-402, functions as the remote end of

a repeaterless T1 transmission system. When used with HiGain Line Units

(HLUs) and HiGain Doubler Units (HDUs), the HiGain system provides

1.544 Mbps data transfer on two unconditioned copper pairs over the full

Carrier Service Area (CSA) range.

In addition to HiGain Maintenance Terminal screens, the HRU-402 List 4

provides special performance monitoring and sectionalized analysis

information for fault isolation. This performance monitoring feature supports

real-time and on-demand reporting.

Figure 1 shows a basic HiGain configuration for a T1 High-bit-rate Digital

Subscriber Line (HDSL) circuit. The HLU is installed at the Central Office

(CO) shelf and the remote unit is housed in a remote enclosure at the

Customer Premises Equipment (CPE)site.OptionalHDUsprovidetheability

to double or even triple the distance range for customer applications located

outside the CSA.

Figure 1. Typical HiGain System

1024.book Page 1 Thursday, January 4, 2001 10:30 AM

Overview LTPH-TP-1024-02, Issue 2

2 January 3, 2001 HRU-402 List 4

FEATURES

•Front panel featuring:

–Status LEDS for DS1 and HDSL

–RS-232 craft port for connection to a maintenance terminal

–Receive (RCV) and transmit (XMT) test access jacks

–HDSL margin threshold indicator

•Local or line powering options

•Real-time Performance Monitoring (PM) and sectionalized analysis

–ANSI T1.403 Performance Report Messages (PRM)

–Supplemental Performance Report Messages (SPRM)

–Network Performance Report Messages (NPRM)

–Alarm Indicator Signal-Customer Interface (AIS-CI)

–Remote Alarm Indicator-Customer Interface (RAI-CI)

–SuperFrame Remote Alarm Indicator (SF-RAI)

–On-demand access to stored PM information for applications which

do not support real-time monitoring through craft port or inbandand

out-of-band commands

–Mode analysis and SF to Extended SuperFrame (ESF) frame format

conversion for fault isolation

•Support for the Network Remote (NREM), SmartJack (SMJK),

Customer Local Loopback (CLOC), and Transmit Loss of Signal

(TLOS) loopback commands

1024.book Page 2 Thursday, January 4, 2001 10:30 AM

Autres manuels pour HiGain HRU-402

Table des matières

Autres manuels ADC Matériel réseau

ADC

ADC PG-PLUS PLL-733 Manuel utilisateur

ADC

ADC LoopStar 750 Manuel utilisateur

ADC

ADC H2TU-C-202 Instructions d'utilisation d'origine

ADC

ADC ProPatch Miniature Series Manuel utilisateur

ADC

ADC Campus RS Destop Unit Manuel utilisateur

ADC

ADC PG-FlexPlus AMU-912 Manuel utilisateur

ADC

ADC HiGain H2TU-C-319 List 4E Instructions d'utilisation d'origine

ADC

ADC HIGAIN H4TU-C-388 Instructions d'utilisation d'origine

ADC

ADC HIGAIN H4TU-C-231 LIST 5A Instructions d'utilisation d'origine

ADC

ADC Carrier-Grade WiMAX Base Station WMX 5000 Manuel utilisateur

ADC

ADC HRE-602 List 1 Manuel utilisateur

ADC

ADC H2TU-C-388 HiGain Instructions d'utilisation d'origine

ADC

ADC Digivance 19717-A Manuel

ADC

ADC HRE-204 List 1 Manuel utilisateur

ADC

ADC H2TU-C-202 Manuel utilisateur

ADC

ADC H2TU-C-388 HiGain Manuel utilisateur

ADC

ADC HiGain H2TU-C-319 List 4E Instructions d'utilisation d'origine

ADC

ADC HiGain H2TU-C-319 List 4E Instructions d'utilisation d'origine

ADC

ADC H4TU-C-319 List 1 Line Unit Manuel utilisateur

ADC

ADC Double Pair/Line Power G.SHDSL WorldDSL G.S Manuel utilisateur

ADC

ADC HRE-425 List 1 Manuel utilisateur

ADC

ADC LoopStar 1600 Manuel utilisateur

ADC

ADC 75 Ohm Interconnect Manuel utilisateur

ADC

ADC H4TU-C-319 List 1 Line Unit Instructions d'utilisation d'origine

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur

Lanner

Lanner NCA-1525 Manuel utilisateur
